1. INTRODUCTION

This book is a work in progress. Feedback is very much encouraged and welcomed!

The title of this book could equally well be "A getting started guide for users of graph databases and the Gremlin query language featuring hints, tips and sample queries". It turns out that is a bit too too long to fit on one line for a heading but in a single sentence that describes the focus of this work pretty well.

I hope people find what follows useful. It remains a work in progress and more will be added in the coming weeks and months as time permits. I am hopeful that what is presented so far is of some use to folks, who like me, are learning to use the Gremlin query and traversal language and related technologies.

1.1. How this book came to be

I forget exactly when, but over a year ago I started compiling a list of notes, hints and tips, initially for my own benefit, of things I had found poorly explained elsewhere while using graph databases and especially using Apache TinkerPop, Janus Graph and Gremlin. Over time that document grew (and continues to grow) and has effectively become a book. After some encouragement from colleagues I have decided to release it as a living book in an open source venue so that anyone who is interested can read it. It is aimed at programmers and anyone using the Gremlin query language to work with graphs. Lots of code examples, sample queries, discussion of best practices, lessons I learned the hard way etc. are included.

Thanks to all those that have encouraged me to keep going with this adventure!

Kelvin R. Lawrence
October 5th, 2017

1.2. Providing feedback

Please let me know about any mistakes you find in this material and also please feel free to send me feedback of any sort. Suggested improvements are especially welcome. A good way to provide feedback is by opening an issue in the GitHub repository located at https://github.com/krlawrence/graph. You are currently reading revision 271 of the document.

1.3. A word of thanks

I would like to thank my colleagues at IBM, Graham Wallis, Jason Plurad and Adam Holley for their help in refining and improving several of the queries contained in this document. Gremlin is definitely a bit of a team sport. We spent many hours over the last many months discussing the best way to handle different types of queries and traversals!

I would also be remiss if I did not give a big shout out to all of the folks that spend a lot of time replying to questions and suggestions on the Gremlin Users Google Group. Special thanks should go to Daniel Kuppitz, Marko Rodriguez and Stephen Mallette, key members of the team that created and maintains Apache TinkerPop.

1.4. What is this book about?

This book introduces the Apache TinkerPop 3 Gremlin graph query and traversal language via real examples featuring a real world graph that is also provided along with sample code and applications. The graph, air-routes.graphml, is a model of the world airline route network between 3,373 airports including 43,400 routes. The examples presented will work unmodified with the air-routes.graphml file loaded into the Gremlin console running with a TinkerGraph. How to set that environment up is covered in the Downloading, installing and launching the console section below.

Note
The examples in this book have now been updated and tested using Apache TinkerPop version 3.3 which introduced a few breaking changes. If you find any I missed please let me know!

TinkerGraph is an in-memory graph, meaning nothing gets saved to disk automatically, that is shipped as part of the Apache TinkerPop 3 download. The goal of this tutorial is to allow someone with little to no prior knowledge to get up and going quickly using the Gremlin console and the 'air-routes’graph. Later in the document we will discuss using additional technologies such as Janus Graph, Apache Cassandra and Apache Elastic Search with Gremlin. We will also discuss writing stand alone Java and Groovy applications as well as using the Gremlin Console.

Note
In the first four sections of this this document we have mainly focussed on showing the different types of query that you can issue using Gremlin. We have not tried to show all of the output that you will get back from entering these queries but have selectively shown examples of output. We go a lot deeper into things in chapters 5 and 6.
How this book is organized
Chapter 1 - INTRODUCTION
  • We start off by briefly doing a recap on why Graph databases are of interest to us and discuss some good use cases for graphs.

Chapter 2 - GETTING STARTED
  • In Chapter two we introduce several of the components of Apache TinkerPop 3 and we also introduce the air-routes.graphml file that will be used as the graph we base most of our examples on.

Chapter 3 - WRITING GREMLIN QUERIES
  • In Chapter three we start discussing how to use the Gremlin graph traversal and query language to interrogate the air-routes graph. We begin by comparing how we could have built the air-routes graph using a more traditional relational database and then look at how SQL and Gremlin are both similar in some ways and very different in others. For the rest of the Chapter, we introduce several of the key Gremlin methods, or as they are often called, "steps". We mostly focus on reading the graph (not adding or deleting things) in this Chapter.

Chapter 4 - BEYOND BASIC QUERIES
  • In Chapter four we move beyond just reading the graph and describe how to add vertices (nodes), edges and properties as well as how to delete and update them. We also present a discussion of various best practices.We also start to explore some slightly more advanced topics in this chapter.

Chapter 5 - MISCELLANEOUS QUERIES AND THE RESULTS THEY GENERATE
  • In Chapter five we focus on using what we have covered in the prior Chapters to write queries that have a more real world feel. We present a lot more examples of the output from running queries in this Chapter. We also start to discuss topics such as analyzing distances, route distribution and writing geospatial queries.

Chapter 6 - MOVING BEYOND THE CONSOLE AND TINKERGRAPH
  • In Chapter six we move beyond our focus on the Gremlin Console and TinkerGraph. We start by looking at how you can write stand alone Java and Groovy applications that can work with a graph. We then introduce Janus Graph and take a fairly detailed look at its capabilities such as support for transactions, schemas and external indexes. We also explore various technology choices for back end persistent store and index as well as introducing the Gremlin Server.

Chapter 7 - COMMON GRAPH SERIALIZATION FORMATS
  • In Chapter seven a discussion is presented of some common Graph serialization file formats along with coverage of how to use them in the context of TinkerPop 3 enabled graphs.

Chapter 8 - FURTHER READING
  • We finish up by providing several links to useful web sites where you can find tools and documentation for many of the technologies covered in this document.

1.5. So what is a graph database and why should I care?

This document is mainly intended to be a tutorial in working with graph databases and related technology using the Gremlin query language. However, it is worth spending just a few moments to summarize why it is important to understand what a graph database is, what some good use cases for graphs are and why you should care in a World that is already full of all kinds of SQL and NoSQL databases. In this document we are going to be discussing directed property graphs. At the conceptual level these types of graphs are quite simple to understand. You have three basic building blocks. Vertices (often referred to as nodes), edges and properties. Vertices represent "things" such as people or places. Edges represent connections between those vertices and properties and information to the vertices and edges as needed. The directed part of the name means that any edge has a direction. It goes out from one vertex and in to another. You will sometimes hear people use the word digraph as shorthand for directed graph. Consider the relationship "Kelvin knows Jack". This could be modeled as a vertex for each of the people and an edge for the relationship as follows.

Kelvin — knows → Jack

Note the arrow which implies the direction of the relationship. If we wanted to record the fact that Jack also admits to knowing Kelvin we would need to add a second edge from Jack to Kelvin. Properties could be added to each person to give more information about them. For example, my age might be a property on my vertex.

It turns out that Jack really likes cats. We might want to store that in our graph as well so we could create the relationship:

Jack — likes → Cats

Now that we have a bit more in our graph we could answer the question "who does Kelvin know that likes cats?"

Kelvin — knows → Jack — likes → Cats

This is a simple example but hopefully you can already see that we are modelling our data the way we think about it in the real world. Armed with this knowledge you now have all of the basic building blocks you need in order to start thinking about how you might model things you are familiar with as a graph.

So getting back to the question "why should I care?", well, if something looks like a graph, then wouldn’t it be great if we could model it that way. Many things in our everyday lives center around things that can very nicely be represented in a graph. Things such as your social and business networks, the route you take to get to work, the phone network, airline route choices for trips you need to take are all great candidates. There are also many great business applications for graph databases and algorithms. These include recommendation systems, crime prevention and fraud detection to name but three.

The reverse is also true. If something does not feel like a graph then don’t try to force it to be. Your videos are probably doing quite nicely living in the object store where you currently have them. A sales ledger system built using a relational database is probably doing just fine where it is and likewise a document store is quite possibly just the right place to be storing your documents. So "use the right tool for the job" remains as valid a phrase here as elsewhere". Where graph databases come into their own is when the data you are storing is intrinsically linked by its very nature, the air routes network used as the basis for all of the examples in this document being a perfect example of such a situation.

Those of you that looked at graphs as part of a computer science course are correct if your reaction was "haven’t graphs been around for ages?". Indeed Leonard Euler is credited with demonstrating the first graph problem and inventing the whole concept of "Graph Theory" all the way back in 1763 when he investigated the now famous "Seven Bridges of Konigsberg" problem.

If you want read a bit more about graph theory and its present day application you can find a lot of good information on-line. Here’s a Wikipedia link to get you started. https://en.wikipedia.org/wiki/Graph_theory

So given Graph Theory is anything but a new idea, why is it that only recently we are seeing a massive growth in the building and deployment of graph database systems and applications? At least part of the answer is that computer hardware and software has reached the point where you can build large big data systems that scale well for a reasonable price. In fact, it’s even easier than ever to build the large systems because you don’t have to buy the hardware that your system will run on when you use the cloud.

While you can certainly run a graph database on your laptop, I do just that every day, the reality is that in production, at scale, they are big data systems. Large graphs commonly have many billions of vertices and edges in them taking up petabytes of data on disk. Graph algorithms can be both compute and memory intensive and it is only fairly recently that deploying the necessary resources for such big data systems has made financial sense for more everyday uses in business and not just in government or academia. Graph databases are becoming much more broadly adopted across the spectrum from high end scientific research to financial networks and beyond.

Another factor that has really helped start this graph database revolution is the availability of high quality open source technology. There are a lot of great open source projects addressing everything from the databases you need to store the graph data to the query languages used to traverse them all the way up to visually displaying graphs as part of the user interface layer. In particular, it is so called property graphs where we are seeing the broadest development and uptake. In a property graph both vertices and edges can have properties (effectively key,value pairs) associated with them. There are many styles of graph that you may end up building and there have been whole books written on these various design patterns but the property graph technology we will be focussed on in this document can support all of the most common usage patterns. If you hear phrases such as directed graph and undirected graph or cyclic and acyclic graph and many more as you work with graph databases a quick on-line search will get you to a place where you can get familiar with that terminology. A deep discussion of these patterns is beyond the scope of this document and it’s in no way essential to have a full background in graph theory to get productive quickly.

A third, and equally important factor, in the growth we are seeing in graph database adoption is the low barrier of entry for programmers. As you will see from the examples in this document, someone wanting to experiment with graph technology can download the Apache TinkerPop package and as long as Java 8 is installed, be up and running with zero configuration, other than doing an unzip of the files, in as little as five minutes. Graph databases do not force you to define schemas or specify the layout of tables and columns before you can get going and start building a graph. Programmers also seem to find the graph style of programming quite intuitive as it closely models the way they think of the world.

Graph database technology should not be viewed as a "rip and replace" technology but as very much complimentary to other databases that you may already have deployed. One common use case is for the graph to be uses as a form of smart index into other data stores. This is sometimes called having a polyglot data architecture.

1.6. A word about terminology

The words node and vertex are synonymous when discussing a graph. Throughout this book you will find both words used. However, as the Apache TinkerPop documentation almost exclusively uses the word vertex, as much as possible when discussing Gremlin queries and other concepts, I will endeavor to stick to the word vertex or the plural form vertices. As this document has evolved I realized my use of these terms had become inconsistent and in future updates I plan to standardize on vertex rather than node to be consistent with the TinkerPop documentation.

2. GETTING STARTED

Let’s take a look at what you will need to have installed and what tools you will need available to make best use of the examples contained in this guide. The key thing that you will need is the Apache TinkerPop project’s Gremlin Console download.

2.1. What is Apache TinkerPop?

Apache TinkerPop is a graph computing framework and top level project hosted by the Apache Software Foundation. The homepage for the project is located at this URL: http://tinkerpop.apache.org/

The project includes the following components:
Gremlin
  • A graph traversal (query) language

Gremlin Console
  • An interactive shell for working with local or remote graphs.

Gremlin Server
  • Allows hosting of graphs remotely via an HTTP/Web Sockets connection.

TinkerGraph
  • A small in-memory graph implementation that is great for learning.

Programming Interfaces
  • A set of programming interfaces written in Java

Documentation
  • A user guide, a tutorial and programming API documentation.

The programming interfaces allow providers of graph databases to build systems that are TinkerPop enabled. Any such databases can be accessed using the Gremlin query language and corresponding API. For most of this document we will be working within the Gremlin console with a local graph. However in Section 6 we will take a look at Gremlin Server and some other TinkerPop 3 enabled environments. Most of Apache Tinkerpop has been developed using Java 8 but there are also bindings available for many other programming languages such as Groovy and Python. Parts of TinkerPop are themselves developed in Groovy, most notably the Gremlin Console. The nice thing about that is that we can use Groovy syntax along with Gremlin when entering queries into the Console or sending them via REST API to a Gremlin Server. All of these topics are covered in detail in this boook.

The queries used as examples in this book have been tested with Apache TinkerPop version 3.3. using the TinkerGraph graph and the Gremlin console as well as some other TinkerPop 3 enabled graph stores.

2.2. The Gremlin console

The Gremlin Console is a fairly standard REPL (Read Execute Print Loop) shell. It is based on the Groovy console and if you have used any of the other console environments such as those found with Scala, Python and Ruby you will feel right at home here. The Console offers a low overhead (you can set it up in seconds) and low barrier of entry way to start to play with graphs on your local computer. The console can actually work with graphs that are running locally or remotely but for the majority of this document we will keep things simple and focus on local graphs.

To follow along with this tutorial you will need to have installed the Gremlin console or have access to a TinkerPop3/Gremlin enabled graph store such as TinkerGraph or Janus Graph.

Regardless of the environment you use, if you work with Apache TinkerPop enabled graphs, the Gremlin console should always be installed on your machine!

2.2.1. Downloading, installing and launching the console

You can download the Gremlin console from the official Apache TinkerPop website:

It only takes a few minutes to get the Gremlin Console installed and running. You just download the ZIP file and unzip it and you are all set. TinkerPop 3 also requires a recent version of Java 8 being installed. I have done all of my testing using Java 8 version 1.8.0_131. The Gremlin Console will not work with versions prior to 1.8.0_45. If you do not have Java 8 installed it is easy to find and download off the Web.

When you start Gremlin you will be presented with a banner/logo and a prompt that will look something like this. Don’t worry about the plugin messages yet we will talk about those a bit later.

$ ./gremlin.sh

         \,,,/
         (o o)
-----oOOo-(3)-oOOo-----
plugin activated: tinkerpop.server
plugin activated: tinkerpop.utilities
plugin activated: tinkerpop.tinkergraph
gremlin>

You can get a list of the available commands by typing :help. Note that all commands to the console itself are prefixed by a colon ":". This enables the console to distinguish them as special and different from actual Gremlin and Groovy commands.

gremlin> :help

For information about Groovy, visit:
    http://groovy-lang.org

Available commands:
  :help       (:h  ) Display this help message
  ?           (:?  ) Alias to: :help
  :exit       (:x  ) Exit the shell
  :quit       (:q  ) Alias to: :exit
  import      (:i  ) Import a class into the namespace
  :display    (:d  ) Display the current buffer
  :clear      (:c  ) Clear the buffer and reset the prompt counter
  :show       (:S  ) Show variables, classes or imports
  :inspect    (:n  ) Inspect a variable or the last result with the GUI object browser
  :purge      (:p  ) Purge variables, classes, imports or preferences
  :edit       (:e  ) Edit the current buffer
  :load       (:l  ) Load a file or URL into the buffer
  .           (:.  ) Alias to: :load
  :save       (:s  ) Save the current buffer to a file
  :record     (:r  ) Record the current session to a file
  :history    (:H  ) Display, manage and recall edit-line history
  :alias      (:a  ) Create an alias
  :register   (:rc ) Register a new command with the shell
  :doc        (:D  ) Open a browser window displaying the doc for the argument
  :set        (:=  ) Set (or list) preferences
  :uninstall  (:-  ) Uninstall a Maven library and its dependencies from the Gremlin Console
  :install    (:+  ) Install a Maven library and its dependencies into the Gremlin Console
  :plugin     (:pin) Manage plugins for the Console
  :remote     (:rem) Define a remote connection
  :submit     (:>  ) Send a Gremlin script to Gremlin Server

For help on a specific command type:
    :help command

It is worth noting that as mentioned above, the Gremlin console is based on the Groovy console and as such you can enter valid Groovy code directly into the console. So as well as using it to experiment with Graphs and Gremlin you can use it as, for example, a desktop calculator should you so desire!

gremlin> 2+3
==>5

gremlin> a = 5
==>5

gremlin> println "The number is ${a}"
The number is 5

gremlin> for (a in 1..5) {print "${a} "};println()
1 2 3 4 5
Note
The Gremlin Console does a very nice job of only showing you a nice and tidy set of query results. If you are working with a graph system that supports TinkerPop 3 but not via the Gremlin console (an example of this would be talking to a Gremlin Server using the HTTP REST API) then what you will get back is going to be a JSON document that you will need to write some code to parse. We will explore that topic much later in this document.

If you want to see lots of examples of the output from running various queries you will find plenty in the "MISCELLANEOUS QUERIES AND THE RESULTS THEY GENERATE" section of this document where we have tried to go into more depth on various topics.

Mostly you will run the Gremlin console in its interactive mode. However you can also pass the name of a file as a command line parameter, preceded by the -e flag and Gremlin will execute the file and exit. For example if you had a file called "mycode.groovy" you could execute it directly from your command line window or terminal window as follows:

$ gremlin -e mycode.groovy

If you wanted to have the console run your script and not exit afterwards, you can use the -i option instead of -e.

You can get help on all of the command line options for the Gremlin console by typing gremlin --help. You should get back some help text that looks like this

$ gremlin --help

usage: gremlin.sh [options] [...]
  -C, --color                               Disable use of ANSI colors
  -D, --debug                               Enabled debug Console output
  -Q, --quiet                               Suppress superfluous Console
                                            output
  -V, --verbose                             Enable verbose Console output
  -e, --execute=SCRIPT ARG1 ARG2 ...        Execute the specified script
                                            (SCRIPT ARG1 ARG2 ...) and
                                            close the console on
                                            completion
  -h, --help                                Display this help message
  -i, --interactive=SCRIPT ARG1 ARG2 ...    Execute the specified script
                                            and leave the console open on
                                            completion
  -l                                        Set the logging level of
                                            components that use standard
                                            logging output independent of
                                            the Console
  -v, --version                             Display the version

If you ever want to check which version of TinkerPop you have installed you can enter the following command from inside the Gremlin console.

// What version of Gremlin am I running?
Gremlin.version()

2.2.2. Saving output from the console to a file

Sometimes it is useful to save part or all of a console session to a file. You can turn recording to a file on and off using the :record command.

In the following example, we turn recording on using :record start mylog.txt which will force all commands entered and their output to be written to the file mylog.txt until the command :record stop is entered. The command g.V().count().next() just counts how many vertices (nodes) are in the graph. We will explain the Gremlin graph traversal and query language in detail starting in the next section.

gremlin> :record start mylog.txt
Recording session to: "mylog.txt"

gremlin> g.V().count().next()
==>3618
gremlin> :record stop
Recording stopped; session saved as: "mylog.txt" (157 bytes)

If we were to look at the mylog.txt file, this is what it now contains.

// OPENED: Tue Sep 12 10:43:40 CDT 2017
// RESULT: mylog.txt
g.V().count().next()
// RESULT: 3618
:record stop
// CLOSED: Tue Sep 12 10:43:50 CDT 2017

For the remainder of this document I am not going to show the gremlin> prompt or the =⇒ output identifier as part of each example, just to reduce clutter a bit. You can assume that each command was entered and tested using the Gremlin console however.

Tip
If you want to learn more about the console itself you can refer to the official TinkerPop documentation and, even better, have a play with the console and the built in help.

2.3. Introducing TinkerGraph

As well as the Gremlin Console, the TinkerPop 3 download includes an implementation of an in-memory graph store called TinkerGraph. This document was mostly developed using TinkerGraph but I also tested everything using Janus Graph. We will introduce Janus Graph later in the "Introducing Janus Graph" section. The nice thing about TinkerGraph is that for learning and testing things you can run everything you need on your laptop or desktop computer and be up and running very quickly. We will explain how to get started with the Gremlin Console and TinkerGraph a bit later in this document.

Tinkerpop 3 defines a number of capabilities that a graph store should support. Some are optional others are not. You can query any TinkerPop 3 enabled graph store to see which features are supported. The following list shows the features supported by TinkerGraph. This is what you would get back should you call the features method provided by TinkerGraph. We have arranged the list in two columns to aid readability. Don’t worry if not all of these terms makes sense right away - we’ll get there soon!

> GraphFeatures                          > VertexPropertyFeatures
>-- ConcurrentAccess: false              >-- UserSuppliedIds: true
>-- ThreadedTransactions: false          >-- StringIds: true
>-- Persistence: true                    >-- RemoveProperty: true
>-- Computer: true                       >-- AddProperty: true
>-- Transactions: false                  >-- NumericIds: true
> VariableFeatures                       >-- CustomIds: false
>-- Variables: true                      >-- AnyIds: true
>-- LongValues: true                     >-- UuidIds: true
>-- SerializableValues: true             >-- Properties: true
>-- FloatArrayValues: true               >-- LongValues: true
>-- UniformListValues: true              >-- SerializableValues: true
>-- ByteArrayValues: true                >-- FloatArrayValues: true
>-- MapValues: true                      >-- UniformListValues: true
>-- BooleanArrayValues: true             >-- ByteArrayValues: true
>-- MixedListValues: true                >-- MapValues: true
>-- BooleanValues: true                  >-- BooleanArrayValues: true
>-- DoubleValues: true                   >-- MixedListValues: true
>-- IntegerArrayValues: true             >-- BooleanValues: true
>-- LongArrayValues: true                >-- DoubleValues: true
>-- StringArrayValues: true              >-- IntegerArrayValues: true
>-- StringValues: true                   >-- LongArrayValues: true
>-- DoubleArrayValues: true              >-- StringArrayValues: true
>-- FloatValues: true                    >-- StringValues: true
>-- IntegerValues: true                  >-- DoubleArrayValues: true
>-- ByteValues: true                     >-- FloatValues: true
> VertexFeatures                         >-- IntegerValues: true
>-- AddVertices: true                    >-- ByteValues: true
>-- DuplicateMultiProperties: true       > EdgePropertyFeatures
>-- MultiProperties: true                >-- Properties: true
>-- RemoveVertices: true                 >-- LongValues: true
>-- MetaProperties: true                 >-- SerializableValues: true
>-- UserSuppliedIds: true                >-- FloatArrayValues: true
>-- StringIds: true                      >-- UniformListValues: true
>-- RemoveProperty: true                 >-- ByteArrayValues: true
>-- AddProperty: true                    >-- MapValues: true
>-- NumericIds: true                     >-- BooleanArrayValues: true
>-- CustomIds: false                     >-- MixedListValues: true
>-- AnyIds: true                         >-- BooleanValues: true
>-- UuidIds: true                        >-- DoubleValues: true
> EdgeFeatures                           >-- IntegerArrayValues: true
>-- RemoveEdges: true                    >-- LongArrayValues: true
>-- AddEdges: true                       >-- StringArrayValues: true
>-- UserSuppliedIds: true                >-- StringValues: true
>-- StringIds: true                      >-- DoubleArrayValues: true
>-- RemoveProperty: true                 >-- FloatValues: true
>-- AddProperty: true                    >-- IntegerValues: true
>-- NumericIds: true                     >-- ByteValues: true
>-- CustomIds: false
>-- AnyIds: true
>-- UuidIds: true

TinkerGraph is really useful while learning to work with Gremlin and great for testing things out. One common use case where TinkerGraph can be very useful is to crate a sub-graph of a larger graph and work with it locally. TinkerGraph can even be used in production deployments if an all in memory graph fits the bill. Typically, TinkerGraph us used to explore static (no changing) graphs but you can use it from a programming language like Java and mutate its contents if you want to. However, TinkerGraph does not support some of the more advanced features you will find in implementations like Janus Graph such as ACID Transactions and external indexes. We will cover these topics as part of our discussion of Janus Graph towards the end of the document. One other thing worth noting in the list above is that UserSuppliedIds is set to true for vertex and edge ID values. This means that if you load a graph file, such as a GraphML format file, that specifies ID values for vertices and edges then TinkerGraph will honor those IDs and use them. As we shall see later this is not the case with most other graph systems.

When running in the Gremlin Console, support for TinkerGraph should be on by default. If for any reason you find it to be off you, can enable it by issuing the following command.

:plugin use tinkerpop.tinkergraph

Once the TinkerGraph plugin is enabled you will need to close and re-load the Gremlin console. After doing that, you can create a new TinkerGraph instance from the console as follows.

graph = TinkerGraph.open()

In many cases you will want to pass parameters to the open method that give more information on how the graph is to be configured. We will explore those options later in the document. Before you can start to issue Gremlin queries against the graph you also need to establish a graph traversal source object by calling the new graph’s traversal method as follows.

g = graph.traversal()
Note
Throughout the remainder of this document we will follow the convention that we will always use the variable name graph for any variable that represents a graph instance and we will always use the variable name g for any variable that represents an instance of a graph traversal source object.

2.4. Introducing the air-routes graph

Along with these notes I have provided what is, in big data terms,a very small, but nonetheless real World, graph that is written in GraphML, a standard XML format for describing graphs that can be used to move graphs between applications. The graph, air-routes.graphml is a model I built of the World airline route network that is fairly accurate. Of course, in the real World, routes are added and deleted by airlines all the time so please don’t use this graph to plan your next vacation or business trip! However, as a learning tool I hope you will find it useful and easy to relate to. If you feel so inclined you can load the file into a text editor and examine how it is laid out. As you work with graphs you will want to become familiar with popular graph serialization formats. Two common ones are GraphML and GraphSON. The latter is a JSON format that is defined by Apache TinkerPop and heavily used in that environment. GraphML is very widely recognized by TinkerPop and many other tools as well such as Gephi, a popular open source tool for visualizing graph data. A lot of graph ingestion algorithms also sill use comma separated values (CSV) format files.

We will briefly look at loading and saving graph data in Sections 2 and 4. We take a much deeper look at different ways to work with graph data stored in text format files including importing and exporting graph data in the "COMMON GRAPH SERIALIZATION FORMATS" section at the end of this document.

The air-routes graph contains several vertex types that are specified using labels. The most common ones being airport and country. There are also vertices for each of the seven continents (continent) and a single version vertex that I provided as a way to test which version of the graph you are using.

Routes between airports are modeled as edges. These edges carry the route label and include the distance between the two connected airport vertices as a property called dist. Connections between countries and airports are modelled using an edge with a contains label.

Each airport vertex has many properties associated with it giving various details about that airport including its IATA and ICAO codes, its description, the city it is in and its geographic location.

Specifically, each airport vertex has a unique ID, a label of airport and contains the following properties. The word in parenthesis indicates the type of the property.

 type    (string) : Vertex type. Will be 'airport' for airport vertices
 code    (string) : The three letter IATA code like AUS or LHR
 icao    (string) : The four letter ICAO code or none. Example KAUS or EGLL
 desc    (string) : A text description of the airport
 region  (string) : The geographical region like US-TX or GB-ENG
 runways (int)    : The number of available runways
 longest (int)    : Length of the longest runway in feet
 elev    (int)    : Elevation in feet above sea level
 country (string) : Two letter ISO country code such as US, FR or DE.
 city    (string) : The name of the city the airport is in
 lat     (double) : Latitude of the airport
 lon     (double) : Longitude of the airport

We can use Gremlin once the air route graph is loaded to show us what properties an airport vertex has. As an example here is what the airport vertex with an ID of 3 looks like. We will explain the steps that make up the Gremlin query shortly.

// Query the properties of vertex 3
g.V(3).valueMap(true).unfold()

id=3
label=airport
type=[airport]
code=[AUS]
icao=[KAUS]
desc=[Austin Bergstrom International Airport]
region=[US-TX]
runways=[2]
longest=[12250]
elev=[542]
country=[US]
city=[Austin]
lat=[30.1944999694824]
lon=[-97.6698989868164]

Even though the airport vertex label is airport I chose to also have a property called type that also contains the string airport. This was done to aid with indexing when working with other graph database systems and is explained in more detail later in this document.

You may have noticed that the values for each property are represented as lists or arrays if you prefer, even though each list only contains one element. The reasons for this will be explored later in this document but the quick explanation is that this is because TinkerPop allows us to associate a list of values with any vertex property. We will explore ways that you can take advantage of this capability in the "Attaching multiple values (lists or sets) to a single property" section.

The full details of all the features contained in the air-routes graph can be learned by reading the comments at the start of the air-routes.graphml file or reading the README.txt file.

The graph currently contains a total of 3,612 vertices and 49,894 edges. Of these 3,367 vertices are airports, and 43,160 of the edges represent routes. While in big data terms this is really a tiny graph, it is plenty big enough for us to build up and experiment with some very interesting Gremlin queries.

Lastly, here is are some statistics and facts about the air-routes graph. If you want to see a lot more statistics check the README.txt file that is included with the air-routes graph.

Air Routes Graph (v0.77, 2017-Oct-06) contains:
  3,374 airports
  43,400 routes
  237 countries (and dependent areas)
  7 continents
  3,619 total nodes
  50,148 total edges

Additional observations:
  Longest route is between DOH and AKL (9,025 miles)
  Shortest route is between WRY and PPW (2 miles)
  Average route distance is 1,164.747 miles.
  Longest runway is 18,045ft (BPX)
  Shortest runway is 1,300ft (SAB)
  Furthest North is LYR (latitude: 78.2461013793945)
  Furthest South is USH (latitude: -54.8433)
  Furthest East is SVU (longitude: 179.341003418)
  Furthest West is TVU (longitude: -179.876998901)
  Closest to the Equator is MDK (latitude: 0.0226000007242)
  Closest to the Greenwich meridian is LDE (longitude: -0.006438999902457)
  Highest elevation is DCY (14,472 feet)
  Lowest elevation is GUW (-72 feet)
  Maximum airport node degree (routes in and out) is 544 (FRA)
  Country with the most airports: United States (579)
  Continent with the most airports: North America (978)
  Average degree (airport nodes) is 25.726
  Average degree (all nodes) is 25.856

Here are the Top 15 airports sorted by overall number of routes (in and out). In graph terminology this is often called the degree of the vertex or just vertex degree.

    POS   ID  CODE  TOTAL     DETAILS

     1    52   FRA  (544)  out:272 in:272
     2    70   AMS  (541)  out:269 in:272
     3   161   IST  (540)  out:270 in:270
     4    51   CDG  (524)  out:262 in:262
     5    80   MUC  (474)  out:237 in:237
     6    64   PEK  (469)  out:234 in:235
     7    18   ORD  (464)  out:232 in:232
     8     1   ATL  (464)  out:232 in:232
     9    58   DXB  (458)  out:229 in:229
    10     8   DFW  (442)  out:221 in:221
    11   102   DME  (428)  out:214 in:214
    12    67   PVG  (402)  out:201 in:201
    13    50   LGW  (400)  out:200 in:200
    14    13   LAX  (390)  out:195 in:195
    15    74   MAD  (384)  out:192 in:192

Throughout this document you will find the Gremlin queries that can be used to generate many of these statistics.

2.5. TinkerPop 3 migration notes

There are still a large number of examples on the internet that show the TinkerPop 2 way of doing things. Quite a lot of things changed between TinkerPop 2 and TinkerPop 3. If you were an early adopter and are coming from a TinkerPop 2 environment to a TinkerPop 3 environment you may find some of the tips in this section helpful. As we we will explain below, using the sugar plugin will make the migration from TinkerPop 2 easier but it is recommended to learn the full TinkerPop 3 Gremlin syntax and get used to using that as soon as possible. Using the full syntax will make your queries a lot more portable to other TinkerPop 3 enabled graph systems.

TinkerPop 3 requires a minimum of Java 8 v45. It will not run on earlier versions of Java 8 based on my testing.

2.5.1. Creating a TinkerGraph TP2 vs TP3

The way that you create a TinkerGraph changed between TinkerPop 2 and 3.

graph = new TinkerGraph()  // TinkerPop 2
graph = TinkerGraph.open() // TinkerPop 3

2.5.2. Loading a graphML file TP2 vs TP3

If you have previous experience with TinkerPop 2 you may also have noticed that the way a graph is loaded has changed in TinkerPop 3.

graph.loadGraphML('air-routes.graphml') // TinkerPop 2
graph.io(graphml()).readGraph('air-routes.graphml') // TinkerPop 3

The Gremlin language itself changed quite a bit between TinkerPop 2 and TinkerPop 3. The remainder of this document only shows TinkerPop 3 examples.

2.5.3. A word about the TinkerPop.sugar plugin

The Gremlin console has a set of plug in modules that can be independently enabled or disabled. Depending upon your use case you may or may not need to manage plugins.

TinkerPop 2 supported by default some syntactic sugar that allowed shorthand forms of queries to be entered when using the Gremlin console. In TinkerPop 3 that support has been moved to a plugin and is off by default. It has to be enabled if you want to continue to use the same shortcuts that TinkerPop 2 allowed by default.

You can enable sugar support from the Gremlin console as follows:

:plugin use tinkerpop.sugar
Tip
The Gremlin Console remembers which plugins are enabled between restarts.

In the current revision of this document I have tried to remove any dependence on the TinkerPop.sugar plugin from the examples presented. By not using Sugar, queries shown in this document should port very easily to other TinkerPop 3 enabled graph platforms. A few of the queries may not work on versions of TinkerPop prior to 3.2 as TinkerPop continues to evolve and new features are being added fairly regularly.

The Tinkerpop.sugar plugin allows some queries to be expressed in a more shorthand or lazy form, often leaving out references to values() and leaving out parenthesis. For example:

// With Sugar enabled
g.V.hasLabel('airport').code

// Without Sugar enabled
g.V().hasLabel('airport').values('code')

People Migrating from TinkerPop 2 will find the Sugar plugin helps get your existing queries running more easily but as a general rule it is recommended to become familiar with the longhand way of writing queries as that will enable your queries to run as efficiently as possible on graph stores that support TinkerPop 3. Also, due to changes introduced with TinkerPop 3, using sugar will not be as performant as using the normal Gremlin syntax.

Note
In earlier versions of this document many of the examples showed the sugar form. In the current revision I have tried to remove all use of that form. It’s possible that I may have missed a few and I will continue to check for, and fix, any that got missed. Please let me know if you find any that slipped through the net!

2.6. Loading the air-routes graph using the Gremlin console

Here is some code you can load the air routes graph using the gremlin console by putting it into a file and using :load to load and run it or by entering each line into the console manually. These commands will setup the console environment, create a TinkerGraph graph and load the air-routes.graphml file into it. Some extra console features are also enabled.

These commands create an in-memory TinkerGraph which will use LONG values for the vertex and edge IDs. TinkerPop 3 introduced the concept of a traversal so as part of loading a graph we also setup a graph traversal source called g which we will then refer to in our subsequent queries of the graph. The max-iteration option tells the Gremlin console the maximum number of lines of output that we ever want to see in return from a query. The default, if this is not specified, is 100.

Tip
You can use the max-iteration setting to control how much output the Gremlin Console displays.

If you are using a different graph environment, if GraphML import is supported, you can still load the air-routes.graphml file by following the instructions specific to that system. Once loaded, the queries below should still work either unchanged or with minor modifications.

conf = new BaseConfiguration()
conf.setProperty("gremlin.tinkergraph.vertexIdManager","LONG")
conf.setProperty("gremlin.tinkergraph.edgeIdManager","LONG")
graph = TinkerGraph.open(conf)
graph.io(graphml()).readGraph('air-routes.graphml')
g=graph.traversal()
:set max-iteration 1000
Note
Setting the ID manager as shown above is important. If you do not do this, by default, when using TinkerGraph, ID values will have to be specified as strings such as "3" rather than just the numeral 3.

If you put the commands given above into a file called something like mygremlin-setup, once the console is up and running you can load that file by entering the command below. Doing this will save you a fair bit of time as each time you restart the console you can just reload your configuration file and the environment will be configured and the graph loaded and you can get straight to writing queries.

:load mygremlin-setup
Note
As a best practice you should use the full path to the location where the GraphML file resides if at all possible to make sure that the GraphML reading code can find it.

Once you have the Gremlin Console up and running and have the graph loaded, if you feel like it you can cut and paste queries from this document directly into the console to see them run.

Once the air-routes graph is loaded you can enter the following command and you will get back information about the graph. In the case of a TinkerGraph you will get back a useful message telling you how many vertices and edges the graph contains. Note that the contents of this message will vary from one graph system to another and should not be relied upon as a way to keep tack of vertex and edge counts. We will look at some other ways of doing that later in the document.

// Tell me something about my graph
graph.toString()

When using TinkerGraph, the message you get back will look something like this.

tinkergraph[vertices:3610 edges:49490]

2.7. Turning off some of the Gremlin console’s output

Sometimes, especially when assigning a result to a variable and you are not interested in seeing all the steps that Gremlin took to get there, the Gremlin console displays more output than is desirable. An easy way to prevent this is to just add an empty list ";[]" to the end of your query as follows.

a=g.V().has('code','AUS').out().toList();[]

2.8. A word about indexes and schemas

Some graph implementations such as IBM-Graph have strict requirements on the use of an index. This means that a schema and an index must be in place before you can work with a graph and that you can only begin a traversal by referencing a property in the graph that is included in the index. While that is beyond the scope of this document, it should be pointed out that some of the queries included in this material will not work on any graph system that requires all queries to be backed by an index and does not allow what are sometimes called full graph searches for cases where a particular item in a graph is not backed by an index. One example of this is vertex and edge labels which are typically not indexed but are sometimes very useful items to specify at the start of a query. As the examples in this document are intended to work just fine with a only basic TinkerGraph the subject of indexes is not covered in more detail until Section 6 "MOVING BEYOND THE CONSOLE AND TINKERGRAPH" where we will take a look at some other technologies such as Janus Graph and we do discuss indexing as part of that coverage. You should always refer to the specific documentation for the graph system you are using to decide what you need to do about creating an index and schema for your graph. We will explain what TinkerGraph is in the next section.

In general for any graph, regardless of whether it is optional or not, use of an index should be considered a best practice. Even TinkerGraph has a way to create an index should you want to.

Note
In production systems, especially those where the graphs are large, the task of creating and managing the index is often handed to an additional software component such as Apache Solr or Apache Elastic Search.

3. WRITING GREMLIN QUERIES

Now that you hopefully have the air-routes graph loaded it’s time to start writing some queries!

In this section we will begin to look at the Gremlin query language. We will start off with a quick look at how Gremlin and SQL differ and are yet in some ways similar, then we will look at some fairly basic queries and finally get into some more advanced concepts. Hopefully each set of examples presented by building upon things previously discussed will be easy to understand.

3.1. Introducing Gremlin

Gremlin is the name of the graph traversal and query language that TinkerPop provides for working with property graphs. Gremlin can be used with any graph store that is Apache TinkerPop enabled. Gremlin is a fairly imperative language but also has some more declarative constructs as well. Using Gremlin we can traverse a graph looking for values, patterns and relationships we can add or delete vertices and edges, we can create sub-graphs and lots more.

3.1.1. A quick look at Gremlin and SQL

While it is not required to know SQL in order to be productive with Gremlin, if you do have some experience with SQL you will notice many of the same keywords and phrases being used in Gremlin. As a simple example the SQL and Gremlin examples below both show how we might count the number of airports there are in each country using firstly a relational database and secondly a property graph.

When working with a relational database, we might decide to store all of the airport data in a single table called airports. In a very simple case (the air routes graph actually stores a lot more data than this about each airport) we could setup our airports table so that it had entries for each airport as follows.

ID   CODE  ICAO  CITY             COUNTRY
---  ----  ----  ---------------  ----------
1    ATL   KATL  Atlanta          US
3    AUS   KAUS  Austin           US
8    DFW   KDFW  Dallas           US
47   YYZ   CYYZ  Toronto          CA
49   LHR   EGLL  London           UK
51   CDG   LFPG  Paris            FR
52   FRA   EDDF  Frankfurt        DE
55   SYD   YSSY  Sydney           AU

We could then use a SQL query to count the distribution of airports in each country as follows.

select country,count(country) from airports group by country;

We can do this in Gremlin using the air-routes graph with a query like the one below (we will explain what all of this means later on in the document).

g.V().hasLabel('airport').groupCount().by('country')

You will discover that Gremlin provides its own flavor of several constructs that you will be familiar with if you have used SQL before, but again, prior knowledge of SQL is in no way required to learn Gremlin.

One thing you will not find when working with a graph using Gremlin is the concept of a SQL join. Graph databases by their very nature avoid the need to join things together (as things that need to be connected already are connected) and this is a core reason why, for many use cases, Graph databases are a very good choice and can be more performant than relational databases.

Graph databases are usually a good choice for storing and modelling networks. The air-routes graph is an example of a network graph a social network is of course another good example. Networks can be modelled using relational databases too but as you explore the network and ask questions like "who are my friends' friends?" in a social network or "where can I fly to from here with a maximum of two stops?" things rapidly get complicated and result in the need for multiple joins.

As an example, imagine adding a second table to our relational database called routes. It will contain three columns representing the source airport, the destination airport and the distance between them in miles (SRC,DEST and DIST). It would contain entries that looked like this (the real table would of course have thousands of rows but this gives a good idea of what the table would look like).

SRC  DEST  DIST
---  ----  ----
ATL  DFW   729
ATL  FRA   4600
AUS  DFW   190
AUS  LHR   4901
BOM  AGR   644
BOM  LHR   4479
CDG  DFW   4933
CDG  FRA   278
CDG  LHR   216
DFW  FRA   5127
DFW  LHR   4736
LHR  BOM   4479
LHR  FRA   406
YYZ  FRA   3938
YYZ  LHR   3544

If we wanted to write a SQL query to calculate the ways of travelling from Austin (AUS) to Agra (AGR) with two stops, we would end up writing a query that looked something like this:

select a1.code,r1.dest,r2.dest,r3.dest from airports a1
  join routes r1 on a1.code=r1.src
  join routes r2 on r1.dest=r2.src
  join routes r3 on r2.dest=r3.src
  where a1.code='AUS' and r3.dest='AGR';

Using our air-routes graph database the query can be expressed quite simply as follows:

g.V().has('code','AUS').out().out().out().has('code','AGR').path().by('code')

Adding or removing hops is as simple as adding or removing one or more of the out() steps which is a lot simpler than having to add additional join clauses to our SQL query. This is a simple example, but as queries get more and more complicated in heavily connected data sets like networks, the SQL queries get harder and harder to write whereas, because Gremlin is designed for working with this type of data, expressing a traversal remains fairly straightforward.

We can go one step further with Gremlin and use repeat to express the concept of three times as follows.

g.V().has('code','AUS').repeat(out()).times(3).has('code','AGR').path().by('code')

Gremlin also has a repeat …​ until construct that we will see used later in this document. When combined with the emit step, repeat provides a nice way of getting back any routes between a source and destination no matter how many hops it might take to get there.

Again, don’t worry if some of the Gremlin steps shown here are confusing, we will cover them all in detail a bit later. The key point to take away from this discussion of SQL and Gremlin is that for data that is very connected, Graph databases provide a very good way to store that data and Gremlin provides a nice and fairly intuitive way to traverse that data efficiently.

One other point worthy of note is that every vertex and every edge in a graph has a unique ID. Unlike in the relational world where you may or may not decide to give a table an ID column this is not optional with graph databases. In some cases the ID can be a user provided ID but more commonly it will be generated by the graph system when a vertex or edge is first created. If you are familiar with SQL, you can think of the ID as a primary key of sorts if you want to. Every vertex and ID can be accessed using it’s ID. Just as with relational databases, graph databases can be indexed and any of the properties contained in a vertex or an edge can be added to the index and can be used to find things efficiently. In large graph deployments this greatly speeds up the process of finding things as you would expect. We look more closely at IDs in the Working with IDs section.

3.2. Some fairly basic Gremlin queries

A graph query is often referred to as a traversal as that is what we are in fact doing. We are traversing the graph from a starting point to an ending point. Traversals consist of one or more steps (essentially methods) that are chained together.

As we start to look at some simple traversals here are a few steps that you will see used a lot. Firstly, you will notice that almost all traversals start with either a g.V() or a g.E(). Sometimes there will be parameters specified along with those steps but we will get into that a little later. You may remember from when we looked at how to load the air-routes graph in Section 2 we used the following instruction to create a graph traversal source object for our loaded graph.

g = graph.traversal()

Once we have a graph traversal source object we can use it to start exploring the graph. The V step returns vertices and the E step returns edges. You can also use a V step in the middle of a traversal as well as at the start but we will examine those uses a little later. The V and E steps can also take parameters indicating which set of vertices or edges we are interested in. That usage is explained in the "Working with IDs" section.

Tip
If it helps with remembering you can think of g.V() as meaning "looking at all of the vertices in the graph" and g.E() as meaning "looking at all of the edges in the graph". We then add additional steps to narrow down our search criteria.

The other steps we need to introduce are the has and hasLabel steps. They can be used to test for a certain label or property having a certain value. We will introduce a lot of different Gremlin steps as we build up our Gremlin examples throughout this document, including may other forms of the has step, but these few are enough to get us started.

You can refer to the official Apache TinkerPop documentation for full details on all of the graph traversal steps that are used in this tutorial. With this tutorial I have not tried to teach every possible usage of every Gremlin step and method, rather, I have tried to provide a good and approachable foundation in writing many different types of Gremlin query using an interesting and real world graph.

Note
The latest TinkerPop 3 documentation is always available at this URL: http://tinkerpop.apache.org/docs/current/reference/

Below are some simple queries against the air-routes graph to get us started. It is assumed that the air-routes graph has been loaded already per the instructions above. The query below will return any vertices (nodes) that have the airport label.

// Find vertices that are airports
g.V().hasLabel('airport')

This query will return the vertex that represents the Dallas Fort Worth (DFW) airport.

// Find the DFW vertex
g.V().has('code','DFW')

The next two queries combine the previous two into a single query. The first one just chains the queries together. The second shows a form of the has step that we have not looked at before that takes an additional label value as its first parameter.

// Combining those two previous queries (two ways that are equivalent)
g.V().hasLabel('airport').has('code','DFW')

g.V().has('airport','code','DFW')

Here is what we get back from the query. Notice that this is the Gremlin Console’s way of telling us we got back the Vertex with an ID of 8.

v[8]

So, what we actually got back from these queries was a TinkerPop Vertex data structure. Later in this document we will look at ways to store that value into a variable for additional processing. Remember that even though we are working with a Groovy environment while inside the Gremlin Console, everything we are working with here, at its core, is Java code. So we can use the getClass method from Java to introspect the object. Note the call to next which turns the result of the traversal into an object we can work with. The next step is one of a series of steps that the Tinkerpop documentation describes as terminal steps. We will see more of these terminal steps in use throughout this document.

g.V().has('airport','code','DFW').next().getClass()

class org.apache.tinkerpop.gremlin.tinkergraph.structure.TinkerVertex

We could even add a call to getMethods() at the end of the query above to get back a list of all the methods and their types supported by the TinkerVertex class.

3.2.1. Retrieving property values from a vertex

There are several different ways of working with vertex properties. We can add, delete and query properties for any vertex or edge in the graph. We will explore each of these topics in detail over the course of this document. Initially, let’s look at a couple of simple ways that we can look up the property values of a given vertex.

// What property values are stored in the DFW vertex?
g.V().has('airport','code','DFW').values()

Here is the output that the query returns. Note that we just get back the values of the properties when using the values step, we do not get back the associated keys. We will see how to do that later in the document.

US
DFW
13401
Dallas
607
KDFW
-97.0380020141602
airport
US-TX
7
32.896800994873
Dallas/Fort Worth International Airport

The values step can take parameters that tell it to only returned the values for the provided key names. The queries below return the values of some specific properties.

// Return just the city name property
g.V().has('airport','code','DFW').values('city')

Dallas

// Return the 'runways' and 'icao' property values.
g.V().has('airport','code','DFW').values('runways','icao')

KDFW
7

3.2.2. Does a specific property exist on a given vertex or edge?

You can simply test to see if a property exists as well as testing for it containing a specific value. To do this we can just provide has with the name of the property we are interested in. This works equally well for both vertex and edge properties.

// Find all edges that have a 'dist' property
g.E().has('dist')

// Find all vertices that have a 'region' property
g.V().has('region')

// Find all the vertices that do not have a 'region' property
g.V().hasNot('region')

// The above is shorthand for
 g.V().not(has('region'))

3.2.3. Counting things

A common need when working with graphs is to be able to count how "many of something" there are in the graph. We will look in the next section at other ways to count groups of things but first of all let’s look at some examples of using the count step to count how many of various things there are in our air-routes graph. First of all lets find out how many vertices in the graph represent airports.

// How many airports are there in the graph?
g.V().hasLabel('airport').count()

3374

Now, looking at edges that have a route label, let’s find out how many flight routes are stored in the graph.

// How many routes are there?
g.V().hasLabel('airport').outE('route').count()

43400

You could shorten the above a little as follows but this would cause more edges to get looked as as we do not first filter out all vertices that are not airports.

// How many routes are there?
g.V().outE('route').count()

43400

You could also do it this way but generally starting by looking at all the Edges in the graph is considered bad form as property graphs tend to have a lot more edges than vertices.

// How many routes are there?
g.E().hasLabel('route').count()

43400

We have not yet looked at the outE step used above. We will look at it very soon however in the "Starting to walk the graph" section.

3.2.4. Counting groups of things

Sometimes it is useful to count how many of each type (or group) of things there are in the graph. This can be done using the group and groupCount steps. While for a very large graph it is not recommended to run queries that look at all of the vertices or all of the edges in a graph, for smaller graphs this can be quite useful. For the air routes graph we could easily count the number of different vertex and edge types in the graph as follows.

// How many of each type of vertex are there?
g.V().groupCount().by(label)

If we were to run the query we would get back a map where the keys are label names and the values are the counts for the occurrence of each label in the graph.

[continent:7,country:237,version:1,airport:3374]

There are other ways we could write the query above that will yield the same result. One such example is shown below.

// How many of each type of vertex are there?
g.V().label().groupCount()

[continent:7,country:237,version:1,airport:3374]

We can also run a similar query to find out the distribution of edge labels in the graph. An example of the type of result we would get back is also shown.

// How many of each type of edge are there?
g.E().groupCount().by(label)

[contains:6748,route:43400]

As before we could rewrite the query as follows.

// How many of each type of edge are there?
g.E().label().groupCount()

[contains:6748,route:43400

By way of a side note, the examples above are shorthand ways of writing something like this example which also counts vertices by label.

// As above but using group()
g.V().group().by(label).by(count())

[continent:7,country:237,version:1,airport:3374]

We can be more selective in how we specify the groups of things that we want to count. In the examples below we first count how many airports there are in each country. This will return a map of key:value pairs where the key is the country code and the value is the number of airports in that country. As the fourth and fifth examples show, we can use select to pick just a few values from the whole group that got counted. Of course if we only wanted a single value we could just count the airports connected to that country directly but the last two examples are intended to show that you can count a group of things and still selectively only look at part of that group.

// How many airports are there in each country?
g.V().hasLabel('airport').groupCount().by('country')

// How many airports are there in each country? (look at country first)
g.V().hasLabel('country').group().by('code').by(out().count())

We can easily find out how many airports there are in each continent using group to build a map of continent codes and the number of airports in that continent. The output from running the query is shown below also.

// How many airports are there in each continent?
g.V().hasLabel('continent').group().by('code').by(out().count())

[EU:583,AS:932,NA:978,OC:284,AF:294,AN:0,SA:303]

These queries show how select can be used to extract specific values from the map that we have created. Again you can see the results we get from running the query.

// How many airports in there in France (having first counted all countries)
g.V().hasLabel('airport').groupCount().by('country').select('FR')

59

// How many airports are there in France, Greece and Belgium respectively?
g.V().hasLabel('airport').groupCount().by('country').select('FR','GR','BE')

[FR:58,GR:39,BE:5]

The group and groupCount steps are very useful when you want to count groups of things or collect things into group using a selection criteria. You will find a lot more examples of grouping and counting things in the section called "Counting more things".

3.2.5. Starting to walk the graph

So far we have mostly just explored queries that look at properties on a vertex or count how many things we can find of a certain type. Where the power of a graph really comes into play is when we start to walk or traverse the graph by looking at the connections (edges) between vertices. The term walking the graph is used to describe moving from one vertex to another vertex via an edge. Typically when using the phrase walking a graph the intent is to describe starting at a vertex traversing one or more vertices and edges and ending up at a different vertex or sometimes, back where you started in the case of a circular walk. It is very easy to traverse a graph in this way using Gremlin. The journey we took while on our walk is often referred to as our path. There are also cases when all you want to do is return edges or some combination of vertices and edges as the result of a query and Gremlin allows this as well. We will explore a lot of ways to modify the way a graph is traversed in the upcoming sections. To get us started, here are some simple examples.

The out step is used to find vertices connected by an outgoing edge to that vertex and the outE step is used to explore outgoing edges from a given vertex. Conversely the in and inE steps can be used to look for incoming vertices and edges. The outE and inE steps are especially useful when you want to look at the properties of an edge. There are several other steps that we can use when traversing a graph to move between vertices and edges. We will encounter those in the "Other ways to explore vertices and edges using both, bothE, bothV and otherV" section of this document.

This first query does a few interesting things. Firstly we find the vertex representing the Austin airport (the airport with a property of code containing the value AUS). Having found that vertex we then go out from there. This will find all of the vertices connected to Austin by an outgoing edge. Having found those airports we then ask for the values of their code properties using the values step. Finally the fold step puts all of the results into a list for us. This just makes it easier for us to inspect the results in the console.

// Where can I fly to from Austin?
g.V().has('airport','code','AUS').out().values('code').fold()

Here is what you might get back if you were to run this query in your console.

[YYZ, LHR, FRA, MEX, PIT, PDX, CLT, CUN, MEM, CVG, IND, MCI, DAL, STL, ABQ, MDW, LBB, HRL, GDL, PNS, VPS, SFB, BKG, PIE, ATL, BNA, BOS, BWI, DCA, DFW, FLL, IAD, IAH, JFK, LAX, MCO, MIA, MSP, ORD, PHX, RDU, SEA, SFO, SJC, TPA, SAN, LGB, SNA, SLC, LAS, DEN, MSY, EWR, HOU, ELP, CLE, OAK, PHL, DTW]

All edges in a graph have a label. However, one thing we did not do in the previous query was specify a label for the out step. If you do not specify a label you will get back any connected vertex regardless of its edge label. In this case it does not cause us a problem as airports only have one type of outgoing edge, labeled route. However, in many cases in graphs you create or are working with your vertices may be connected to other vertices by edges with edges with differing labels so it is good practice to get into the habit of specifying edge labels as part of your gremlin queries. So we could change our query just a bit by adding a label reference on the out step as follows.

// Where can I fly to from Austin?
g.V().has('airport','code','AUS').out('route').values('code').fold()

Despite having just stated consistently referencing labels is a good idea, unless you truly do want to get back all edges or all connected vertices, I will break my own rule quite a bit in this document. The reason for this is purely to save space and make the queries I present shorter.

Here are a few more simple queries similar to the previous one.

// Where can I fly to from Austin, with one stop on the way?
// Note that, as written, coming back to Austin will be included
// in the results as this query does not rule it out!
g.V().has('airport','code','AUS').out('route').out('route').values('code')

// What routes come in to LCY?
g.V().has('airport','code','LCY').in('route').values('code')

// Flights from London Heathrow (LHR) to airports in the USA
g.V().has('code','LHR').out('route').has('country','US').values('code')

3.2.6. What vertices and edges did I visit? - Introducing path

A Gremlin method (often called a step) that you will see used a lot in this document is path. After you have done some graph walking using a query you can use path to get a summary back of where you went. Here is a simple example of path being used. Throughout the document you will see numerous examples of path being used including in conjunction with by to specify how the path should be formatted. This particular query will return the vertices and outgoing edges starting at the LCY airport vertex. You can read this query like this: "Start at the LCY vertex, find all outgoing edges and also find all of the vertices that are on the other ends of those edges".

// This time, for each route, return both vertices and the edge that connects them.
g.V().has('airport','code','LCY').outE().inV().path()

If you run that query as-is you will get back a series of results that look like this. This shows that there is a route from vertex 88 to vertex 77 via an edge with an ID of 13208.

[v[88],e[13208][88-route->77],v[77]]

While this is useful, we might want to return something more human readable such as the IATA codes for each airport and perhaps the distance property from the edge that tells us how far apart the airports are. We could add some by modulators to our query to do this. Take a look at the modified query and an example of the results that it will now return. The by modulators are processed in a round robin fashion. So even though there are three values we want to have formatted, we only need to specify two by modulators as both the first and third values are the same. If all three were different, say for example that the third value was a different property like a city name then we would have to provide an explicit by modulator for it. If this is not fully clear yet don’t panic. Both path and by are used a lot throughout this document.

g.V().has('airport','code','LCY').outE().inV().path().by('code').by('dist')

When you run this modified version of the query, you will receive a set of results that look like the following line.

[LCY,468,GVA]

Note that the example above is equivalent to this longer form of the same query. The by modulator steps that follow a path are applied in a round robin fashion. So if there are not enough specified for the number of steps in the path, it just loops back around to the first by step and so on.

g.V().has('airport','code','LCY').outE().inV().path().by('code').by('dist').by('code')

There are a few things to be aware of when using path. Those concerns are explained in the A warning that path can be memory and CPU intensive section a bit later.

3.2.7. Does an edge exist between two vertices?

You can use the hasNext step to check if an edge exists between two vertices and get a Boolean (true or false) value back. The first query below will return true because there is an edge (a route) between AUS and DFW. The second query will return false because there is no route between AUS and SYD.

g.V().has('code','AUS').out('route').has('code','DFW').hasNext()

true

g.V().has('code','AUS').out('route').has('code','SYD').hasNext()

false

3.2.8. Limiting the amount of data returned

It is sometimes useful, especially when dealing with large graphs, to limit the amount of data that is returned from a query. As shown in the examples below, this can be done using the limit and tail steps. A little later in this document we also introduce the coin step that allows a pseudo random sample of the data to be returned.

// Only return the FIRST 20 results
g.V().hasLabel('airport').values('code').limit(20)

// Only return the LAST 20 results
g.V().hasLabel('airport').values('code').tail(20)

Depending upon the implementation, it is probably more efficient to write the query like this, with limit coming before values to guarantee less airports are initially returned but it is also possible that an implementation would optimize both the same way.

// Only return the FIRST 20 results
g.V().hasLabel('airport').limit(20).values('code')

Note that limit provides a shorthand alternative to range. The first of the two examples above could have been written as follows.

// Only return the FIRST 20 results
g.V().hasLabel('airport').range(0,20).values('code')

We can also limit based on time taken. The following query has a maximum limit of ten milliseconds. All of the parts of this query are explained in detail later on in this document but I think what they do is fairly clear.

// Limit the query to however much can be processed within 10 milliseconds
g.V().has('airport','code','AUS')
     .repeat(timeLimit(10).out()).until(has('code','LHR')).path().by('code')

3.2.9. Retrieving a range of vertices

Gremlin provides various ways to return a sequence of vertices. We have already seen the limit and range steps used in the previous section to return the first 20 elements of a query result. We can also use the range step to select different range of vertices by giving a non zero starting offset and an ending offset. The range offsets are zero based, and while the official documentation states that the ranges are inclusive/inclusive it actually appears from my testing that they are inclusive/exclusive.

// Return the first two airport vertices found
g.V().hasLabel('airport').range(0,2)

// Return the fourth, fifth and sixth airport vertices found (zero based)
g.V().hasLabel('airport').range(3,6)

// Return all the remaining vertices starting at the 3500th one
g.V().range(3500,-1)
Note
There is no guarantee as to which airport vertices will be selected as this depends upon how they are stored by the back end graph. Using Tinkergraph the airports will most likely come back in the order they are put into the graph. This is not likely to be the case with other graph stores such as Titan and IBM Graph. So do not rely on any sort of expectation of order when using range to process sets of vertices.

There are many other ways to specify a range of values using Gremlin. You will find several additional examples in the "Testing values and ranges of values" section.

3.2.10. Using as, select and project to name and refer back to prior steps

Sometimes it is useful to be able to remember a point of a traversal and refer back to it later on. This ability was more essential in TinkerPop 2 than it is in TinkerPop 3 but it still has many uses.

g.V().has('code','DFW').as('from').out().has('region','US-CA').as('to').
      select('from','to').by('code')

This query, while a bit contrived, and in reality a poor substitute for using path returns the following results.

[from:DFW,to:LAX]
[from:DFW,to:ONT]
[from:DFW,to:PSP]
[from:DFW,to:SFO]
[from:DFW,to:SJC]
[from:DFW,to:SAN]
[from:DFW,to:SNA]
[from:DFW,to:OAK]
[from:DFW,to:SMF]
[from:DFW,to:FAT]
[from:DFW,to:SBA]

While the prior example was perhaps not ideal, it does show how as and select work. For completeness, here is the same query but using path.

g.V().has('code','DFW').out().has('region','US-CA').path().by('code')

Which would produce the following results.

[DFW,LAX]
[DFW,ONT]
[DFW,PSP]
[DFW,SFO]
[DFW,SJC]
[DFW,SAN]
[DFW,SNA]
[DFW,OAK]
[DFW,SMF]
[DFW,FAT]
[DFW,SBA]

You can also give a point of a traversal multiple names and refer to each later on in the traversal/query.

g.V().has('type','airport').limit(10).as('a','b','c').
      select('a','b','c').by('code').by('region').by(out().count())

In the most recent releases of TinkerPop you can also use the new project step and achieve the same results that you can get from the combination of as and select steps. The example below shows the previous query, rewritten to use project instead of as and select.

g.V().has('type','airport').limit(10).project('a','b','c').
      by('code').by('region').by(out().count())

This query, and the prior query, would return the following results.

[a:ATL,b:US-GA,c:232]
[a:ANC,b:US-AK,c:39]
[a:AUS,b:US-TX,c:59]
[a:BNA,b:US-TN,c:55]
[a:BOS,b:US-MA,c:129]
[a:BWI,b:US-MD,c:89]
[a:DCA,b:US-DC,c:93]
[a:DFW,b:US-TX,c:221]
[a:FLL,b:US-FL,c:141]
[a:IAD,b:US-VA,c:136]

In the prior example we gave our variables simple names like a and b. However, it is sometimes useful to give our traversal variables more meaningful names and it is perfectly OK to do that. Let’s rewrite the query to use some more descriptive variable names.

 g.V().has('type','airport').limit(10).project('IATA','Region','Routes').
      by('code').by('region').by(out().count())

When we run the modified query, here is the output we get.

[IATA:ATL,Region:US-GA,Routes:232]
[IATA:ANC,Region:US-AK,Routes:39]
[IATA:AUS,Region:US-TX,Routes:59]
[IATA:BNA,Region:US-TN,Routes:55]
[IATA:BOS,Region:US-MA,Routes:129]
[IATA:BWI,Region:US-MD,Routes:89]
[IATA:DCA,Region:US-DC,Routes:93]
[IATA:DFW,Region:US-TX,Routes:221]
[IATA:FLL,Region:US-FL,Routes:141]
[IATA:IAD,Region:US-VA,Routes:136]

3.3. Using valueMap to explore the properties of a vertex or element

A call to valueMap will return all of the properties of a vertex or element as an array of key:value pairs. Basically a hash map. You can also select which properties you want valueMap to return if you do not want them all. Each element in the map can be addressed using the name of the key. By default the ID and label are not included in the map unless a parameter of true is provided.

The query below will return the keys and values for all properties associated with the Austin airport vertex.

// Return all the properties and values the AUS vertex has
g.V().has('code','AUS').valueMap()

If you are using the Gremlin console, the output from running the previous command should look something like this.

[country:[US], code:[AUS], longest:[12248], city:[Austin], elev:[542], icao:[KAUS], lon:[-97.6698989868164], type:[airport], region:[US-TX], runways:[2], lat:[30.1944999694824], desc:[Austin Bergstrom International Airport]]
Note
Notice how each key like country is followed by a value that is returned as an element of a list. This is because it is possible (for vertices but not for edges) to provide more than one property value for a given key by encoding them as a list.

Here are some more examples of how valueMap can be used. If a parameter of true is provided, then the results returned will include the ID and label of the element being examined.

// If you also want the ID and label, add a parameter of true
g.V().has('code','AUS').valueMap(true)

[country:[US],id:3,code:[AUS],longest:[12250],city:[Austin],lon:[-97.6698989868164],type:[airport],elev:[542],icao:[KAUS],region:[US-TX],runways:[2],label:airport,lat:[30.1944999694824],desc:[Austin Bergstrom International Airport]]

You can also mix use of true along with requesting the map for specific properties. The next example will just return the ID, label and region property.

// If you want the ID, label and a specific field like the region, you can do this
g.V().has('code','AUS').valueMap(true,'region')

[id:3,region:[US-TX],label:airport]
Tip
If you only need the keys and values for specific properties to be returned it is recommended to pass the names of those properties as parameters to the valueMap step so it does not return a lot more data than you need. Think of this as the difference, in the SQL World, between selecting just the columns you are interested in from a table rather than doing a SELECT *.

As shown above, you can specify which properties you want returned by supplying their names as parameters to the valueMap step. For completeness, it is worth noting that you can also use a select step to refine the results of a valueMap.

// You can 'select' specific fields from a value map
g.V().has('code','AUS').valueMap().select('code','icao','desc')

[code:[AUS],icao:[KAUS],desc:[Austin Bergstrom International Airport]]

If you are reading the output of queries that use valueMap on the Gremlin console, it is sometimes easier to read the output if you add an unfold step to the end of the query as follows.

g.V().has('code','AUS').valueMap(true,'code','icao','desc','city').unfold()

code=[AUS]
city=[Austin]
icao=[KAUS]
id=3
label=airport
desc=[Austin Bergstrom International Airport]

3.4. Assigning query results to a variable

It is extremely useful to be able to assign the results of a query to a variable. The example below stores the results of the valueMap call shown above into a variable called aus.

// Store the properties for the AUS aiport in the variable aus.
aus=g.V().has('code','AUS').valueMap().next()
Tip
It is necessary to add a call to next to the end of the query in order for this to work. Forgetting to add the call to next is a very commonly made mistake by people getting used to the Gremlin query language. The call to next terminates the traversal part of the query and generates a concrete result that can be stored in a variable.

Once you have some results in a variable you can refer to it as you would in any other programming language that supports key:value type maps and dictionaries. We will explore mixing Java and Groovy code with your Gremlin queries later in this document. For now we will just show the Groovy println command being used to display the results of the query that we stored in aus. We will take a deeper look at the use of variables with Gremlin later in the document when we look at mixing Gremlin and Groovy in the "Making Gremlin even Groovier" section.

// We can now refer to aus using key:value syntax
println "The AUS airport is located in " + aus['city'][0]

The AUS airport is located in Austin
Note
Because properties are stored as arrays of values. Even if there is only one property value for the given key, we still have to add the [0] when referencing it otherwise the whole array will be returned if we just used aus['city']. We will explore why property values are stored in this way in the "Attaching multiple values (lists or sets) to a single property" section.

3.5. Working with IDs

Every vertex and every edge in a graph has a unique ID that can be used to reference them individually or as a group. Beware that the IDs you provide when loading a graph from a GraphML or GraphSON file may not in many cases end up being the IDs that the back-end graph store actually uses as it builds up your graph. Tinkergraph for example will preserve user provided IDs but most systems like Janus Graph or IBM-Graph generate their own IDs. The same is true when you add vertices and edges using a graph traversal or using the TinkerPop API. This is a long winded way of saying that you should not depend on the IDs in your GraphML or GraphSON file that you just loaded remaining unchanged once the data has been loaded into the graph store. When you add new a vertex or edge to your graph, the graph system will automatically generate a new, unique ID for it. If you need to figure out the ID for a vertex or an edge you can always get it from a query of the graph itself!

Tip
Don’t rely on the graph preserving the ID values you provide. Write code that can query the graph itself for ID values.

Especially when dealing with large graphs, because using IDs is typically very efficient, you will find that many of your queries will involve collecting one or more IDs and then passing those on to other queries or parts of the same query. In most if not all cases, the underlying graph system will have setup it’s data structures, whether on disk or in memory, to be very rapidly accessed by ID value.

Let’s demonstrate the use of ID values using a few simple examples. The query below finds the ID, which is 8, for the vertex that represents the DFW airport.

 // What is the ID of the "DFW" vertex?
 g.V().has('code','DFW').id()

 8

Let’s reverse the query and find the code for the vertex with an ID of 8.

// Simple lookup by ID
g.V().hasId(8).values('code')

DFW

We could also have also written the above query as follows.

// which is the same as this
g.V().has(id,8).values('code')

Here are some more examples that make use of the ID value.

// vertices with an ID between 1 and 5 (note this is inclusive/exclusive)
g.V().hasId(between(1,6))

// Which is an alternate form of this
g.V().has(id,between(1,6))

// Find routes from the vertex with an ID of 6 to any vertex with an ID less than 46
g.V().hasId(6).out().has(id,lt(46)).path().by('code')

// Which is the same as
g.V().hasId(6).out().hasId(lt(46)).path().by('code')

You can also pass a single ID or multiple IDs directly into the V() step. Take a look at the two examples below.

// What is the code property for the vertex with an ID of 3?
g.V(3).values('code')

AUS

// As above but for all of the specified vertex IDs
g.V(3,6,8,15).values('code')

AUS
BWI
DFW
MCO

You can also pass a list of ID values into the V step. We take a closer look at using variables in this way in the "Using a variable to feed a traversal" section.

a=[3,6,8,15]

g.V(a).values('code')

Every property in the graph also has an ID as we shall explore in the "Properties have IDs too" section.

3.6. Working with labels

It’s a good idea when designing a graph to give the vertices and edges meaningful labels. You can use these to help refine searches. For example in the air-routes graph, every airport vertex is labelled airport and every country vertex, not surprisingly, is labelled country. Similarly, edges that represent a flight route are labelled route. You can use labels in many ways. We already saw the hasLabel() step being used in the basic queries section to test for a particular label. Here are a few more examples.

// What label does the LBB vertex have?
g.V().has('code','LBB').label()

// What airports are located in Australia?  Note that 'contains' is an
// edge label and 'country' is a vertex label.
g.V().hasLabel('country').has('code','AU').out('contains').values('code')

// We could also write this query as follows
g.V().has('country','code','AU').out().values('code')

By using labels in this way we can effectively group vertices and edges into classes or types. Imagine if we wanted to build a graph containing different types of vehicles. We might decide to label all the vertices just vehicle but we could decide to use labels such as car, truck and bus. Ultimately the overall design of your graph’s data model will dictate the way you use labels but it is good to be aware of their value.

Note
As useful as labels are, in larger graph deployments when indexing technology such as Solr or Elastic Search is often used to speed up traversing the graph, vertex labels typically do not get indexed. Therefore, it is currently recommended that an actual vertex property that can be indexed is used when walking a graph rather than relying on the vertex label. This is especially important when working with large graphs where performance can become an issue.

Here are a few more examples of ways we can work with labels.

// You can explicitly reference a vertex label using the label() method
g.V().where(label().is(eq('airport'))).count()

// But you would normally just use the hasLabel() method in this case of course
g.V().hasLabel('airport').count()

// How many non airport vertices are there?
g.V().where(label().is(neq('airport'))).count

// Again, it would be more natural to actually write this query like this:
g.V().not(hasLabel('airport')).count()

// The same basic concepts apply equally to edges
g.E().where(label().is(eq('route'))).count()

g.E().hasLabel('route').count()

Of course we have already seen another common place where labels might get used. Namely in the three parameter form of has as in the example below. The first parameter is the label value. The next two parameters test the properties of all vertices that have the airport label for a code of "SYD".

g.V().has('airport','code','SYD')

3.7. Using the local step to make sure we get the result we intended

Sometimes it is important to be able to do calculations based on the current state of a traversal rather than waiting until near the end. A common place where this is necessary is when calculating the average value of a collection. In the next section we are going to look at a selection of numerical and statistical operations that Gremlin allows us to perform. However, for now lets use the mean step to calculate the average of something and look at the effect the local step has on the calculation. The mean step works just like you would expect, it returns the mean, or average, value for a set of numbers.

If we wanted to calculate the average number of routes from an airport, the first query that we would write might look like the one below.

g.V().hasLabel('airport').out('route').count().mean()

43400.0

As you can see the answer we got back, 42760.0 looks wrong, and indeed it is. That number is in fact the total number of outgoing routes in the entire graph. This is because as written the query counts all of the routes, adds them all up, but does not keep track of how many airports it visited. This means that calling the mean step is essentially the same as dividing the count by one.

So how do we fix this? The answer is to use the local step. What we really want to do is to create, in essence, a collection of values, where each value is the route count for just one airport. Having done that, we want to divide the sum of all of these numbers by the number of members ,airports in this case, int the collection.

Take a look at the modified query below.

// Average number of outgoing routes from an airport.
g.V().hasLabel('airport').local(out('route').count()).mean()

12.863070539419088

The result this time is a much more believable answer. Notice how this time we placed the out().('route').count() steps inside a local step. The query below, with the mean step removed, shows what is happening during the traversal as this query runs. I truncated the output to just show a few lines.

g.V().hasLabel('airport').local(out('route').count()).limit(10)

232
38
59
55
129
87
93
220
141
135

What this shows is that for the first ten airports the collection that we are building up contains one entry for each airport that represents the number of outgoing routes that airport has. Then, when we eventually apply the mean step it will calculate the average value of our entire collection and give us back the result that we were looking for.

There are other ways that local can be used. We will see examples of those throughout the document including how local can be used as a parameter to the order step when we dig deeper into route analysis in the ""Distribution of routes in the graph (mode and mean) section of the document.

3.8. Basic statistical and numerical operations

The following queries demonstrate concepts such as calculating the number of a particular item that is present in the graph, calculating the average (mean) of a set of values and calculating a maximum or minimum value. We will dig a bit deeper into some of these capabilities and explain in more detail in the "Distribution of routes in the graph (mode and mean)" section of the document. Some of these examples also take advantage of the local step that was introduced in the previous section.

// How many routes are there from Austin?
g.V().has("airport","code","AUS").out().count()

// Sum of values - total runways of all airports
g.V().hasLabel('airport').values('runways').sum()

// Statistical mean (average) value - average number of runways per airport
g.V().hasLabel('airport').values('runways').mean()

// Average number of routes to and from an airport
g.V().hasLabel('airport').local(both('route').count()).mean()

//maximum value - longest runway
g.V().hasLabel('airport').values('longest').max()

// What is the biggest number of outgoing routes any airport has?
 g.V().hasLabel('airport').local(out('route').count()).max()

//minimum value - shortest runway
g.V().hasLabel('airport').values('longest').min()

3.8.1. Testing values and ranges of values

We have already seen some ways of testing whether a value is within a certain range. Gremlin provides a number of different steps that we can use to do range testing. The list below provides a summary of the available steps. We will see each of these in use throughout this document.

Table 1. Steps that test values or ranges of values

eq

Equal to

neq

Not equal to

gt

Greater than

gte

Greater than or equal to

lt

Less than

lte

Less than or equal to

inside

Inside a lower and upper bound, neither bound is included.

outside

Outside a lower and upper bound, neither bound is included.

between

Between two values inclusive/exclusive (upper bound is excluded)

within

Must match at least one of the values provided. Can be a range or a list

without

Must not match any of the values provided. Can be a range or a list

The following queries demonstrate these capabilities being used in different ways. First of all, here are some examples of some of the direct compare steps such as gt and gte being used. The fold step conveniently folds all of the results into a list for us.

// Airports with at least 5 runways
g.V().has('runways',gte(5)).values('code','runways').fold()

Here is the output that we might get from running the query.

[ATL,5,BOS,6,DFW,7,IAH,5,ORD,8,DEN,6,DTW,6,YYZ,5,AMS,6,SNN,5,MKE,5,MDW,5,GIS,5,HLZ,5,NPE,5,NSN,5,PPQ,5,TRG,5,UFA,5,KRP,5]

The next three queries show examples of lt, eq and neq bing used.

// Airports with less than 3 runways
g.V().has('runways',lt(3)).values('code','runways').fold()

// How many airports have 3 runways?
g.V().has('runways',eq(3)).count()

// How many airports have anything but just 1 runway?
g.V().has('runways',neq(1)).count()

Here are examples of inside and outside being used.

// Airports with greater than 3 but less than 6 runways.
g.V().has('runways',inside(3,6)).values('code','runways')

// Airports with less than  3 or more than 6 runways.
g.V().has('runways',outside(3,6)).values('code','runways')

Below are some examples showing within and without being used.

// Airports with at least 3 but not more than 6 runways
g.V().has('runways',within(3..6)).values('code','runways').limit(15)

// Airports with 1,2 or 3 runways.
g.V().has('runways',within(1,2,3)).values('code','runways').limit(15)

// Airports with less than 3 or more than 6 runways.
g.V().has('runways',without(3..6)).values('code','runways').limit(15)

The between step lets us test the provided value for being greater than or equal to a lower bound but less than an upper bound. The query below will find any airport that has 5,6 or 7 runways. In other words, any airport that has at least 5 but less than 8 runways.

// Airports with at least 5 runways but less than 8
g.V().has('runways',between(5,8)).values('code','runways').fold()

Here is the result of running the query.

[ATL,5,BOS,6,DFW,7,IAH,5,DEN,6,DTW,6,YYZ,5,AMS,6,SNN,5,MKE,5,MDW,5,GIS,5,HLZ,5,NPE,5,NSN,5,PPQ,5,TRG,5,UFA,5,KRP,5]

As with many queries we may build, there are several ways to get the same answer. Each of the following queries will return the same result. To an extent which one you use comes down to personal preference although in some cases one form of a query may be better than another for reasons of performance.

g.V().hasId(gt(0)).hasId(lte(46)).out().hasId(lte(46)).count()

g.V().hasId(within(1..46)).out().hasId(lte(46)).count()

g.V().hasId(within(1..46)).out().hasId(within(1L..46L)).count()

g.V().hasId(between(1,47)).out().hasId(lte(46)).count()

g.V().hasId(within(1..46)).out().hasId(between(1,47)).count()

g.V().hasId(inside(0,47)).out().hasId(lte(46)).count()
Note
The values do not have to be numbers. We could also compare strings for example.

Let’s now look at a query that compares strings rather than numbers. The following query finds all airports located in the state of Texas in the United States but only returns their code if the name of the city the airport is located in is not Houston

g.V().has('airport','region','US-TX').has('city',neq('Houston')).
      values('code')

This next query can be used to find routes between Austin and Las Vegas. We use a within step to limit the results we get back to just routes that have a plane change in Dallas, San Antonio or Houston airports.

 g.V().has('airport','code','AUS').
       out().has('code',within('DFW','DAL','IAH','HOU','SAT')).
       out().has('code','LAS').path().by('code')

Here is what the query returns. Looks like we can change planes in Dallas or Houston but nothing goes via San Antonio.

[AUS,DFW,LAS]
[AUS,IAH,LAS]
[AUS,DAL,LAS]
[AUS,HOU,LAS]

Conversely, if we wanted to avoid certain airports we could use without instead. This query again finds routes from Austin to Las Vegas but avoids any routes that go via Phoenix (PHX) or Los Angeles (LAX).

 g.V().has('airport','code','AUS').
       out().has('code',without('PHX','LAX')).
       out().has('code','LAS').path().by('code')

Lastly this query uses both within and without to modify the previous query to just airports within the United States or Canada as Austin now has a direct flight to London in England we probably don’t want to go that way if we are headed to Vegas!

g.V().has('airport','code','AUS').out().
      has('country',within('US','CA')).
      has('code',without('PHX','LAX')).out().
      has('code','LAS').path().by('code')

The within and without steps can take a variety of input types. For example, each of these queries will yield the same results.

// Range of values (inclusive, inclusive)
g.V().hasId(within(1..3))

// Explicit set of values
g.V().hasId(within(1,2,3))

// List of values
g.V().hasId(within([1,2,3]))

You will find more examples of these types of queries in the next section.

3.8.2. Refining flight routes analysis using not, neq, within and without

As we saw in the previous section, it is often useful to be able to specifically include or exclude values from a query. We have already seen a few examples of within and without being used in the section above. The following examples show additional queries that use within and without as well as some examples that use the neq (not equal) and not steps to exclude certain airports from query results.

The following query finds routes from AUS to SYD with only one stop but ignores any routes that stop in DFW.

g.V().has('airport','code','AUS').
      out().has('code',neq('DFW')).
      out().has('code','SYD').path().by('code')

We could also have written the query using not

g.V().has('airport','code','AUS').
      out().not(values('code').is('DFW')).
      out().has('code','SYD').path().by('code')

Similar to the above but adding an and clause to also avoid LAX

g.V().has('airport','code','AUS').
      out().and(has('code',neq('DFW')),has('code',neq('LAX'))).
      out().has('code','SYD').path().by('code')

We could also have written the prior query this way replacing and with without This approach feels a lot cleaner and it is easy to add more airports to the without test as needed. We will look more at steps like and in the "Boolean operations" section that is coming up soon.

// Flights to Sydney avoiding DFW and LAX
g.V().has('airport','code','AUS').
      out().has('code',without('DFW','LAX')).
      out().has('code','SYD').path().by('code')

Using without is especially useful when you want to exclude a list of items from a query. This next query finds routes from San Antonio to Salt Lake City with one stop but avoids any routes that pass through a list of specified airports.

// How can I get from SAT to SLC but avoiding DFW,LAX,PHX and JFK ?
g.V().has('airport','code','SAT').
      out().has('code',without('DFW','LAX','PHX','JFK')).
      out().has('code','SLC').path().by('code')

In a similar way, within allows us to specifically give a list of things that we are interested in. The query below again looks from routes from SAT to SLC with one stop but this time only returns routes that stop in one of the designated airports.

// From AUS to SLC with a stop in any one of DFW,LAX,PHX or TUS
g.V().has('airport','code','SAT').
       out().has('code',within('DFW','LAX','PHX','TUS')).
       out().has('code','SLC').path().by('code')

Here is what the query returns.

[SAT,LAX,SLC]
[SAT,DFW,SLC]

Here are two more examples that use without and within to find routes based on countries.

// Flights from Austin to countries outside (without) the US and Canada
g.V().has('code','AUS').out().has('country',without('US','CA')).values('city')

Here is the output from running the query.

London
Frankfurt
Mexico City
Cancun
Guadalajara

Here is a twist on the previous query that looks for destinations in Mexico or Canada that you can fly to non stop from Austin.

// Flights from Austin to airports in (within) Mexico or Canada
g.V().has('code','AUS').out().has('country',within('MX','CA')).values('city')

This is what we get back from our new query.

Toronto
Mexico City
Cancun
Guadalajara

3.8.3. Using coin and sample to sample a dataset

In any sort of analysis work it is often useful to be able to take a sample, perhaps a pseudo random sample, of the data set contained within your graph. The coin step allows you to do just that. It simulates a biased coin toss. You give coin a value indicating how biased the toss should be. The value should be between 0 and 1, where 0 means there is no chance something will get picked (not that useful!), 1 means everything will get picked (also not that useful!) and 0.5 means there is an even 50/50 chance that an item will get selected.

The following query simply picks airports with a 50/50 coin toss and returns the airport code for the first 20found.

// Pick 20 airports at random with an evenly biased coin (50% chance).
g.V().hasLabel('airport').coin(0.5).limit(20).values('code')

This next query is similar to the first but takes a subtly different approach. It will select a pseudo random sample of vertices from the graph and for each one picked return its code and its elevation. Note that a very small value of 0.05 (or 5% chance of success) is used for the coin bias parameter this time. This has the effect that only a small number of vertices are likely to get selected but there is a better chance they will come from all parts of the graph and avoids needing a limit step. Of course, there is no guarantee how many airports this query will pick!

// Select some vertices at random and return them with their elevation.
g.V().hasLabel('airport').coin(0.05).values('code','elev').fold()

We can see how fairly the coin step is working by counting the number of vertices returned. The following query should always return a count representing approximately half of the airports in the graph.

g.V().hasLabel('airport').coin(0.5).count()

If all you want is, say 20 randomly selected vertices, without worrying about setting the value of the coin yourself, you can use the sample step instead.

g.V().hasLabel('airport').sample(20).values('code')

3.8.4. Using Math.random to more randomly select a single node

While the sample step allows you to select one or more vertices at random, in my testing, at least when using a TinkerGraph, it tends to favor vertices with lower index values. So for example, in a test I ran this query 1000 times.

g.V().hasLabel('airport').sample(1).id()

What I found was that I always got back an ID of less than 200. This leads me to believe that the sample(1) call is doing something similar to this

g.V().hasLabel('airport').coin(0.01).limit(1)

Look at the code below. Even if I run that simple experiment many times always gives results similar to these.

(1..10).each { println g.V().hasLabel('airport').sample(1).id().next()}

69
143
94
115
36
47
23
22
129
67

Given the air routes graph has over 3,300 airport vertices I wanted to come up with a query that gave a more likely result of picking any one airport from across all of the possible airports in the graph. By taking advantage of the Java Math class we can do something that does seem to much more randomly pick one airport from across all of the possible airports. Take a look at the snippets of Groovy/Gremlin code below.

Note
More examples of using variables to store values and other ways to use additional Groovy classes and methods with Gremlin are provided in the "Making Gremlin even Groovier" and "Using a variable to feed a traversal" sections.
// How many airports are there?
numAirports = g.V().hasLabel('airport').count().next()

3374

// Pick a random airport ID
x=Math.round(numAirports*Math.random()) as Integer

2359

// Get the code for our randomly selected airport
g.V(x).values('code')

PHO

This simple experiment shows that the numbers being generated using the Math.random approach appears to be a lot more evenly distributed across all of the possible airports.

(1..10).each { println Math.round(numAirports*Math.random()) as Integer}

1514
18
3087
1292
3062
2772
2401
400
2084
3028

Note that this approach only works unmodified with the air-routes graph loaded into a TinkerGraph. This is because we know that the TinkerGraph implementation honors user provided IDs and that in the air routes graph, airport IDs begin at one and are sequential with no gaps. However, you could easily modify this approach to work with other graphs without relying on knowing that the index values are sequential. For example you could extract all of the IDs into a list and then select one randomly from that list.

It is likely that this apparent lack of randomness is more specific to TinkerGraph and the fact that it will respect user provided ID values whereas other graph systems will probably store vertices in a more random order to begin with. Indeed when I ran these queries on Janus graph the sample step did indeed yield a better selection of airports from across the graph.

If the airport IDs were not all known to be in a sequential order one after the other, we could create a list of all the airport IDs and then select one at random by doing do something like this if we wanted to use our Math.random technique.

airports = g.V().hasLabel('airport').id().toList()

numAirports = airports.size

3374

x=Math.round(numAirports*Math.random()) as Integer

859

g.V(airports[x-1])

v[859]

g.V(airports[x-1]).values('code')

OSR

3.9. Sorting things

You can use order to sort things in either ascending (the default) or descending order.Note that the sort does not have to be the last step of a query. It is perfectly OK to sort things in the middle of a query before moving on to a further step. We can see examples of that in the first two queries below. Note that the first query will return different results than the second one. I used fold at the end of the query to collect all of the results into a nice list. The fold step can also do more than this. It provides a way of doing the reduce part of map-reduce operations. We will see some other examples of its use elsewhere in this document such as in the "Using fold to do simple Map-Reduce computations" section.

// Sort the first 20 airports returned in ascending order
g.V().hasLabel('airport').limit(20).values('code').order().fold()

[ANC,ATL,AUS,BNA,BOS,BWI,DCA,DFW,FLL,IAD,IAH,JFK,LAX,LGA,MCO,MIA,MSP,ORD,PBI,PHX]


// Sort all of the airports in the graph by their code and then return the first 20
g.V().hasLabel('airport').order().by('code').limit(20).values('code').fold()

[AAE,AAL,AAN,AAQ,AAR,AAT,AAX,AAY,ABA,ABB,ABD,ABE,ABI,ABJ,ABL,ABM,ABQ,ABR,ABS,ABT]

By default a sort performed using order is performed in ascending order. If we wanted to sort in descending order instead we can specify decr as a parameter to order. We can also specify incr if we want to be clear that we intend an ascending order sort.

// Sort the first 20 airports returned in descending order
g.V().hasLabel('airport').limit(20).values('code').order().by(decr).fold()

[PHX,PBI,ORD,MSP,MIA,MCO,LGA,LAX,JFK,IAH,IAD,FLL,DFW,DCA,BWI,BOS,BNA,AUS,ATL,ANC]

You can also sort things into a random order using shuffle. Take a look at the example below and the output it produces.

g.V().hasLabel('airport').limit(20).values('code').order().by(shuffle).fold()

[MCO,LGA,BWI,IAD,ATL,BOS,DCA,BNA,IAH,DFW,MIA,MSP,ANC,AUS,JFK,ORD,PBI,FLL,LAX,PHX]

Below is an example where we combine the field we want to sort by longest and the direction we want the sort to take, decr into a single by instruction.

// List the 10 airports with the longest runways in decreasing order.
g.V().hasLabel('airport').order().by('longest',decr).valueMap().select('code','longest').limit(10)

Here is the output from running the query. To save space I have split the results into two columns.

[code:[BPX],longest:[18045]]    [code:[DOH],longest:[15912]]
[code:[RKZ],longest:[16404]]    [code:[GOQ],longest:[15748]]
[code:[ULY],longest:[16404]]    [code:[HRE],longest:[15502]]
[code:[UTN],longest:[16076]]    [code:[FIH],longest:[15420]]
[code:[DEN],longest:[16000]]    [code:[ZIA],longest:[15092]]

Lastly, let’s look at another way we could have coded the query we used earlier to find the longest runway in the graph. As you may recall, we used the following query.While the query does indeed find the longest runway in the graph. If we wanted to know which airport or airports had runways of that length we would have to run a second query to find them.

g.V().hasLabel('airport').values('longest').max()

Now that we know how to sort things we could write a slightly more complex query that sorts all the airports by longest runway in descending order and returns the valueMap for the first of those. While this query could probably be written more efficiently and also improved to handle cases where more than one airport has the longest runway, it provides a nice example of using order to find an airport that we are interested in.

g.V().hasLabel('airport').order().by(values('longest'),decr).limit(1).valueMap()

In the case of the air-routes graph there is only one airport with the longest runway. The runway at the Chinese city of Bangda is 18,045 feet long. The reason the runway is so long is due to the altitude of the airport which is located 14,219 feet above sea level. Aircraft need a lot more runway to operate safely at that altitude!

[country:[CN], code:[BPX], longest:[18045], city:[Bangda], elev:[14219], icao:[ZUBD], lon:[97.1082992553711], type:[airport], region:[CN-54], runways:[1], lat:[30.5536003112793], desc:[Qamdo Bangda Airport]]

3.9.1. Sorting by key or value

Sometimes, when the results of a query are a set of one or more key:value pairs, we need to sort by either the key or the value in either ascending or descending order. Gremlin offers us ways that we can control the sort in these cases. Examples of how this works are shown below.

Note
In Tinkerpop 3.3 changes to the syntax were made. The previous keywords valueDecr, valueIncr, keyDecr and keyIncr are now specified using the form by(keys,incr) or by(values,decr) etc.

The following example shows the difference between running a query with and without the use of order to sort using the keys of the map created by the group step.

// Query but do not order
g.V().hasLabel('airport').limit(5).group().by('code').by('runways')

[BNA:[4],ANC:[3],BOS:[6],ATL:[5],AUS:[2]]

Notice also how local is used as a parameter to order. This is required so that the ordering is done while the final list is being constructed. If you do not specify local then order will have no effect as it will be applied to the entire result which is treated as a single entity at that point.

// Query and order by airport code (the key)
g.V().hasLabel('airport').limit(5).
      group().by('code').by('runways').
      order(local).by(keys,incr)

[ANC:[3],ATL:[5],AUS:[2],BNA:[4],BOS:[6]]

In this example we make the numbers of runways the key field and sort on it in descending order.

g.V().hasLabel('airport').limit(10).
      group().by('runways').by('code').
      order(local).by(keys,decr)

[7:[DFW],6:[BOS],5:[ATL],4:[BNA,IAD],3:[ANC,BWI,DCA],2:[AUS,FLL]]

3.10. Boolean operations

Gremlin provides a set of logical operators such as and, or and not that can be used to form Boolean (true/false) type queries. In a lot of cases I find that or can be avoided by using within for example and that not can be sometimes avoided by using without but it is still good to know that these operators exist. The and operator can sometimes be avoided by chaining has steps together. That said there are always cases where having these boolean steps available is extremely useful.

// Simple example of doing a Boolean AND operation
g.V().and(has('code','AUS'),has('icao','KAUS'))

// Simple example of doing a Boolean OR operation
g.V().or(has('code','AUS'),has('icao','KDFW'))

You can also use and in an infix way as follows so long as you only want to and two traversals together.

g.V().has('code','AUS').and().has('icao','KAUS')

As you would probably expect, an or step can have more than two choices. This one below has four. Also, note that in practice, for this query, using within would be a better approach but this suffices as an example of a bigger or expression.

g.V().hasLabel('airport').or(has('region','US-TX'),
                             has('region','US-LA'),
                             has('region','US-AZ'),
                             has('region','US-OK'))
                          .order().by('region',incr)
                          .valueMap().select('code','region')

Using within the example above could be written like this so always keep in mind that using or may not always be the best approach to use for a given query. We will look more closely at the within and without steps in the following section.

g.V().hasLabel('airport').has('region',within('US-TX','US-LA','US-AZ','US-OK')).
                          order().by('region',incr).
                          valueMap().select('code','region')

This next example uses an and step to find airports in Texas with a runway at least 12,000 feet long.

g.V().hasLabel('airport').and(has('region','US-TX'),has('longest',gte(12000))).values('code')

As with the or step, using and is not always necessary. We could rewrite the previous query as follows.

g.V().has('region','US-TX').has('longest',gte(12000))

Gremlin also provides a not step which works as you would expect. This query finds vertices that are not airports?

g.V().not(hasLabel('airport')).count()

This previous query could also be written as follows.

g.V().has(label,neq('airport')).count()
Tip
Depending on the model of your graph and the query itself it may or may not make sense to use the boolean steps. Sometimes, as described above chaining has steps together may be more efficient or using within and without my make more sense.

Boolean steps such as and can also be dot combined as the example below shows. This query finds all the airports that have less than 100 outbound routes but more than 95 and returns them grouped by airport code and route count. Notice how in this case the and step is added to the lt step using a dot rather than having the and be the containing step for the whole test. The results from running the query are shown below as well.

g.V().hasLabel('airport').
      where(out().count().is(lt(100).and(gt(95)))).
      group().by('code').by(out().count())

[BUD:96,SZX:99,AUH:97,BGY:99]

The query we just looked at could also be written as follows but in this case using the and step inline by dot combining it (as above) feels cleaner to me. As you can see we get the same result as before.

g.V().hasLabel('airport').where(and(out().count().is(lt(100)),
                out().count().is(gt(95)))).
      group().by('code').by(out().count())

[BUD:96,SZX:99,AUH:97,BGY:99]

As a side note, if we wanted to reverse the grouping so that the airports were grouped by the counts rather than the codes we could do that as follows.

g.V().hasLabel('airport').
      where(out().count().is(lt(100).and(gt(95)))).
      group().by(out().count()).by('code')

[96:[BUD],97:[AUH],99:[SZX,BGY]]

You can also add additional inline and steps to a query as shown below. Notice that this time AUH is not part of the result set as it has 97 routes which our new and test eliminates.

g.V().hasLabel('airport').
      where(out().count().is(lt(100).and(gt(95)).and(neq(97)))).
      group().by(out().count()).by('code')

[96:[BUD],99:[SZX,BGY]]

We used the where step a lot in the examples above. We will explain in more detail how the where step works in the "Using where to filter things out of a result" section which is coming up soon.

3.11. Using where to filter things out of a result

We have already seen the where step used in some of the prior examples. In this section we will take a slightly more focussed look at the where step. The where step is an example of a filter. It takes the current state of a traversal and only allows anything that matches the specified constraint to pass on to any following steps. Where can be used by itself, or as we shall see later, in conjunction with a by modulator or following a match or a choose step.

Tip
It is worth noting that some queries that use where can also be written using has instead.

Let’s start by looking at a simple example of how has and where can be used to achieve the same result.

// Find airports with more than five runways
g.V().has('runways',gt(5))

// Find airports with more than five runways
g.V().where(values('runways').is(gt(5)))

In examples like the one above, both queries will yield the exact same results but the has step feels simpler and cleaner for such cases. The next example starts to show the power of the where step. We can include a traversal inside of the where step that does some filtering for us. In this case, we first find all vertices that are airports and then use a where step to only keep airports that have more than 60 outgoing routes. Finally we count how many such airports we found.

// Airports with more than 60 unique routes from them
g.V().hasLabel('airport').where(out('route').count().is(gt(60))).count()

179

In our next example, we want to find routes between airports that have an ID of less than 47 but only return routes that are longer than 4,000 miles. Again, notice how we are able to look at the incoming vertex ID values by placing a reference to inV at the start of the where expression. The where step is placed inside of an and step so that we can also examine the dist property of the edge. Finally we return the path as the result of our query.

// Routes longer than 4,000 miles between airports with and ID less than 47
g.V().hasId(lt(47)).outE().
      and(where(inV().id().is(lt(47))),values('dist').is(gt(4000))).inV().
      path().by('code').by('dist')

Below is what we get back as a result of running the query.

[ATL,4502,HNL]
[JFK,4970,HNL]
[ORD,4230,HNL]
[EWR,4950,HNL]
[HNL,4502,ATL]
[HNL,4970,JFK]
[HNL,4230,ORD]
[HNL,4950,EWR]

Our last example in this section uses a where step to make sure we don’t end up back where we started when looking at airline routes with one stop. We find routes that start in Austin, with one intermediate stop, that then continue to another airport, but never end up back in Austin. A limit step is used to just return the first 10 results that match this criteria. Notice how the as step is used to label the AUS airport so that we can refer to it later in our where step. The effect of this query is that routes such as AUS→DFW→AUS will not be returned but AUS→DFW→LHR will be as it does not end up back in Austin.

// List 10 places you can fly to with one stop, starting at Austin but
// never ending up back in Austin
g.V().has('code','AUS').as('a').out().out().where(neq('a')).
              path().by('code').limit(10)

3.11.1. Using where and by to filter results

A new capability was added in the Tinkerpop 3.2.4 release that allows a where step to be followed with a by modulator. This makes writing certain types of queries a lot easier than it was before. The query below starts at the Austin airport and finds all the airports that you can fly to from there. A where by step is then used to filter the results to just those airports that have the same number of runways that Austin has. What is really nice about this is that we do not have to know ahead of time how many runways Austin itself has as that is handled for us by the query.

 g.V().has('code','AUS').as('a').out().
       where(eq('a')).by('runways').valueMap('code','runways')
Tip
Combining the where and by steps allows you to write powerful queries in a nice and simple way.

If you were to run the query in the Gremlin Console, these are the results that you should see. Note that all the airports returned have two runways. This is the same number of runways that the Austin airport has.

[code:[LHR],runways:[2]]
[code:[MEX],runways:[2]]
[code:[CUN],runways:[2]]
[code:[GDL],runways:[2]]
[code:[PNS],runways:[2]]
[code:[VPS],runways:[2]]
[code:[FLL],runways:[2]]
[code:[SNA],runways:[2]]
[code:[MSY],runways:[2]]

3.12. Using choose to write if…​then…​else type queries

The choose step allows the creation of queries that are a lot like the "if then else" constructs found in most programming languages. If we were programming in Java we might find ourselves writing something like the following.

if (longest > 12000)
{
  return(code);
}
else
{
  return(desc);
}

Gremlin offers us a way to do the same thing. The query below finds all the airports in Texas and then will return the value of the code property if an airport has a runway longer than 12,000 feet otherwise it will return the value of the desc.

// If an airport has a runway > 12,000 feet return its code else return its description
g.V().has('region','US-TX').choose(values('longest').is(gt(12000)),
                                   values('code'),
                                   values('desc'))

Here is another example that uses the same constructs.

// If an airport has a code of AUS or DFW report its region else report its country
g.V().hasLabel('airport').choose(values('code').is(within('AUS','DFW')),
                                 values('city'),
                                 values('region')).limit(15)

Sometimes it is very useful, as the query below demonstrates, to return constant rather than derived values as part of a query. This query will return the string "some" if an airport has less than four runways or "lots" if it has more than four.

// You can also return constants using the constant() step
g.V().hasLabel('airport').limit(10).
      choose(values('runways').is(lt(4)),
             constant('some'),
             constant('lots'))
Tip
The constant step can be used to return a constant value as part of a query.

Here is one more example that uses a sample step to pick 10 airports and then return either "lots" or "not so many" depending on whether the airport has more than 50 routes or not. Note also how as and select are used to combine the both the derived and constant parts of the query result that we will ultimately return.

g.V().hasLabel('airport').sample(10).as('a').
      choose(out('route').count().is(gt(50)),
             constant('lots'),
             constant('not so many')).as('b').
      select('a','b').by('code').by()

Here is an example of what the output from running this query might look like.

[a:YYT,b:not so many]
[a:YEG,b:not so many]
[a:LGA,b:lots]
[a:DXB,b:lots]
[a:BLR,b:not so many]
[a:CGN,b:lots]
[a:BOM,b:lots]
[a:SIN,b:lots]
[a:TSF,b:not so many]
[a:HKG,b:lots]

We could go one step further if you don’t want the a: and b: keys returned as part of the result by adding a select(values) to the end of the query as follows.

g.V().hasLabel('airport').sample(10).as('a').
      choose(out('route').count().is(gt(50)),
             constant('lots'),
             constant('not so many')).as('b').
      select('a','b').by('code').by().select(values)

Here is what the output from the modified form of the query.

[YYT,not so many]
[YEG,not so many]
[LGA,lots]
[DXB,lots]
[BLR,not so many]
[CGN,lots]
[BOM,lots]
[SIN,lots]
[TSF,not so many]
[HKG,lots]

3.13. Using option to write case/switch type queries

When option is combined with choose the result is similar to the case or switch style construct found in most programming languages.

// You can combine choose and option to generate a more "case statement" like query
g.V().hasLabel('airport').choose(values('code')).
                            option('DFW',values('desc')).
                            option('AUS',values('region')).
                            option('LAX',values('runways'))


// This example has three options - note the default case of 'none' used as the catchall
// Note how for ease of reading the query can be split across multiple lines.
g.V().hasLabel('airport').limit(10).choose(values('runways')).
                                      option(1,constant('just one')).
                                      option(2,constant('a couple')).
                                      option(7,constant('lots')).
                                      option(none,constant('quite a few'))

3.14. Using match to do pattern matching

Match was added in TinkerPop 3 and allows a more declarative style of pattern based query to be expressed in Gremlin. Match can be a bit hard to master but once you figure it out it can be a very powerful way of traversing a graph looking for specific patterns.

Below is an example that uses match to look for airline route patterns where there is a flight from one airport to another but no return flight back to the original airport. The first query looks for such patterns involving the JFK airport as the starting point. You can see the output from running the query below it. This is the correct answer as, currently, the British Airways Airbus A318 flight from London City (LCY) airport stops in Dublin (DUB) to take on more fuel on the way to JFK but does not need to stop on the way back because of the trailing wind.

// Find any cases of where you can fly from JFK non stop to a place you cannot get back from
// there non stop.This query should return LCY, as the return flight stops in DUB to refuel.
g.V().has('code','JFK').match(__.as('s').out().as('d'),
                              __.not(__.as('d').out().as('s'))).
                        select('s','d').by('code')

[s:JFK,d:LCY]

We can expand the query by leaving off the specific starting point of JFK and look for this pattern anywhere in the graph. This really starts to show how important and useful the match Gremlin step is. We don’t have any idea what we might find, but by using match, we are able to describe the pattern of behavior that we are looking for and Gremlin does the rest.

// Same as above but from any airport in the graph.
g.V().hasLabel('airport').match(__.as('s').out().as('d'),
                                __.not(__.as('d').out().as('s'))).
                          select('s','d').by('code')

If you were to run the query you would find that there are in fact over 200 places in the graph where this situation applies. We can add a count to the end of query to find out just how many there are.

// How many occurrences of the pattern in the graph are there?
g.V().hasLabel('airport').match(__.as('s').out().as('d'),
                                __.not(__.as('d').out().as('s'))).
                          select('s','d').by('code').count()


238

The next query looks for routes that follow the pattern A→B→C but where there is no direct flight of the form A→C. In other words it looks for all routes between two airports with one intermediate stop where there is no direct flight alternative available. Note that the query also eliminates any routes that would end up back at the airport of origin. To achieve the requirement that we not end up back where we started, a where step is included to make sure we do not match any routes of the form A→B→A.

g.V().hasLabel('airport').match(__.as('a').out().as('b')
                               ,__.as('b').out().where(neq('a')).as('c')
                               ,__.not(__.as('a').out().as('c'))).
                          select('a','b','c').by('code').limit(10)

There are, of course a lot of places in the air-routes graph where this pattern can be found. Here are just a few examples of the results you might get from running the query.

[a:ATL,b:MLB,c:ISP]
[a:ATL,b:MLB,c:BIM]
[a:ATL,b:MLB,c:YTZ]
[a:ATL,b:PHF,c:SFB]
[a:ATL,b:SBN,c:SFB]
[a:ATL,b:SBN,c:AZA]
[a:ATL,b:SBN,c:PIE]
[a:ATL,b:SBN,c:PGD]
[a:ATL,b:TRI,c:SFB]
[a:ATL,b:TRI,c:PIE]

Here is another example of using match along with a where. This query starts out by looking at how many runways Austin has and then looks at every airport that you can fly to from Austin and then looks at how many runways those airports have. Only airports with the same number as Austin are returned. While this is a bit of a contrived query, it does show the power of match and also illustrates using values calculated in one part of a query later on in that same query.

g.V().has('code','AUS').
      match(__.as('aus').values('runways').as('ausr'),
            __.as('aus').out('route').as('outa').values('runways').as('outr')
              .where('ausr',eq('outr'))).
      select('outa').valueMap().select('code','runways')

As I mentioned, the example above is a bit contrived and it could actually be done without using a match step at all and just using a where step as shown below. Hopefully, however, these examples give you an idea of what match can do.

g.V().has('code','AUS').as('aus').values('runways').as('ausr').
      select('aus').out().as('outa').values('runways').as('outr').
      where('ausr',eq('outr')).select('outa').valueMap().select('code','runways')

3.15. Using union to combine query results

The union step works just as you would expect from its name. It allows to to combine parts of a query into a single result. Just as with the boolean and and or steps it is sometimes possible to find other ways to do the same thing without using union but it does offer some very useful capability.

By way of a simple example, the following query returns flights that arrive in AUS from the UK of that leave AUS and arrive in Mexico.

// Flights to AUS from the UK or from AUS to Mexico
g.V().has('code','AUS').union(__.in().has('country','UK')
                              ,out().has('country','MX')).path().by('code')

When we run that query, we get the following results

[AUS,LHR]
[AUS,MEX]
[AUS,CUN]
[AUS,GDL]

This query solves the problem "Find all routes that start in London, England and end up in Paris or Berlin with no stops". Because city names are used and not airport codes, all airports in the respective cities are considered.

g.V().has('city','London').has('region','GB-ENG').
         union(out('route').has('city','Paris'),
              out('route').has('city','Berlin')).path().by('code')

Here are the results we get back from running the query.

[LHR,CDG]
[LHR,ORY]
[LHR,TXL]
[LGW,CDG]
[LGW,SXF]
[LCY,CDG]
[LCY,ORY]
[STN,TXL]
[STN,SXF]
[LTN,CDG]
[LTN,SXF]

As mentioned above, sometimes, especially for fairly simple queries, there are alternatives to using union. The previous query could have been written as follows using the within method.

// The above query could have been written without using union() as follows
g.V().has('city','London').has('region','GB-ENG').
      out().has('city',within('Paris','Berlin')).path().by('code')

This next query is more interesting. We again start from any airport in London, but then we want routes that meet any of the criteria:

  • Go to Berlin and then to Lisbon

  • Go to Paris and then Barcelona

  • Go to Edinburgh and then Rome

We also want to return the distances in each case. Note that you can union together as many sets of operations as you need to. In this example we combine the results of three sets of traversals.

// Returns any paths found along with the distances between airport pairs.

g.V().has('city','London').has('region','GB-ENG').
      union(outE().inV().has('city','Berlin').outE('route').inV().has('city','Lisbon').
            path().by('code').by('dist').by('code').by('dist'),
            outE().inV().has('city','Paris').outE('route').inV().has('city','Barcelona').
            path().by('code').by('dist').by('code').by('dist'),
            outE().inV().has('city','Edinburgh').outE('route').inV().has('city','Rome').
            path().by('code').by('dist').by('code').by('dist'))

Here is what we get back when we run our query

[LHR,227,ORY,513,BCN]
[LHR,216,CDG,533,BCN]
[LGW,591,SXF,1432,LIS]
[LGW,191,CDG,533,BCN]
[LCY,227,ORY,513,BCN]
[STN,563,SXF,1432,LIS]
[LTN,589,SXF,1432,LIS]
[LTN,236,CDG,533,BCN]

Here is one last example of using union. This query finds the total distance of all routes from any airport in Madrid to any airport anywhere and also does the same calculation but minus any routes that end up in any Paris airport.

g.V().has('city','Madrid').outE('route').
      union(values('dist').sum(),
            filter(inV().has('city',neq('Paris'))).values('dist').sum())

Here is the output from running the query. As you can see the first number is slightly larger than the second as all routes involving Paris have been filtered out from the calculation.

397708
396410

3.16. Using sideEffect to do things on the side

The sideEffect step allows you to do some additional processing as part of a query without changing what gets passed on to the next stage of the query. The example below finds the airport vertex V(3) and then uses a sideEffect to count the number of places that you can fly to from there and stores it in a traversal variable named a before counting how many places you can get towith one stop and storing that value in b. Note that there are other ways we could write this query but it demonstrates quite well how sideEffect works.

g.V(3).sideEffect(out().count().store('a')).out().out().count().as('b').select('a','b')

[a:[59],b:5911]

Later in the document we will discuss lambda functions, sometimes called closures and how they can be used. The example below combines a closure with a sideEffect to print a message before displaying information about the node that was found. Again notice how the sideEffect step has no effect on what is seen by the subsequent steps. You can see the output generated below the query.

g.V().has('code','SFO').sideEffect{println "I'm working on it"}.values('desc')

I'm working on it
San Francisco International Airport

Later in the document will will look at other ways that side effects can be used to solve more interesting problems.

3.17. Using aggregate to create a temporary collection

At the time of writing this document, there were 59 places you could fly to directly (non stop) from Austin. We can verify this fact using the following query.

g.V().has('code','AUS').out().count()

59

If we wanted to count how many places we could go to from Austin with one stop, we could use the following query. The dedup step is used as we only want to know how many unique places we can go to, not how many different ways of getting to all of those places there are.

g.V().has('code','AUS').out().out().dedup().count()

865

There is however a problem with this query. The 865 places is going to include (some or possibly all of) the places we can also get to non stop from Austin. What we really want to find are all the places that you can only get to from Austin with one stop. So what we need is a way to remember all of those places and remove them from the 865 some how. This is where aggregate is useful. Take a look at the modified query below

g.V().has('code','AUS').out().aggregate('nonstop').
     out().where(without('nonstop')).dedup().count()

806

After the first out step. all of the vertices that were found are stored in a collection I chose to call nonstop. Then, after the second out we can add a where step that essentially says "only keep the vertices that are not part of the nonstop collection". We still do the dedup step as otherwise we will still end up counting a lot of the remaining airports more than once.

Notice that 806 is precisely 59 less than the 865 number returned by the previous query which shows the places you can get to non stop were all correctly removed from the second query. This also tells us there are no flights from Austin to places that you cannot get to from anywhere else!

3.18. Using inject to insert values into a query

Sometimes you may want to add something additional to be returned along with the results of your query. This can be done using the inject step. In the example below, the string ABIA, another acronym commonly used when referring to the Austin Bergstrom International Airport, is injected into the query.

g.V().has('code','AUS').values().inject('ABIA')

If we were to run the query, here is what we would get back

ABIA
US
AUS
12250
Austin
542
KAUS
-97.6698989868164
airport
US-TX
2
30.1944999694824
Austin Bergstrom International Airport

3.19. Using coalesce to see which traversal returns a result

Sometimes, when you are uncertain as to which traversal of a set you are interested in will return a result you can have them evaluated in order by the coalesce step. The first of the traversals that you specify that returns a result will cause that result to be the one that is returned to your query.

Look at the example below. Starting from the vertex with an ID of 3 it uses coalesce to first see if there are any outgoing edges with a label of fly. If there are any the vertices connected to those edges will be returned. If there are not any, any vertices on any incoming edges labelled contains will be returned.

// Return the first step inside coalesce that returns a node
g.V(3).coalesce(out('fly'),__.in('contains')).valueMap()

As there are not any edges labelled fly in the air-routes graph, the second traversal will be the one whose results are returned.

If we were to run the above query using the air-routes graph, this is what would be returned.

[code:[NA],type:[continent],desc:[North America]]
[code:[US],type:[country],desc:[United States]]

We can put more than two traversals inside of a coalesce step. In the following example there are now three. Because some contains edges do exist for this vertex, the route edges will not be looked at as the traversals are evaluated in left to right order.

g.V(3).coalesce(out('fly'),
              __.in('contains'),
                out('route')).valueMap()

As we can see the results returned are still the same.

[code:[NA],type:[continent],desc:[North America]]
[code:[US],type:[country],desc:[United States]]

3.19.1. Combining coalesce with a constant value

The coalesce step can also be very useful when combined with a constant value. In the example below if the airport is in Texas then its description is returned. If it is not in Texas, the string "Not in Texas" is returned instead.

g.V(1).coalesce(has('region','US-TX').values('desc'),constant("Not in Texas"))

Not in Texas

g.V(3).coalesce(has('region','US-TX').values('desc'),constant("Not in Texas"))

Austin Bergstrom International Airport

A bit later in the "Using coalesce to only add a vertex if it does not exist" section we will again use coalesce to check to see if a vertex already exists before we try to add it.

3.20. Other ways to explore vertices and edges using both, bothE, bothV and otherV

We have already looked at examples of how you can walk a graph and examine vertices and edges using steps such as out, in, outE and inE. In this section we introduce some additional ways to explore vertices and edges.

As a quick recap, we have already seen examples of queries like the one below that simply counts the number of outgoing edges from the node with an ID of 3.

g.V(3).outE().count()

59

Likewise, this query counts the number of incoming edges to that same node.

g.V(3).inE().count()

61

The following query introduces the bothE step. What this step does is return all of the edges connected to this node whether they are outgoing or incoming. As we can see the count of 120 lines up with the values we got from counting the number of outgoing and incoming edges. We might want to retrieve the edges, as a simple example, to examine a property on each of them.

g.V(3).bothE().count()

120

If we wanted to return vertices instead of edges, we could use the both step. This will return all of the vertices connected to the node with an ID of 3 regardless of whether they are connected by an outgoing or an incoming edge.

g.V(3).both().count()

120

This next query can be used to show us the 120 vertices that we just counted in the previous query. I sorted the results and used fold to build them into a list to make the results easier to read. Note how vertex 3 is not returned as part of the results. This is important, for as we shall see in a few examples time, this is not always the case.

g.V(3).both().order().by(id).fold()

[v[1],v[1],v[4],v[4],v[5],v[5],v[6],v[6],v[7],v[7],v[8],v[8],v[9],v[9],v[10],v[10],v[11],v[11],v[12],v[12],v[13],v[13],v[15],v[15],v[16],v[16],v[17],v[17],v[18],v[18],v[20],v[20],v[21],v[21],v[22],v[22],v[23],v[23],v[24],v[24],v[25],v[25],v[26],v[26],v[27],v[27],v[28],v[28],v[29],v[29],v[30],v[30],v[31],v[31],v[34],v[34],v[35],v[35],v[38],v[38],v[39],v[39],v[41],v[41],v[42],v[42],v[45],v[45],v[46],v[46],v[47],v[47],v[49],v[49],v[52],v[52],v[136],v[136],v[147],v[147],v[149],v[149],v[178],v[178],v[180],v[180],v[182],v[182],v[183],v[183],v[184],v[184],v[185],v[185],v[186],v[186],v[187],v[187],v[188],v[188],v[190],v[190],v[273],v[273],v[278],v[278],v[389],v[389],v[416],v[416],v[430],v[430],v[549],v[549],v[929],v[929],v[1274],v[1274],v[3591],v[3605]]

You probably also noticed that most of the vertices appear twice. This is because for most air routes there is an outgoing and an incoming edge. If we wanted to eliminate any duplicate results we can do that by adding a dedup step to our query.

g.V(3).both().dedup().order().by(id).fold()

[v[1],v[4],v[5],v[6],v[7],v[8],v[9],v[10],v[11],v[12],v[13],v[15],v[16],v[17],v[18],v[20],v[21],v[22],v[23],v[24],v[25],v[26],v[27],v[28],v[29],v[30],v[31],v[34],v[35],v[38],v[39],v[41],v[42],v[45],v[46],v[47],v[49],v[52],v[136],v[147],v[149],v[178],v[180],v[182],v[183],v[184],v[185],v[186],v[187],v[188],v[190],v[273],v[278],v[389],v[416],v[430],v[549],v[929],v[1274],v[3591],v[3605]]

We can do another count using our modified query to check we got the expected number of results back.

g.V(3).both().dedup().count()

61

There are a similar set of things we can do when working with edges using the bothV and otherV steps. The bothV step returns the vertices at both ends of an edge and the otherV step returns the vertex at the other end of the edge. This is relative to how we are looking at the edge.

The query below starts with our same node with the ID of 3 and then looks at all the edges no matter whether they are incoming or outgoing and retrieves all of the vertices at each end of those edges using the bothV step. Notice that this time our count is 240. This is because for every one of the 120 edges, we asked for the node at each end so we ended up with 240 of them.

g.V(3).bothE().bothV().count()

240

We can again add a dedup step to get rid of duplicate vertices as we did before and re-do the count but notice this time we get back 62 instead of the 61 we got before. So what is going on here?

g.V(3).bothE().bothV().dedup().count()

62

Let’s run another query and take a look at all of the vertices that we got back this time.

g.V(3).bothE().bothV().dedup().order().by(id()).fold()

[v[1],v[3],v[4],v[5],v[6],v[7],v[8],v[9],v[10],v[11],v[12],v[13],v[15],v[16],v[17],v[18],v[20],v[21],v[22],v[23],v[24],v[25],v[26],v[27],v[28],v[29],v[30],v[31],v[34],v[35],v[38],v[39],v[41],v[42],v[45],v[46],v[47],v[49],v[52],v[136],v[147],v[149],v[178],v[180],v[182],v[183],v[184],v[185],v[186],v[187],v[188],v[190],v[273],v[278],v[389],v[416],v[430],v[549],v[929],v[1274],v[3591],v[3605]]

Can you spot the difference? This time, vertex 3 (v[3]) is included in our results. This is because we started out by looking at all of the edges and then asked for all the vertices connected to those edges. Vertex 3 gets included as part of that computation. So beware of this subtle difference between using both and the bothE().bothV() pattern.

Let’s rewrite the queries we just used again but replace bothV with otherV. Notice that when we count the number of results we are back to 61 again.

g.V(3).bothE().otherV().dedup().count()
61

So let’s again look at the returned vertices and see what the difference is.

g.V(3).bothE().otherV().dedup().order().by(id()).fold()

[v[1],v[4],v[5],v[6],v[7],v[8],v[9],v[10],v[11],v[12],v[13],v[15],v[16],v[17],v[18],v[20],v[21],v[22],v[23],v[24],v[25],v[26],v[27],v[28],v[29],v[30],v[31],v[34],v[35],v[38],v[39],v[41],v[42],v[45],v[46],v[47],v[49],v[52],v[136],v[147],v[149],v[178],v[180],v[182],v[183],v[184],v[185],v[186],v[187],v[188],v[190],v[273],v[278],v[389],v[416],v[430],v[549],v[929],v[1274],v[3591],v[3605]]

As you can see, when we use otherV we do not get v[3] returned as we are only looking at the other vertices relative to where we started from, which was v[3].

3.21. Shortest paths (between airports) - introducing repeat

Gremlin provides a repeat…​until looping construct similar to those found in many programming languages. This gives us a nice way to perform simple shortest path type queries. We can use a repeat…​until loop to look for paths between two airports without having to specify an explicit number of out steps to try.

While performing such computations, we may not want paths we have already travelled to be travelled again. We can ask for this behavior this using the simplePath step. Doing so will speed up queries that do not need to travel the same paths through a graph multiple times. Without the simplePath step being used the query we are about to look at could take a lot longer. The addition of a limit step is also important as without it this query will run for a LONG time looking for every possible path!!

The query below looks for routes between Austin (AUS) and Agra (AGR). An important query for those Austinites wanting to visit the Taj Mahal!

// What are some of the ways to travel from AUS to AGR?
g.V().has('code','AUS').repeat(out().simplePath()).
                        until(has('code','AGR')).path().by('code').limit(10)

Here are the results from running the query. Notice how, using the repeat…​until construct we did not have to specify how many steps to try.

[AUS,YYZ,BOM,AGR]
[AUS,LHR,BOM,AGR]
[AUS,FRA,BOM,AGR]
[AUS,EWR,BOM,AGR]
[AUS,YYZ,ZRH,BOM,AGR]
[AUS,YYZ,BRU,BOM,AGR]
[AUS,YYZ,MUC,BOM,AGR]
[AUS,YYZ,ICN,BOM,AGR]
[AUS,YYZ,CAI,BOM,AGR]
[AUS,YYZ,ADD,BOM,AGR]

You can also place the repeat before the until as shown below.

// Another shortest path example using until...repeat instead
g.V().has('code','AUS').until(has('code','SYD')).
                        repeat(out().simplePath()).limit(10).path().by('code')

Here are the results from running the query.

[AUS,DFW,SYD]
[AUS,LAX,SYD]
[AUS,SFO,SYD]
[AUS,YYZ,HND,SYD]
[AUS,YYZ,ICN,SYD]
[AUS,YYZ,SCL,SYD]
[AUS,YYZ,AUH,SYD]
[AUS,YYZ,TPE,SYD]
[AUS,YYZ,CAN,SYD]
[AUS,YYZ,DFW,SYD]

We can also specify an explicit number of out steps to try using a repeat…​times loop but this of course assumes that we know ahead of time how many stops we want to look for between airports.

g.V().has('code','AUS').repeat(out()).times(2).has('code','SYD').path().by('code')

[AUS,DFW,SYD]
[AUS,LAX,SYD]
[AUS,SFO,SYD]

The previous query is equivalent to this next one but doing it this way is less flexible in that we can not as easily vary the number of out steps, should, for example we want to next try five hops instead of the current two..

g.V().has('code','AUS').out().out().has('code','SYD').path().by('code')

A bit later, in the Using emit to return results during a traversal section, we will look at how emit can be used to adjust the behavior of a repeat…​times loop.

3.21.1. A warning that path can be memory and CPU intensive

The path step is incredibly useful and I find myself using it a lot. However, there are some downsides to the use of path, especially when searching entire graphs for non trivial results. Take a look at the query below. It returns the first 10 routes found that will get you from Papa Stour (PSV), a small airport in the Shetland Islands, to Austin (AUS). The simplePath step is used to make sure the same exact path is never looked at twice. This query runs quickly and returns some useful results.

g.V().has('code','PSV').repeat(out().simplePath()).until(has('code','AUS')).
      limit(10).path().by('code')

[PSV,LWK,FIE,KOI,EDI,JFK,AUS]
[PSV,LWK,FIE,KOI,EDI,EWR,AUS]
[PSV,LWK,FIE,KOI,EDI,LHR,AUS]
[PSV,LWK,FIE,KOI,EDI,FRA,AUS]
[PSV,LWK,FIE,KOI,GLA,JFK,AUS]
[PSV,LWK,FIE,KOI,GLA,MCO,AUS]
[PSV,LWK,FIE,KOI,GLA,EWR,AUS]
[PSV,LWK,FIE,KOI,GLA,PHL,AUS]
[PSV,LWK,FIE,KOI,GLA,YYZ,AUS]
[PSV,LWK,FIE,KOI,GLA,LHR,AUS]

However, were we to reverse the query as follows we can run into trouble. In fact, if you run this query on your laptop, after a few minutes of high CPU usage and increased fan noise, it is likely you will get an error that the query ran out of available memory.

g.V().has('code','AUS').repeat(out().simplePath()).until(has('code','PSV')).
      limit(10).path().by('code')

The reason this happens is as follows. There are very few routes from PSV and not many more from the airports it is closely connected to. Therefore, if you start the query from PSV, you will fairly quickly find some paths that end up in AUS. However, if you start from AUS there are a lot of possible routes that Gremlin has to explore before it gets close to finding PSV. If it helps, think of a funnel where PSV is at the narrow end and AUS is at the other.

Note
The path step uses a lot of memory and in some cases can cause issues.

The reason that so much memory is consumed is that the path step, even if simplePath is used to avoid travelling the same path twice, has to store up a very large number of routes before finding the ones we are actually interested in. So while the path step is incredibly useful, be aware that in cases like this one, it can get you into trouble if not used with care.

3.22. Calculating node degree

While working with graphs, the word degree is used when discussing the number of edges coming into a node, going out from a node or potentially both coming in and going out. It’s quite simple with Gremlin to calculate various measures of degree as the examples below show.

// Out degree (number of routes) from each node (airport)
g.V().out().groupCount().by('code')

// what is the out degree (number of unique outbound routes) from LHR, JFK and DFW?
 g.V().hasLabel('airport').out().groupCount().by('code').select('LHR','JFK','DFW')

// Calculate degree (in and out) for each node (so counts edges going both ways)
// Note the project() step was introduced in gremlin 3.2 and is ideal for this!
g.V().hasLabel('airport').limit(10).project("v","degree").by('code').by(bothE().count())

// We could also write the same query like this.
g.V().hasLabel('airport').limit(10).group().by('code').by(bothE().count())

3.23. More examples using what we have covered so far

The queries in this section build upon the topics that we have covered so far.

// Which cities can I fly to from any airport in the Hawaiian islands?
g.V().has('airport','region','US-HI').out().path().by('city')

// Find all the airports that are in Europe (The graph stores continent information
// as "contains" edges connected from a "continent" node to each airport node.
g.V().has('continent','code','EU').out('contains').values('code').order().fold()

The next queries show two ways of finding airports with 6 or more runways.

g.V().where(values('runways').is(gte(6))).values('code')

g.V().has('runways',gte(6)).values('code')

Next, let’s look at two ways of finding flights from airports in South America to Miami. The first query uses select which is what we would have had to do in the TinkerPop 2 days. The second query, which feels cleaner to me, uses the path and by step combination introduced in TinkerPop 3.

g.V().has('continent','code','SA').out().as('x').out().as('y').
      has('code','MIA').select('x','y').by('code')

g.V().has('continent','code','SA').out().out().
      has('code','MIA').path().by('code')

This query finds the edge that connects Austin (AUS) with Dallas Ft. Worth (DFW) and returns the dist property of that edge so we know how far that journey is.

// How far is it from DFW to AUS?
g.V().has('code','DFW').outE().as('a').inV().has('code','AUS').select('a').values('dist')

190

As an alternative approach, we could return a path that would include both airport codes and the distance. Notice how we need to use outE and inV rather than just out as we still need the edge to be part of our path so that we can get its dist property using a by step.

g.V().has('code','DFW').outE().inV().has('code','AUS').path().by('code').by('dist')

[DFW,190,AUS]

If we wanted to find out if there are any ways to get from Brisbane to Austin with only one stop, this query will do nicely!

// Routes from BNE to AUS with only one stop
g.V().has('code','BNE').out().out().has('code','AUS').path().by('code')

[BNE,LAX,AUS]

This is another way of doing the same thing but, once again, to me using path feels more concise. The only advantage of this query is that if all you want is the name of any intermediate airports then that’s all you get!

g.V().has('code','BNE').out().as('stop').
                        out().has('code','AUS').select('stop').values('code')

LAX

A common thing you will find yourself doing when working with a graph is counting things. This next query looks for all the airports that have less than five outgoing routes and counts them. It does this by counting the number of airports that have less than five outgoing edges with a route label. There are a surprisingly high number of airports that offer this small number of destinations.

// Airports with less than 5 outgoing edges
g.V().hasLabel('airport').where(out('route').count().is(lt(5))).count()

2058

In a similar vein this query finds the airports with more than 200 outgoing routes. The second query shows that where is a synonym for filter in many cases.

g.V().hasLabel("airport").where(outE('route').count().is(gt(200))).values('code')

g.V().hasLabel("airport").filter(outE("route").count().is(gt(200))).values('code')

Here are two more queries that look for things that meet a specific criteria. The first finds routes where the distance is exactly 100 miles. The second one looks for the airports that have an elevation above 10,000 feet.

// List ten (or less) routes where the distance is exactly 100 miles
g.V().as('a').outE().has('dist',eq(100)).limit(10).inV().as('b').
      select('a','b').by('code')

// Airports above 10,000ft sorted by ascending elevation
g.V().has('airport','elev', gt(10000)).
      order().by('elev',incr).valueMap('city','elev')

The next query finds any routes between Austin and Sydney that only require one stop.The by step offers a clean way of doing this query by combining it with path.

g.V().has('code','AUS').out().out().has('code','SYD').path().by('code')

The following three queries all achieve the same result. They find flights from any airport in Africa to any airport in the United States. These queries are intresting as the continent information is represented in the graph as edges connecting an airport node with a continent node. This is about as close as Gremlin gets to a SQL join statement!

The first query starts by looking at airports the second starts from the node that represents Africa. The third query uses where to show an alternate way of achieving the same result.

g.V().hasLabel('airport').as('a').in('contains').has('code','AF').
      select('a').out().has('country','US').as('b').select('a','b').by('code')

g.V().hasLabel('continent').has('code','AF').out().as('a').
      out().has('country','US').as('b').
      select('a','b').by('code')

g.V().hasLabel('airport').where(__.in('contains').has('code','AF')).as('a').
      out().has('country','US').as('b').select('a','b').by('code')

If we run the query we should get results that look like this. I have laid them out in two columns to save space.

[a:JNB, b:ATL]    [a:ACC, b:JFK]
[a:JNB, b:JFK]    [a:CMN, b:IAD]
[a:CAI, b:JFK]    [a:CMN, b:JFK]
[a:ADD, b:IAD]    [a:GCK, b:DFW]
[a:ADD, b:EWR]    [a:DKR, b:IAD]
[a:LOS, b:ATL]    [a:DKR, b:JFK]
[a:LOS, b:IAH]    [a:LFW, b:EWR]
[a:LOS, b:JFK]    [a:RAI, b:BOS]
[a:ACC, b:IAD]

The query below shows how to use the project step that was introduced in TinkerPop 3, along with order and select to produce a sorted table of airports you can fly to from AUSTIN along with their runway counts. The limit step is used to only return the top ten results. You will find several examples elsewhere in this document that use variations of this collection of steps.

g.V().has('code','AUS').out().project('ap','rw').by('code').by('runways').
      order().by(select('rw'),decr).limit(10)

Here are the results we get from running the query.

[ap:ORD, rw:8]
[ap:DFW, rw:7]
[ap:BOS, rw:6]
[ap:DEN, rw:6]
[ap:DTW, rw:6]
[ap:YYZ, rw:5]
[ap:MDW, rw:5]
[ap:ATL, rw:5]
[ap:IAH, rw:5]
[ap:FRA, rw:4]

4. BEYOND BASIC QUERIES

So far we have looked mostly at querying the graph. In the following sections we will look at some other topics that it is also important to be familiar with when working with Gremlin such as mixing in some Groovy or Java code with your queries, adding vertices (vertices),and edges and properties to a graph and also how to delete them. We will also look at how to create a sub-graph and how to save a graph to and XML or JSON file.

4.1. A word about layout and indentation

As you begin to write more complex Gremlin queries they can get quite lengthy. In order to make them easier for others to read it is recommended to spread them over multiple lines and indent them in a way that makes sense. I am not going to propose an indentation standard, I believe this should be left to personal preference however there are a few things I want to mention in passing. When working with the Gremlin console, if you want to spread a query over multiple lines then you will need to end each line with a backslash character or with a character such as a period or a comma that tells the Gremlin parser that there is more to come.

The following example shows the query we already looked at in the Boolean operations section of this document but this time edited so that it could be copy and pasted directly into the Gremlin console.

g.V().hasLabel('airport').has('region',within('US-TX','US-LA','US-AZ','US-OK'))   \
                         .order().by('region',incr)   \
                         .valueMap().select('code','region')

We can avoid the use of backslash characters if we lay the query out as follows. Each line ends with a period which tells the parser that there are more steps coming.

g.V().hasLabel('airport').has('region',within('US-TX','US-LA','US-AZ','US-OK')).
                          order().by('region',incr).
                          valueMap().select('code','region')

If we do not give the parser one of these clues that there is more to come, the Gremlin console will try and execute each line without waiting for the next line.

Whether you decide to use the backslash as a continuation character or leave the period on the previous line is really a matter of personal preference. Just be sure to do one or the other if you want to use multiple line queries within the Gremlin console.

4.2. A warning about reserved word conflicts and collisions

Most of the time the issue I am about to describe will not be a problem. However, there are cases where names of Gremlin steps conflict with reserved words and method names in Groovy. Remember that Gremlin is coded in Groovy and Java. If you hit one of these cases, often the error message that you will get presented with does not make it at all clear that you have run into this particular issue. Let’s look at some examples. One step name in Gremlin that can sometimes run into this naming conflict is the in step. However, you do not have to worry about this in all cases. First take a look at the following query.

g.V().has('code','AUS').in()

That query does not cause an error and correctly returns all of the vertices that are connected by an incoming edge, to the AUS node. There is no conflict of names here because it is clear that the in() reference applies to the result of the has step. However, now take a look at this query.

g.V().has('code','AUS').union(in(),out())

In this case the in() is on it’s own and not dot connected to a previous step. The Gremlin runtime (which remember is written in Groovy) will try to interpret this and will throw an error because it thinks this is a reference to its own in method. To make this query work we have to adjust the syntax slightly as follows.

g.V().has('code','AUS').union(__.in(),out())

Notice that I added the "__." (underscore underscore period) in front of the in(). This is shorthand for "the thing we are currently looking at", so in this case, the result of the has step.

There are currently not too many Groovy reserved words to worry about. The three that you have to watch out for are in, not and as which have special meanings in both Gremlin and Groovy. Remember though, you will only need to use the "__." notation when it is not clear what the reserved word, like in, applies to.

You will find an example of not being used with the "__." prefix in the "Modelling an ordered binary tree as a graph" section a bit later on.

4.3. Thinking about your data model

As important as it is to become good at writing effective Gremlin queries, it is equally important, if not more so, to put careful consideration into how you model your data as a graph. Ideally you want to arrange your graph so that it can efficiently support the most common queries that you foresee it needing to handle.

Consider this query description. "Find all flight routes that exist between airports anywhere in the continent of Africa and the United States". When putting the air-routes graph together I decided to model continents as their own vertices. So each of the seven continents has a node. Each node is connected to airports within that continent by an edge labeled "contains".

I could have chosen to just make the continent a property of each airport node but had I done that, to answer the question about "routes starting in Africa" I would have to look at every single airport node in the graph just to figure out which continent contained it. By giving each continent it’s own node I am able to greatly simplify the query we need to write.

Take a look at the query below. We first look just for vertices that are continents. We then only look at the Africa node and the connections it has (each will be to a different airport). By starting the query in this way, we have very efficiently avoided looking at a large number of the airports in the graph altogether. Finally we look at any routes from airports in Africa that end up in the United States. This turns out to yield a nice and simple query in no small part because our data model in the graph made it so easy to do.

// Flights from any Airport in Africa to any airport in the United States
g.V().hasLabel('continent').has('code','AF').out().as('a')
     .out().has('country','US').as('b').select('a','b').by('code')

We could also have started our query by looking at each airport and looking to see if it is in Africa but that would involve looking at a lot more vertices. The point to be made here is that even if our data model is good we still need to always be thinking about the most efficient way to write our queries.

// Gives same results but not as efficient
g.V().hasLabel('airport').as('a').in('contains').has('code','AF')
     .select('a').out().has('country','US').as('b').select('a','b').by('code')

Now for a fairly simple graph, like air-routes, this discussion of efficiency is perhaps not such a big deal, but as you start to work with large graphs, getting the data model right can be the difference between good and bad query response times. If the data model is bad you won’t always be able to work around that deficiency simply by writing clever queries!

4.3.1. Keeping information in two places within the same graph

Sometimes, to improve query efficiency I find it is actually worth having the data available more than one place within the same graph. An example of this in the air routes graph would be the way I decided to model countries. I have a unique node for each country but I also store the country code as a property of each airport node. In a small graph this perhaps is overkill but I did it to make a point. Look at the following two queries that return the same results - the cities in Portugal that have airports in the graph.

g.V().has('country','code','PT').out("contains").values('city')

g.V().has('airport','country','PT').values('city')

The first query finds the country node for Portugal and then, finds all of the countries connected to it. The second query looks at all airport vertices and looks to see if they contain PT as the country property.

In the first example it is likely that a lot less vertices will get looked at than the first even though a few edges will also get walked as there are over 3,000 airport vertices but less than 300 country vertices. Also, in a production system with an index in place finding the Portugal node should be very fast.

Conversely, if we were already looking at an airport node for some other reason and just wanted to see what country it is in, it is more convenient to just look at the country property of that node.

So there is no golden rule here but it is something to think about while designing your data model.

4.3.2. Using a graph as an index into other data sources

While on the topic of what to keep in the graph, something to resist being drawn into in many cases is the desire to keep absolutely everything in the graph. For example, in the air routes graph I do not keep every single detail about an airport (radio frequencies, runway names, weather information etc.) in the airport vertices. That information is available in other places and easy to find. In a production system you should consider carefully what needs to be in your graph and what more naturally belongs elsewhere. One thing I could do is add a URL as a property of each airport node that points to the airports home page or some other resource that has all of the information. In this way the graph becomes a high quality index into other data sources. This is a common and useful pattern when working with graphs. This model of having multiple data sources working together is sometimes referred to as Polyglot storage.

4.3.3. A few words about supernodes

When a node in a graph has a large number of edges and is disproportionately connected to many of the other vertices in the graph it is likely that many, if not all, graph traversals of any consequence will include that node. Such vertices (nodes) are often referred to as supernodes. In some cases the presence of supernodes may be unavoidable but with careful planning as you design your graph model you can reduce the likelihood that nodes become supernodes. The reason we worry about supernodes is that they can significantly impact the performance of graph traversals. This is because it is likely that any graph traversal that goes via such a node will have to look at most if not all of the edges connected to that node as part of a traversal.

The air-routes graph does not really have anything that could be classed as a supernode. The node with the most edges is the continent node for North America that has approximately 980 edges. The busiest airports are IST and AMS and they both have just over 530 total edges. So in the case of the air-routes graph we do not have to worry too much.

If we were building a graph of a social network that included famous people we might have to worry. Consider some of the people on Twitter with millions of followers. Without taking some precautions, such a social network, modelled as a graph, could face issues.

As you design your graph model it is worth considering that some things are perhaps better modelled as a node property than as a node with lots of edges needing to connect to it. For example in the air routes graph there are country vertices and each airport is connected to one of the country vertices. In the air routes graph this is not a problem as even if all of the airports in the graph were in the same country that would still give us less than 3,500 edges connected to that node. However, imagine if we were building a graph of containing a very large number of people. If we had several million people in the graph all living in same the country that would be a guaranteed way to get a supernode if we modelled that relationship by connecting every person node to a country node using a lives in edge. In such situations, it would be far more sensible to make the country where a person lives a property of their own node.

A detailed discussion of supernode mitigation is beyond the scope of this document but I encourage you to always be thinking about their possibility as you design your graph and also be thinking about how you can prevent them becoming a big issue for you.

4.4. Making Gremlin even Groovier

As we have already discussed, the Gremlin console builds upon the Groovy console, and Groovy itself is coded in Java. This means that all of the classes and methods that you would expect to have available while writing Groovy or Java programs are also available to you as you work with the Gremlin Console. You can intermix additional features from Groovy and Java classes along with the features provided by the TinkerPop 3 classes as needed. This capability makes Gremlin additionally powerful. You can also take advantages of these features when working with Gremlin Server over HTTP and with other TinkerPop based Graph services like IBM Graph with the caveat that some features may be blocked if viewed as a potential security risk to the server.

Every Gremlin query we have demonstrated so far is also, in reality, valid Groovy. We have already shown examples of storing values into variables and looping using Groovy constructs as part of a single or multi part Gremlin query.

In this section we are going to go one step further and actualaly define some methods, using Groovy syntax, that can be run while still inside the Gremlin Console. By way of a simple example, let’s define a method that will tell us how far apart two airports are and then invoke it.

// A simple function to return the distance between two airports
def dist(g,from,to) {
  d=g.V().has('code',from).outE().as('a').inV().has('code',to)
         .select('a').values('dist').next()
  return d }

// Can be called like this
dist(g,'AUS','MEX')

This next example shows how to define a slightly longer method that prints out information about the degree of a node in a nice, human readable, form.

// Groovy function to display node degree
def degree(g,s) {
  v = g.V().has('code',s).next();
  o=g.V(v).out().count().next();
  i=g.V(v).in().count().next() ;
  println "Edges in  : " + i;
  println "Edges out : " + o;
  println "Total     : " +(i+o);
}

// Can be called like this
degree(g,'LHR')

Here is an example that shows how we can query the graph, get back a list of values and then use a for loop to display them. Notice this time how we initially store the results of the query into the variable x. The call to toList ensures that x will contain a list (array) of the returned values.

// Using a Groovy for() loop to iterate over a list returned by Gremlin
x=g.V().hasLabel('airport').limit(10).toList()
for (a in x) {println(a.values('code').next()+" "+a.values('icao').next()+" "+a.values('desc').next())}

// We can also do this just using a 'for' loop and not storing anything into a variable.
for (a in g.V().hasLabel('airport').limit(10).toList()) {println(a.values('code').next()+""+a.values('icao').next())}

Sometimes (as you have seen above) it is necessary to make a call to next to get the result you expect returned to your variable.

number = g.V().hasLabel('airport').count().next()
println "The number of airports in the graph is " + number

Here is another example that makes a Gremlin query inside a for loop.

for (a in 1..10) print g.V().has(id,a).values('code').next()+" "

This example returns a hash of vertices, with node labels as the keys and the code property as the values. It then uses the label names to access the returned hash.

a=g.V().group().by(label).by('code').next()
println(a["country"].size())
println(a["country"][5])
println(a["airport"][2])

Here is another example. This time we define a method that takes as input a traversal object and the code for an airport. It then uses those parameters to run a simple Gremlin query to retrieve all of the places that you can fly to from that airport. It then uses a simple for loop to print the results in a table. Note the use of next as part of the println. This is needed in order to get the actual values that we are looking for. If we did not include the calls to next we would actually get back the iterator object itself and not the actual values.

// Given a traversal and an airport code print a list of all the places you can
// fly to from there including the IATA code and airport description.
def from(g,a) {
  places=g.V().has('code',a).out().toList();
  for (x in places) {println x.values('code').next()+" "+x.values('desc').next()}
}

// Call like this
from(g,'AUS')

This example creates a hash map of all the airports, using their IATA code as the key. We can then access the map using the IATA code to query information about those airports. Remember that the ;[] at the end of the query just stops the console from displaying unwanted output.

// Create a map (a) of all vertices with the code property as the key
a=g.V().group().by('code').next();[]

// Show the description stored in the JFK node
a['JFK'][0].values('desc')

Another useful way to work with veriables is to establish the variable and then use the fill step to place the results of a query into it. The example below creates an empty lisy called german. The query then finds all the vertices for airports located in Germany and uses the fill step to place them into the variable.

german = []
g.V().has('airport','country','DE').fill(german)

We can then use our list as you would expect. Remember that as we are running inside the Gremlin console we do not have to explicitly iterate through the list as you would if you were writing a stand alone Groovy application.

// How many results did we get back?
german.size

32

// Query some values from one of the airports in the list
german[0].values('city','code')

FRA
Frankfurt

// Feed an entry from our list back into a traversal
g.V(german[1]).values('city')

Munich

g.V(german[1]).out().count()

237

Towards the end of the document, in the "Working with TinkerGraph from a Groovy application" section, we will explore writing some stand alone Groovy code that can use the TinkerPop API and issue Gremlin queries while running outside of the Gremlin Console as a stand alone application.

4.4.1. Using a variable to feed a traversal

Sometimes it is very useful to store the result of a query in a variable and then, later on, use that variable to start a new traversal. You may have noticed we did that in the very last example of the prior section where we fed the german variable back in to a traversal. By way of another simple example, the code below stores the result of the first query in the variable austin and then uses it to look for routes from Austin in second query. Notice how we do this by passing the variable containing the Austin vertex into the V() step.

 austin=g.V().has('code','AUS').next()
 g.V(austin).out()

You can take this technique one step further and pass an entire saved list of vertices to V(). In the next example we first generate a list of all airports that are in Scotland and then pass that entire list into V() to first of all count how many routes there are from those airports and then we start another query that looks for any route from those airports to airports in Germany.

// Find all airports in Scotland
a=g.V().hasLabel('airport').has('region','GB-SCT').toList()

// How many routes from these airports?
g.V(a).out().count()

// How many of those routes end up in Germany?
g.V(a).out().has('country','DE').values('code')

In this example of using with variables to drive traversals, we again create a list of airports. This time we find all the airports in Texas. We then use a Groovy each loop to iterate through the list. For each airport in the list we print the code of the starting airport and then the codes of every airport that you can fly to from there.

// Find all of the airports in Texas
texas=g.V().has('region','US-TX').toList()

// For each airport, print a list of all the airports that you can fly to from there.
texas.each {println it.values('code').next() + "===>" +
                    g.V(it).out().values('code').toList()}

This example, which is admittedly a bit contrived, we use a variable inside of a has step. We initially create a list containing all of the IATA codes for each airport in the graph. We then iterate through that list and calculate how many outgoing routes there are from each place and print out a string containing the airport IATA code and the count for that airport.Note that this could easily be done just using a Gremlin query with no additional Groovy code. The point of this example is more to show another example of mixing Gremlin, Groovy and variables. Knowing that you can do this kind of thing may come in useful as you start to write more complicated graph database applications that use Gremlin. You will see this type of query done using just Gremlin in the section called "Finding unwanted parallel edges"" later in this document.

m=g.V().hasLabel('airport').values('code').toList()
for (a in m) println a + " : " + g.V().has('code',a).out().count().next()

Lastly, here is an example that uses an array of values to seed a query.

['AUS','RDU','MCO','LHR','DFW'].
     each {println g.V().has('code','JFK').outE().inV().
                         has('code',it).path().by('code').by('dist').next()}

Here is the output from running the code.

[JFK, 1520, AUS]
[JFK, 427, RDU]
[JFK, 945, MCO]
[JFK, 3440, LHR]
[JFK, 1390, DFW]

4.5. Adding vertices, edges and properties

So far in this document we have largely focussed on loading a graph from a file and running queries against it. As you start to build your own graphs you will not always start with a graph saved as a text file in GraphML, CSV, GraphSON or some other format. You may start with an empty graph and incrementally add vertices and edges. Just as likely you may start with a graph like the air routes graph, read from a file, but want to add vertices, edges and properties to it over time. In this section we will explore various ways of doing just that.

Vertices and edges can be added directly to the graph using the graph object or as part of a graph traversal. We will look at both of these techniques over course of the following pages.

4.5.1. Adding an airport (vertex) and a route (edge)

The following code uses the graph object that we created when we fist loaded the air-routes graph to create a new airport vertex (node) and then adds a route (edge) from it to the existing DFW vertex. We can specify the label name (airport) and as many properties as we wish to while creating the vertex. In this case we just provide three. We can additionally add and delete vertex properties after a vertex has been created. While using the graph object in this way works, it is strongly recommended that the traversal source object g be used instead and that vertices and edges be added using a traversal. Examples of how to do that are coming up next.

// Add an imaginary airport with a code of 'XYZ' and connect it to DFW
xyz = graph.addVertex(label,'airport',
                      'code','XYZ',
                      'icao','KXYZ',
                      'desc','This is not a real airport')

// Find the DFW vertex
dfw = g.V().has('code','DFW').next()

// Create a route from our new airport to DFW
xyz.addEdge('route',dfw)

In many cases it is more convenient, and also recommendd, to perform each of the previous operations using just the traversal object g. The following example does just that. We first create a new aiport vertex for our imaginary airport and store it’s vertex in the variable xyz. We can then use that stored value when we create the edge also using a traversal. As with many parts of the Gremlin language, there is more than one way to achieve the same results.

// Add an imaginary airport with a code of 'XYZ' and connect it to DFW
xyz = g.addV('airport').property('code','XYZ').
                        property('icao','KXYZ').
                        property('desc','This is not a real airport').next()

Notice, in the code above, how each property step can be chained to the previous one when adding multiple properties. Whether you need to do it while creating a node or to add and edit properties on a node at a later date you can use the same property step.

Note
It is strongly recommended that the traversal source object g be used when adding, updating or deleting vertices and edges. Using the graph object directly is not viewed as a TinkerPop best practice.

We can now add a route from DFW to XYZ. We are able to use our xyz variable to specify the destination of the new route using a to step and wrapping the variable inside of a V step.

// Add a route from DFW to XYZ
g.V().has('code','DFW').addE('route').to(V(xyz))

We could have written the previous line like this if we had not previously saved anything in a variable.

g.V().has('code','DFW').addE('route').to(V().has('code','XYZ'))

We might also want to add a returning route from XYZ back to DFW. We can do this using the from step in a similar way as we used the to step above.

// Add the return route back to DFW
g.V().has('code','DFW').addE('route').from(V(xyz))

Another way that we could have chosen to create our edge is by naming things using as steps. Note also there is more than one way to define the direction of an edge. Two examples are shown below. One uses the addOutE step and the other uses the outE and to combination. Notice also how the V step was used below to essentially start a new traversal midway through the current one.

g.V().has('code','XYZ').as('a').V().has('code','DFW').addOutE('route','a')

g.V().has('code','XYZ').as('a').V().has('code','DFW').addE('route').to('a')

You will see a bigger example that uses as to name steps in the "Quickly building a graph for testing" section that is coming up soon.

4.5.2. Using a traversal to seed a property with a list

You can use the results of a traversal to create or update properties. The example below creates a new property called places for the Austin airport vertex. The values of the property are the results of finding all of the places that you can travel to from that airport and folding their code values into a list.

// Add a list as a property value
g.V().has('code','AUS').property('places',out().values('code').fold())

We can use a valueMap step to make sure the property was created as we expected it to be. As you can see a new property called places has been created containing as it’s value a list of codes.

g.V().has('code','AUS').valueMap('places')

[places:[[YYZ, LHR, FRA, MEX, PIT, PDX, CLT, CUN, MEM, CVG, IND, MCI, DAL, STL, ABQ, MDW, LBB, HRL, GDL, PNS, VPS, SFB, BKG, PIE, ATL, BNA, BOS, BWI, DCA, DFW, FLL, IAD, IAH, JFK, LAX, MCO, MIA, MSP, ORD, PHX, RDU, SEA, SFO, SJC, TPA, SAN, LGB, SNA, SLC, LAS, DEN, MSY, EWR, HOU, ELP, CLE, OAK, PHL, DTW]]]

To gain access to these values from your code or Gremlin console queries, we can use the next step. A simple example is given below where values is used to retrieve the values of the places property and then we use size to see how many entries there are in the list.

g.V().has('code','AUS').values('places').next().size()

59

Once we have access to the list of values we can access them using the normal Groovy array syntax. The example below returns the three values with an index between 2 and 4.

g.V().has('code','AUS').values('places').next()[2..4]

FRA
MEX
PIT

4.5.3. Quickly building a graph for testing

Sometimes for testing and for when you want to report a problem or ask for help on a mailing list it is handy to have a small stand alone graph that you can use. The code below will create a mini version of the air routes graph in the Gremlin Console. Note how all of the vertices and edges are created in a single query with each step joined together.

graph=TinkerGraph.open()
g=graph.traversal()
g.addV(label,'airport','code','AUS').as('aus').
  addV(label,'airport','code','DFW').as('dfw').
  addV(label,'airport','code','LAX').as('lax').
  addV(label,'airport','code','JFK').as('jfk').
  addV(label,'airport','code','ATL').as('atl').
  addE('route').from('aus').to('dfw').
  addE('route').from('aus').to('atl').
  addE('route').from('atl').to('dfw').
  addE('route').from('atl').to('jfk').
  addE('route').from('dfw').to('jfk').
  addE('route').from('dfw').to('lax').
  addE('route').from('lax').to('jfk').
  addE('route').from('lax').to('aus').
  addE('route').from('lax').to('dfw')

4.5.4. Adding vertices and edges using a loop

Sometimes it is more efficient to define the details of the vertices or edges that you plan to add to the graph in an array and then add each node or edge using a simple for loop that iterates over it. The following example adds our imaginary airports directly to the graph using such a loop. Notice that we do not have to specify the ID that we want each vertex to have. The graph will assign a unique ID to each new node for us.

vertices = [["WYZ","KWYZ"],["XYZ","KXYZ"]]
for (a in vertices) {graph.addVertex(label,"airport","code",a[0],"iata",a[1])}

We could also have added the vertices using the traversal object g as follows. Notice the call to next(). Without this the node creation will not work as expected.

vertices = [["WYZ","KWYZ"],["XYZ","KXYZ"]]
for (a in vertices) {g.addV("airport").property("code",a[0],"iata",a[1]).next()}

This technique of creating vertices and/or edges using a for loop can also be useful when working with graphs remotely over HTTP connections. It is a very convenient way to combine a set of creation steps into a single REST API call.

If you prefer a more Groovy like syntax you can also do this.

vertices = [["WYZ","KWYZ"],["XYZ","KXYZ"]]
vertices.each {g.addV("airport").property("code",it[0],"iata",it[1]).next()}

4.5.5. Using coalesce to only add a vertex if it does not exist

In the Combining coalesce with a constant value section we looked at how coalesce could be used to return a constant value if the other entities that we were looking for did not exist. We can reuse that pattern to produce a traversal that will only add a vertex to the graph if that vertex has not already been created.

Let’s assume we wanted to add a new airport, with the code "XYZ" but we are not sure if the airport might have already been added.

We can check to see if the airport exists, using a basic has step.

g.V().has('code','XYZ')

If it does not exist yet, which in this case it does not, noting will be returned. We could go one step further and change the query to return an empty list [] if the airport does not exist by adding a fold step to the query.

g.V().has('code','XYZ').fold()

[]

Now that we have a query that can return an empty list if a vertex does not exist we can take advantage of this in a coalesce step. The query below looks to see if the airport already exists and passes the result of that into a coalesce step. Remember, coalesce will return the result of the first traversal it looks at that returns a good result. We can make the first parameter passed to coalesce and unfold step. This way in the case where the airport does not exist, unfold will return nothing and so coalesce will attempt the second step. In this case our second step creates a vertex for the airport "XYZ".

g.V().has('code','XYZ').fold().coalesce(unfold(),addV().property('code','XYZ'))

v[53865]

As you can see the query above created a new vertex with an ID of 53865 as the XYZ airport did not already exist. However, if we run the same query again, notice that we get the same vertex back that we just created and not a new one. This is because this time, the coalesce step does find a result from the unfold step and so completed before attempting the addV step.

g.V().has('code','XYZ').fold().coalesce(unfold(),addV().property('code','XYZ'))

v[53865]

Using coalesce in this way provides us with a nice pattern for a commonly performed task of checking to see if something already exists before we create it.

4.6. Deleting vertices, edges and properties

So far in this document we have looked at several examples where we created new vertices, edges and properties but we have not yet looked at how we can delete them. Gremlin provides the drop step that we can use to remove things from a graph.

4.6.1. Deleting a node

In some of our earlier examples we created a fictitious airport node with a code of XYZ and added it to the air routes graph. If we now wanted to delete it we could use the following Gremlin code. Note that removing the node will also remove any edges we created connected to that node.

// Remove the XYZ node
g.V().has('code','XYZ').drop()

4.6.2. Deleting an edge

We can also use drop to remove specific edges. The following code will remove the flights, in both directions between AUS and LHR.

// Remove the flight from AUS to LHR  (both directions).
g.V().has('code','AUS').outE().as('e').inV().has('code','LHR').select('e').drop()
g.V().has('code','LHR').outE().as('e').inV().has('code','AUS').select('e').drop()

4.6.3. Deleting a property

Lastly, we can use drop to delete a specific property value from a specific node. Let’s start by querying the properties defined by the air-routes graph for the San Francisco airport.

g.V().has('code','SFO').valueMap()

[country:[US],code:[SFO],longest:[11870],city:[San Francisco],elev:[13],icao:[KSFO],lon:[-122.375],type:[airport],region:[US-CA],runways:[4],lat:[37.6189994812012],desc:[San Francisco International Airport]]

Let’s now drop the desc property and re-query the property values to prove that it has been deleted.

g.V().has('code','SFO').properties('desc').drop()

g.V().has('code','SFO').valueMap()

[country:[US],code:[SFO],longest:[11870],city:[San Francisco],elev:[13],icao:[KSFO],lon:[-122.375],type:[airport],region:[US-CA],runways:[4],lat:[37.6189994812012]]

If we wanted to delete all of the properties currently associated with the SFO airport node we could do that as follows.

g.V().has('code','SFO').properties().drop()

4.6.4. Removing all the edges or vertices in the graph

This may not be something you want to do very often, but should you wish to remove every edge in the graph you could do it, using the traversal object, g, as follows. Note that for very large graphs this may not be the most efficient way of doing it depending upon how the graph store handles this request.

// Remove all the edges from the graph
g.E().drop()

You could also use the graph object to do this. The code below uses the graph object to retrieve all of the edges and then iterates over them dropping them one by one. Again for very large graphs this may not be an ideal approach is this requires reading all of the edge definitions into memory. Note that in this case we call the remove method rather than use drop as we are not using a graph traversal in this case.

// Remove all the edges from the graph
graph.edges().each{it.remove()}

You could also delete the whole graph, vertices and edges, by deleting all of the vertices!

// Delete the entire graph!
g.V().drop()

4.7. Property keys and values revisited

We have already looked, earlier in the document, at numerous queries that retrieve, create or manipulate in some way the value of a given property. There are still however a few things that we have not covered in any detail concerning properties. Most of the property values we have looked at so far have been simple types such as a String or an Integer. In this section we shall look more closely at properties and explain how they can in fact be used to store lists and sets of values. We will also introduce in this section the concept of a property ID.

4.7.1. The Property and VertexProperty interfaces

In a TinkerPop 3 enabled graph, all properties are implementations of the Property interface. Vertices implement the VertexProperty interface which itself implements Property. These interfaces are documented as part of the Apache TinkerPop 3 JavaDoc. The interface defines the methods that you can use when working with a vertex property object in your code. One important thing to note about vertex properties is that they are immutable. You can create them but once created they cannot be updated.

We will look more closely at the Java interfaces that TinkerPop 3 defines in the "Working with TinkerGraph from Java Application" section a bit later in this document.

The VertexProperty interface does not define any "setter" methods beyond the basic constructor itself. Your immediate reaction to this is likely to be "but I know you can change a property’s value using the property step". Indeed we have already discussed doing just that in this document. However, behind the scenes, what actually happens when you change a property, is that a new property object is created and used to replace the prior one. We will examine this more in a minute but first let’s revisit a few of the basic concepts of properties.

In a property graph both vertices and edges can contain one or more properties. We have already seen a query like the one below that retrieves the values from each of the property keys associated with the DFW airport node.

g.V().has('airport','code','DFW').values()

US
DFW
13401
Dallas
607
KDFW
-97.0380020141602
airport
US-TX
7
32.896800994873
Dallas/Fort Worth International Airport

What we have not mentioned so far, however, is that the previous query is a shortened form of this one.

g.V().has('airport','code','DFW').properties().value()

US
DFW
13401
Dallas
607
KDFW
-97.0380020141602
airport
US-TX
7
32.896800994873
Dallas/Fort Worth International Airport

If we wanted to retrieve the VertexProperty (vp) objects for each of the properties associated with the DFW node we could do that too. In a lot of cases it will be sufficient just to use values or valueMap to access the values of one or more properties but there are some cases, as we shall see when we look at property IDs, where having access to the vertex property object itself is useful.

g.V().has('airport','code','DFW').properties()

vp[country->US]
vp[code->DFW]
vp[longest->13401]
vp[city->Dallas]
vp[elev->607]
vp[icao->KDFW]
vp[lon->-97.0380020141602]
vp[type->airport]
vp[region->US-TX]
vp[runways->7]
vp[lat->32.896800994873]
vp[desc->Dallas/Fort Worth In]

We have already seen how each property on a vertex or edge is represented as a key and value pair. If we wanted to retrieve a list of all of the property keys associated with a given vertex we could write a query like the one below that finds all of the property keys associated with the DFW vertex in the air-routes graph.

g.V().has('airport','code','DFW').properties().key()

country
code
longest
city
elev
icao
lon
type
region
runways
lat
desc

We could likewise find the names, with duplicates removed, of any property keys associated with any outgoing edges from the DFW vertex using this query. Note that edge properties are implementations of Property and not VertexProperty.

g.V().has('code','DFW').outE().properties().key().dedup()

dist

We can use the fact that we now know how to specifically reference both the key and value parts of any property to construct a query like the one below that adds up the total length of all the longest runway values and number of runways in the graph and groups them by property key first and sum of the values second.

g.V().hasLabel("airport").properties("runways","longest").
                          group().by(key).by(value().sum())

[longest:25497644, runways:4816]

4.7.2. The propertyMap traversal step

We have previously used the valueMap step to produce a map of key/value pairs for all of the properties associated with a node or edge. There is also a propertyMap step that can be used that yields a similar result but the map includes the vertex property objects for each property.

g.V().has('code','AUS').propertyMap()
[country:[vp[country->US]], code:[vp[code->AUS]], longest:[vp[longest->12250]], city:[vp[city->Austin]], lon:[vp[lon->-97.6698989868164]], type:[vp[type->airport]], places:[vp[places->[YYZ, LHR, FRA, MEX,]], elev:[vp[elev->542]], icao:[vp[icao->KAUS]], region:[vp[region->US-TX]], runways:[vp[runways->2]], lat:[vp[lat->30.1944999694824]], desc:[vp[desc->Austin Bergstrom Int]]]

4.7.3. Properties have IDs too

We have seen many examples already that show how both vertices and edges have a unique ID. What may not have been obvious however is that properties also an ID. Unlike node and edge IDs property IDs are not guaranteed to be unique across the graph. Certainly with TinkerGraph I have encountered cases where a node and a property share the same ID. This is not really an issue because they are used in different ways to access their associated graph element.

The query below returns the vertex property object (vp) for any property in the graph that has a value of London.

g.V().properties().hasValue('London')
vp[city->London]
vp[city->London]
vp[city->London]
vp[city->London]
vp[city->London]
vp[city->London]

At first glance, each of the values returned above looks identical. However, let’s now query their ID values.

g.V().properties().hasValue('London').id()

583
595
1051
1123
2467
7783

As you can see each property has a different, and unique, ID. We can use these ID values in other queries in the same way as we have for vertices and edges in some of our earlier examples.

g.V().properties().hasId(583)

vp[city->London]

We can query the value of this property as you would expect.

g.V().properties().hasId(583).value()

London

We can retrieve the name of the property key as follows.

g.V().properties().hasId(583).key()

city

We could also have used label instead of key

g.V().properties().hasId(583).label()

city

We can also find out which element (node or edge) that this property belongs to.

g.V().properties().hasId(583).next().element()

v[49]

We can also look at other property values of the element containing our property with an ID of 583.

g.V().properties().hasId(583).next().element().values('desc')

London Heathrow

Should you need to you can also find out which graph this property is part of. In this case it is part of a TinkerGraph.

g.V().has('airport','code','DFW').properties('city').next().graph()

tinkergraph[vertices:3619 edges:50148]

To further show that each property has an ID the following code retrieves a list of all the vertex properties associated with vertex V(3) and prints out the property key along with its corresponding ID.

p = g.V(3).properties().toList()
p.each {println it.key + "\t:" + it.id}

country :28
code    :29
longest :30
city    :31
elev    :32
icao    :33
lon     :34
type    :35
region  :36
runways :37
lat     :38
desc    :39
Note
If you update a property, its ID value will also be changed as you have in reality replaced the property with a new one which is allocated a new ID.

Take a look at the example below. First of all we query the ID of the city property from vertex V(4). Next we change its value to be newname and then query the property ID again. Note that the ID has changed. As mentioned above, vertex properties are immutable. When you update a property value using the property step, a new property object is created that replaces the prior one.

g.V(4).properties('city').id()

43

g.V(4).property('city','newname')

g.V(4).properties('city').id()

53361

The fact that every property in a graph has an ID can improve performance of accessing properties, especially in large graphs.

4.7.4. Attaching multiple values (lists or sets) to a single property

A node property value can be a basic type such as a String or an Integer but it can also be something more sophisticated such as a Set or a List containing multiple values. You can think of these values as being an array but depending on how you create them you have to work with them differently. In this section we will look at how we can create multiple values for a single property key. Such values can be setup when the node is first created or added afterwards. These more complex type of property values are not supported on edges.

If we wanted to store the IATA amd ICAO codes for the Austin airport in a list associated with a single property rather than as separate properties we could have created them when we created the Austin node follows. You can also add properties to an existing node that have lists of values. We will look at how to do that later in this section.

g.addV('code','AUS','code','KAUS')

By creating the code property in this way, its cardinality type is now effectively LIST rather than SINGLE. While working with TinkerGraph we do not need to setup explicit schemas for our property types. However, once we start working with a more sophisticated graph system such as Janus Graph, that is something that we will both want and need to be able to do. We cover the topic of cardinality in detail in the "The Janus Graph management API" section later in the document.

Now that we have created the code property to have a list of values we can query either one of the values in the list. If we look at the value map we get back from the following example queries you can see both values in the list we associated with the property code.

g.V().has('code','AUS').valueMap()
[code:[AUS,KAUS]]

g.V().has('code','KAUS').valueMap()
[code:[AUS,KAUS]]

We can also query the values as normal.

g.V().has('code','AUS').values()
AUS
KAUS

We can also use the properties step to get the result back as vertex properties (vp). We discuss vertex properties in detail in the "The Property and VertexProperty interfaces" section.

g.V().has('code','AUS').properties()

vp[code->AUS]
vp[code->KAUS]

For completeness we could also do this.

g.V().properties().hasValue('AUS')

vp[code->AUS]

So now we know how to create a node with property values in a list we need a way to update those properties. We can do this using a special form of the property step where the first paramter is list to show that what follows are updates to the existing list and not replacements for the whole list.

The example below adds another code that is sometimes used when talking about the Austin airport to our list of codes. If we left off the list parameter the whole property would be overwritten with a value of ABIA.

g.V().has('code','AUS').property(list,'code','ABIA')

If we query the properties again we can see that there are now three values for the code property.

g.V().has('code','AUS').properties()
vp[code->AUS]
vp[code->KAUS]
vp[code->ABIA]

We can observe the same thing by looking at our valueMap results again.

g.V().has('code','AUS').valueMap()
[code:[AUS,KAUS,ABIA]]

If we want to delete one of the properties from the list we can do it using drop. If we look the value map after dropping ABIA we can indeed see that it is gone from the list.

g.V().has('code','AUS').properties().hasValue('ABIA').drop()

g.V().has('code','AUS').valueMap()
[code:[AUS,KAUS]]

If we want to drop an entire property containing one or more values we can do it as follows.

g.V().has('code','AUS').properties('code').drop()

To add multiple values to the same property key in the same query we just need to chain the property steps together as shown below.

g.V().has('code','AUS').
      property(list,'desc','Austin Airport').
      property(list,'desc','Bergstrom')

This technique can be used to update an existing property that already has a list of values or to add a new property with a list of values.

The same value can appear more than once with a property that has LIST cardinality. The code fragment below creates a new node, with some duplicate values associated with the dups property.

g.addV(label,'test','dups','one','dups','two','dups','one')

g.V().hasLabel('test').valueMap()

[dups:[one,two,one]]

We can add additional duplicate values after the node has been created.

g.V().hasLabel('test').property(list,'dups','two')

g.V().hasLabel('test').valueMap()

[dups:[one,two,one,two]]

So far we have just created values in a list that have LIST cardinality which means that duplicate values are allowed. If we wanted to prevent that from happening we can use the set keyword when adding properties to force a cardinality of SET.

In the example below we create a new property called hw for vertex V(3) with multiple values but using the set keyword rather than the list keyword that we have used previously. We then look at the valueMap for the hw property to check that inded our set was created.

g.V(3).property(set,'hw',"hello").property(set,'hw','world')

g.V(3).valueMap('hw')

[hw:[hello,world]]

Let’s now test that our set is really working as a set by adding a couple of additional values. Note that we have already added the value hello in the prior steps so with the cardinality being SET we expect that value to be ignored as there is aready a value of hello in the set. We again display the valueMap to prove that the set only has unique values in it.

g.V(3).property(set,'hw',"hello").property(set,'hw','apple')

g.V(3).valueMap('hw')

[hw:[hello,world,apple]]

Note that the other examples we have shown in this section are not the same as just adding a list directly as a property value. In the example below the entire list is treated as a single value.

g.V().has('code','AUS').property('x',['AAAA','BBBB'])

g.V().has('code','AUS').valueMap('x')

[x:[[AAAA,BBBB]]]

4.7.5. Adding properties to other properties (meta properties)

TinkerPop 3 introduced the ability to add a property to another property. Think of this in a way as being able to add a bit of metadata about a property to the property itself. This capability, not surprisingly, is often referred to as "adding a meta property to a property". There are a number of use cases where this capability can be extremely useful. Common ones might be adding a date that a property was last updated or perhaps adding access control information to a property.

The example below adds a meta property with a key of date and a value of 6/6/2017 to the property with a key of code and a value of AUS.

g.V().has('code','AUS').properties().hasValue('AUS').property('date','6/6/2017')

If you wanted to add the date to the code property regardless of its current value, then you could just do this.

g.V().has('code','AUS').properties('code').property('date','6/6/2017')

We can retrieve all of the meta properties on a specific property, such as the code property as follows.

g.V().has('code','AUS').properties('code').properties()

p[date->6/6/2017]

If you want to find all the properties associated with the AUS vertex that have a meta property with a date of 6/6/2017 you can do that as follows.

g.V().has('code','AUS').properties().has('date','6/6/2017')

vp[code->AUS]

We can query for a specific meta property as follows, which will return any meta properties that have a key of date.

g.V().has('code','AUS').properties().hasValue('AUS').properties('date')

p[date->6/6/2017]

You can add multiple meta properties to a property while creating it. The following will add a property called comment to vertex V(3) and also add two meta properties to it representing the date the comment was made and who made it.

g.V(3).property('comment','I like this airport','date','6/6/2017','user','Kelvin')

We can query the graph to make sure everything worked as expected.

g.V(3).properties('comment')

vp[Comment->I like this airport]

g.V(3).properties('comment').properties()

p[date->6/6/2017]
p[user->Kelvin]

You can use drop to remove meta properties but take care when doing so. Take a look at the query below, which looks like it might drop the meta property date, but will in fact drop whole node.

g.V().has('code','AUS').properties().hasValue('AUS').property('date','6/6/2017').drop()

To remove a single meta property we need to use drop in this way

 g.V().has('code','AUS').properties('code').properties('date').drop()

Note that you cannot chain meta properties together endlessly. The main properties on a node are VertexProperty types. The meta property is a Property type and you cannot add another property to those. You can however add more than one meta property to the same vertex property.

So as mentioned above, the meta property provides a way to attach metadata to another property. This enables a number of important use cases including being able to attach a date or ACL information to individual properties.

4.8. Using Lambda functions

Gremlin allows you to put a code fragment (sometimes called a Lambda function or a closure) as part of a query. This is typically done as part of a filter or sideEffect step but there are other places where you wll find this concept used. This technique provides a lot of additional flexibility in how queries can be written. However, care should be used. When processing your query, Gremlin wil try to optimize it as best as it can. For regular traversal steps such as out and has Gremlin will do this optimization for you. However for closures (code inside braces {}) Gremlin cannot do this and will just pass the closure on to the underlying runtime. With people just getting started with Gremlin there is a great temptation to over use in-line code. This is a natural thing to want to do as for programmers it feels like the programming they are used to. However, there is often, if not always, a pure Gremlin traversal step that can be used to do what is needed. Of course with all rules there are exceptions. Here is an example of a closure being used where a has step could and should have been used instead.

// What airports are located in London?
g.V().hasLabel('airport').filter{it.get().property('city').value() =="London"}

Here is the same query just using the has() step. This is a case where we should not be using a lambda function as Gremlin can handle this just fine all by itself.

// What airports are located in London?
g.V().hasLabel('airport').has('city','London')

I think you will agree that the second version is a lot simpler to read and enables Gremlin to do its thing.

For completeness, here is an example of a query that contains a sideEffect step. The main part of the query finds airports with 6 runways and counts them. That result will still be returned but the side effect will also cause the codes of those airports to also be printed. This is a bit of a contrived example but it shows how sideEffect behaves.

// Example of the 'sideEffect' step
g.V().has('runways',6).sideEffect{print it.get().values('code').next()+" "}.count()
Tip
The moral here is, avoid closures unless you can genuinely find no other way to achieve what you need. It is fair I think to observe that sometimes coming up with a closure to do what you want is easier than figuring out the pure Gremlin way to do it but if at all possible using just Gremlin steps is still the recommended path to take. Lambda functions in general are discouraged.

4.8.1. Introducing the Map step

The map step will be familiar to users of programming languages such as Ruby, Python or indeed Groovy. It is often useful to be able to take a set of results, or in the case of Gremlin, the current state of a graph traversal, and modify it in some way before passing on those results to the next part of the traversal. This is what the map step allows us to do.

Take a look at the query below. It simply returns us a list containing the IDs of the first ten airports in the graph.

g.V().hasLabel('airport').limit(10).id().fold()

[1,2,3,4,5,6,7,8,9,10]

Let’s say we wanted to write a query, similar to the one above, that will modify each of those IDs returned in the query above by adding one to each. Take a look at the query below. We have introduced a map step. The map step takes as a parameter a closure (or lambda) function telling it how we want it to operate on the values flowing in to it. The it is Groovy syntax for "the thing that came in" (in this case a traversal). The get is needed to gain access to the current vertex and its properties. Lastly we get the id of the vertex and add one to it. The modified values are then passed on to the next step of the traversal where they are made into a list by the fold step. gg

g.V().hasLabel('airport').limit(10).map{it.get().id() + 1}.fold()

[2,3,4,5,6,7,8,9,10,11]
Note
This is an area where Groovy and Java have a similar but different syntax. If you wanted to use the query above in a Java program you would need to use the Java lambda function syntax.

What is nice about the map step is that it allows us to do within the query itself what we would otherwise have to do after the query was over using a for each type of loop construct.

One other thing to note about the map step is that the closure provided can have multiple steps, separated by semi-colons. The following query demonstrates this.

g.V().hasLabel('airport').limit(10).map{a=1;b=2;c=a+b;it.get().id() + c}.fold()

[4,5,6,7,8,9,10,11,12,13]

Note that only the value from the last expression in the closure is returned from the map. So in the example above the result of c=a+b, 4, is added to each ID.

In the next section we will take a look at some other cases where lambda expressions are very useful.

4.8.2. Using regular expressions to do fuzzy searches

Let’s take a look at one case where use of closures might be helpful. It is a common requirement when working with any kind of database to want to do some sort of fuzzy text search or even to search using a regular expression. TinkerPop 3 itself does not provide direct support for this. In other words there currently is no sophisticated text search method beyond the basic has() type steps we have looked at above. However, the underlying graph store can still expose such capabilities.

Note
Most TinkerPop enabled graph stores that you are likely to use for any sort of serious deployment will also be backed by an indexing technology like Solr or Elastic Search and a graph engine like Titan. In those cases some amount of more sophisticated search methods will likely be made available to you. You should always check the documentation for the system you are using to see what is recommended.

When working with Tinkergraph and the Gremlin console if we want to do any sort of text search beyond very basic things like city == "Dallas" then we will have to fall back on the Lambda function concept to take advantage of underlying Groovy and Java features. Note that even in graph systems backed by a real index the examples we are about to look at should still work but may not be the preferred way.

So let’s look at some examples. First of all, every airport in the air routes graph contains a description which will be something like Dallas Fort Worth International Airport in the case of DFW. If we wanted to search the vertices in the graph for any airport that has the word Dallas in the description we could take advantage of the Groovy String.contains() method and do it like this.

// Airport descriptions containing the word 'Dallas'
g.V().hasLabel('airport').filter{it.get().property('desc').value().contains('Dallas')}

Where things get even more interesting is when you want to use a regular expression as part of a query. Note that the first example below could also be achieved using a Gremlin within() step as it is still really doing exact string comparisons but it gives us a template for how to write any query containing a regular expression. The example that follows finds all airports in cities with names that begin with Dal so it will find Dallas, Dalaman, Dalian, Dalcahue, Dalat and Dalanzadgad!.

// Using a filter to search using a regular expression
g.V().has('airport','type','airport').filter{it.get().property('city').value ==~/Dallas|Austin/}.values('code')

// A regular expression to find any airport with a city name that begins with "Dal"
g.V().has('airport','type','airport').filter{it.get().property('city').value()==~/^Dal\w*/}.values('city')

So in summary it is useful to know about closures and the way you can use them with filters but as stated above - use them sparingly and only when a "pure Gremlin" alternative does not present itself.

Note
We could actually go one step further and create a custom predicate (see next section) that handles regular expressions for us.

4.9. Creating custom tests (predicates)

TinkerPop comes with a set of built in methods that can be used for testing values. These methods are commonly referred to as predicates. Examples of existing Gremlin predicates include methods like gte(), lte() and neq(). Sometimes, however, it is useful to be able to define your own custom predicate that can be passed in to a has(), where() or filter() step as part of a Gremlin query.

The following example uses the Groovy closure syntax to define a custom predicate, called f, that tests the two values passed in to see if x is greater than twice y. This new predicate can then be used as part of a has() step by using it as a parameter to the test() method. When f is called, it will be passed two parameters. The first one will be the value returned in response to asking has() to return the property called longest. The second parameter passed to f will be the value of a that we provide. This is a simple example, but shows the flexibility that Gremlin provides for extending the basic predicates.

// Find the average longest runway length.
a = g.V().hasLabel('airport').values('longest').mean().next()

// Define a custom predicate
f = {x,y -> x > y*2}

// Find airports with runways more than twice the average maximum length.
g.V().hasLabel('airport').has('longest',test(f,a)).values('code')

4.9.1. Creating a regular expression predicate

In the previous section we used a closure to filter values using a regular expression. Now that we know how to create our own predicates we could go one step further and create a predicate that accepts regular expressions for us.

// Create our method
f = {x,y -> x ==~ y}

// Use it to find any vertices where the description string starts with 'Dal'
g.V().has('desc',test(f,/^Dal.*/)).values('desc')

We can actually go one step further and create a custom method called regex rather than use the test method directly. If the following code seems a bit unclear don’t worry too much. It works and that may be all you need to know. However if you want to understand the TinkerPop API in more detail the documentation that can be found on the Apache TinkerPop web page explains things like P in detail. Also remember that Gremlin is written in Groovy/Java and we take advantage of that here as well.

In the following example, rather than use test directly we use the BiPredicate functional interface that is part of Java 8. BiPredicate is sometimes referred to was a two-arity predicate as it takes two parameters. We will create an implementation of the interface called bp. The interface requires that we provide one method called test that does the actual comparison between two objects and returns a simple true or false result. Like we did in the previous section we simply perform a regular expression compare using the ==~ operator.

We can then use our bp implementation to build a named closure that we will call regex. TinkerPop includes a predicate class P that is an implementation of the Java Predicate functional interface. We we can use P to build our new regex method. We can then pass regex directly to steps like has.

// Create a new BiPredicate that handles regular expression pattern matching
bp = new java.util.function.BiPredicate<String, String>() {
         boolean test(String val, String pattern) {
           return val ==~ pattern  }}

// Create a new closure we can use for regular expression pattern matching.
regex = {new P(bp, it)}

// Use our new closure to find descriptions that start with 'Dal'. As this
// unwinds, the contents of 'desc' are passed to the test method as the first parameter
// and the regex pattern as the second paramter.
g.V().has('desc', regex(/^Dal.*/)).values('desc')

4.10. Using graph variables to associate metadata with a graph

TinkerPop 3 introduced the concept of graph variables. A graph variable is a key/value pair that can be associated with the graph itself. Graph variables are not considered part of the graph that you would process with Gremlin traversals but are in essence a way to associate metadata with a graph. You can set and retrieve graph variables using the variables method of the graph object. Let’s assume I wanted to add some metadata that allowed me to record who the maintainer of the air-routes graph is and when it was last updated. We could do that as follows.

graph.variables().set('maintainer','Kelvin')
graph.variables().set('updated','July 18th 2017')

You can use any string that makes sense to you when naming your graph variable keys. We can use the keys method to retrieve the names of any keys currently in place as graph variables.

graph.variables().keys()

updated
maintainer

The asMap method will return any graph variables that are currently set as a map of key/value pairs.

graph.variables().asMap()

updated=July 18th 2017
maintainer=Kelvin

We can use the get method to retrieve the value of a particular key. Note that the value returned is an instance of the java.util.Optional class.

graph.variables().get('updated')

Optional[July 18th 2017]

If you want to delete a graph variable you can use the remove method. In this next example we will delete the maintainer graph variable and re-query the variable map to prove it has been deleted.

graph.variables().remove('maintainer')
graph.variables().asMap()

updated=July 18th 2017

4.11. Turning node values into trees

TinkerPop defines a Tree API but it is not that well fleshed out and has not been updated in a long time. The tree step allows you to create a tree from part of a graph using a Gremlin traversal. The example below creates a tree, of depth 3, where the Austin (AUS) node is the root of the tree. The next level of the tree is all vertices directly connected to AUS. The third level is made up of all the vertices connected by routes to the vertices in the previous level.

//Generate a tree the AUS node and it's neighbors and their neighbors
 t=g.V().has('code','AUS').repeat(out()).times(2).tree().by('code').next()

The object returned to our variable t will be an instance of the org.apache.tinkerpop.gremlin.process.traversal.step.util.Tree class. That class provides a set of methods that can be used when working with a Tree.

// Look at part of the tree directly
t['AUS']['DFW']

// You can also use the TinkerPop Tree API to work with the tree
t.getLeafObjects()
t.getObjectsAtDepth(1)
t.getObjectsAtDepth(1)
t.getObjectsAtDepth(2)

We will see the Tree API used again in the "Modelling an ordered binary tree as a graph" section later on.

4.12. Creating a sub graph

You can create a sub graph which is a subset of the vertices and edges in the main graph. Once created, to work with a sub graph, you create a traversal specific to that new graph and distinct from the trversal being used to process the main graph. Subgraphs are created using the subgraph traversal step. Note that subgraph takes edges (not vertices) as input and returns both those edges and the vertices that they connect with.

// Create a subgraph of all vertices and edges directly connected to the AUS node
// Note that using bothE() means we get incoming and outgoing edges.
subg = g.V().has('code','AUS').bothE().subgraph('subGraph').cap('subGraph').next()

// As above but only keep the outgoing edges in the subgraph.
subg = g.V().has('code','AUS').outE().subgraph('subGraph').cap('subGraph').next()

// Create a subgraph starting at AUS but this time going out two levels. We achieve this
// using a repeat() method to go out from Austin 2 times.
subg = g.V().has('code','AUS').repeat(__.bothE().subgraph('subGraph').outV()).times(2)
                              .cap('subGraph').next()

// Get a traversal object so that we can traverse the newly created sub graph
sgt = subg.traversal(standard())

// Which airports ended up in the sub graph?
sgt.V().hasLabel('airport').values('code')

In this second example we create a subgraph just of airports and routes that are inside Europe. Effectively we just made the Europe only version of the air routes main graph. At first glance, this query looks a bit overwhelming but if you read it slowly and look at each step you should be able to make sense of what it is doing. It is a bit more sophisticated that the previous examples in that as well as extracting the routes and airports into the subgraph it also extracts all of the relevant countries as well.

// Create a sub graph only of airports in Europe and routes between those airports
subgraph = g.V().hasLabel('continent').has('code','EU')
                .outE('contains').subgraph('eu-air-routes').inV().as('a')
                .inE('contains').subgraph('eu-air-routes')
                .outV().hasLabel('country')
                .select('a').outE().as('r').inV().hasLabel('airport').in().hasLabel('continent')
                .has('code','EU').select('r').subgraph('eu-air-routes')
                .cap('eu-air-routes').next()

// Create a traversal object for the subgraph
sg = subgraph.traversal()

// How many routes are there in the subgraph?
sg.E().hasLabel('route').count()

// How many airports?
sg.V().hasLabel('airport').count()

// Now I can query the subgraph to find out where I can get to from LHR within
// the subgraph.
sg.V().has('code','LHR').out().values('code').join(',')

4.13. Saving (serializing) a graph as GraphML (XML) or GraphSON (JSON)

Using TinkerPop 3 you can save a graph either in GraphML or Graphson format. GraphML is an industry standard XML format for describing a graph and is recognized by many other applications such as Gephi. GraphSON was defined as part of the TinkerPop project and is less broadly supported outside of TinkerPop enabled tools and graphs. However, whereas GraphML is considered lossee for some graphs (it does not support all of the data types and structures used by TinkerPop 3). GraphSON is not considered lossee.

Saving a graph to a GraphML file can be done using the following Gremlin expression. You might want to try it on one of your graphs and look at the output generated. You can also take a look at the air-routes.graphml file distribued with this document if you want to look at a well laid out (for human readability) GraphMl file. Bear in mind that by default, TinkerPop will save your graph in a way that is not easily human readable without using a code beautifier first. Most modern text editors can also beautify XML files well.

// Save the graph as GraphML
graph.io(graphml()).writeGraph('mygraph.graphml')

TinkerPop 3 offers two flavors of JSON. The default flavor stores each vertex in a graph and all of its edges as a single JSON document. This is repeated for every vertex in the graph. This is essentially what is known as adjacency list format. If you serialize a graph to file using this method and look at the file afterwards you will see that each line (which could be very wide) is a stand alone JSON obect.

The second flavor is referred to as a wrapped adjacency list format. In this flavor all of the vertices and edges are stored in a single large JSON oject inside of an enclosing vertices object.

Note
The GraphSON file generated will not be easily human readable without doing some pretty printing on it using something like the Python json tool (python -m json.tool mygraph.json) or using a text editor that can beautify JSON.

The Gremlin line below will create a file containing the adjacency list form of GraphSON.

// Save the graph as unwrapped JSON
graph.io(graphson()).writeGraph("graph.json")

The following will create a file containing the wrapped adjacency list form of GraphSON.

// Create a single (wrapped) JSON file
os = new FileOutputStream("mygraph.json")
GraphSONWriter.build().wrapAdjacencyList(true).create().writeGraph(os,graph)
Tip
If you are ingesting large amounts of data into a TinkerPop 3 enables graph, the unwrapped flavor of GraphSON is probably a much better choice than GraphML or wrapped GraphSON. Using this format you can stream data into a graph one vertex at a time rather than having to try and send the entire graph as a potentially huge JSON file all in one go.

If you want to learn more about the specifics of the GraphML and GraphSON formats, they are covered in detail near the end of this document in the "COMMON GRAPH SERIALIZATION FORMATS" section.

4.14. Loading a graph stored as GraphML (XML) or GraphSON (JSON)

In section 2 we saw how to load the air-routes.graphml file. In case you skipped that part lets do a quick recap on loading GraphML files and also look at loading a GraphSON JSON format file.

The only difference between loading a GraphML file or a GraphSON file is in the name of the method from the IoCore Tinkerpop 3 class that we use. When we want to load a graphML file we specify IoCore.graphml().

// Load a graphML file
graph.io(IoCore.graphml()).readGraph('my-graph.graphml')

If we are loading a GraphSON format file we instead specify IoCore.graphson().

// Load a grapSON file
graph.io(IoCore.graphson()).readGraph('my-graph.json')

5. MISCELLANEOUS QUERIES AND THE RESULTS THEY GENERATE

In this section you will find more Gremlin queries that operate on the air-routes graph. All of these queries build upon the topics already covered in the prior sections. Unlike the prior sections, in this section I have included lots of examples of the output returned by running the query than in the previous sections. In cases where the output is rather lengthy I have either truncated or laid it out in columns to make it easier to read and to save space.

5.1. Counting more things

Here are a few more examples that basically just count occurrences of things but are a little more complex than the examples we looked at earlier in the document.This first query looks for any country vertices that have no outgoing edges. This indicates that there are no airports in the graph for those countries.

// Are there any countries that have no airports?
g.V().hasLabel('country').where(out().count().is(0)).values('desc')

Here are the results of running the query.

Andorra
Liechtenstein
Monaco
Montserrat
Pitcairn
San Marino

We can easily count the distribution per airport of runways. We can observe from the results of running the query that the vast majority of airports in the graph have either one or two runways.

// What is the distribution of runways in the graph
g.V().hasLabel('airport').groupCount().by('runways')

[1:2288, 2:756, 3:224, 4:51, 5:15, 6:4, 7:1, 8:1]

This next query finds all airports that have more than 180 outgoing routes and returns their IATA codes.

// Airports with more than 180 outgoing routes
g.V().hasLabel('airport').where(out('route').count().is(gt(180))).values('code').fold()

[ATL,DFW,IAH,JFK,LAX,ORD,DEN,EWR,LHR,LGW,CDG,FRA,DXB,PEK,PVG,FCO,AMS,BCN,MAD,MUC,DME,IST]

We could improve our query a bit to include the IATA code and the exact number of outgoing routes in the returned result. There are a few different ways that we could do this. One way that is quite convenient is to use group.

// Same basic query but return the airport code and the route count
g.V().where(out('route').count().is(gt(180))).group().by('code').by(out().count())

[ORD:226, DFW:216, FRA:254, CDG:253, PEK:232, AMS:257, ATL:232, MUC:219, IST:259, DME:206, DXB:225]

How many airports are there in each of the UK regions of England, Scotland, Wales and Northern Ireland?

g.V().has('country','code','UK').out('contains').groupCount().by('region')

[GB-ENG:27,GB-WLS:3,GB-NIR:3,GB-SCT:21]

The next query counts how many airports have more than 400 total routes (inbound and outbound).

// Airports with more than 400 total routes
g.V().hasLabel('airport').where(both('route').count().is(gt(400))).values('code')

ATL
ORD
CDG
FRA
PEK
AMS
IST

This next query counts how many airports in the graph only have one outgoing route. There are actually a lot of airports that meet this criteria.

// How many airports have only one route?
g.V().hasLabel('airport').where(out().count().is(eq(1))).count()

This query uses groupCount to produce a map of key value pairs where the key is the two character ISO country code and the value is the number of airports that country has.

// How many airports does each country have in the graph?
g.V().hasLabel('airport').groupCount().by('country')

[PR:6, PT:14, PW:1, PY:2, QA:1, AE:9, AF:4, AG:1, AI:1, AL:1, AM:2, AO:14, AR:36, AS:1, AT:6, RE:2, AU:113, AW:1, AZ:5, RO:13, BA:4, BB:1, RS:2, BD:7, BE:5, RU:115, BF:2, BG:4, RW:2, BH:1, BI:1, BJ:1, BL:1, BM:1, BN:1, BO:15, SA:26, BQ:3, SB:17, BR:115, SC:2, BS:18, SD:5, SE:39, BT:1, SG:1, BW:4, SI:1, BY:1, BZ:13, SK:2, SL:1, SN:3, SO:5, CA:203, SR:1, SS:1, CC:1, CD:11, ST:1, SV:1, CF:1, CG:3, CH:5, SX:1, CI:1, SY:1, SZ:1, CK:6, CL:16, CM:5, CN:179, CO:50, CR:13, TC:4, TD:1, CU:10, CV:7, TG:1, TH:32, CW:1, CX:1, CY:3, TJ:4, CZ:5, TL:1, TM:1, TN:8, TO:1, TR:44, TT:2, DE:32, TV:1, TW:9, TZ:8, DJ:1, DK:8, DM:1, DO:7, UA:13, UG:4, UK:52, DZ:29, US:566, EC:15, EE:3, EG:10, EH:2, UY:2, UZ:11, ER:1, VC:1, ES:41, ET:14, VE:24, VG:2, VI:2, VN:21, VU:26, FI:19, FJ:10, FM:4, FO:1, FR:54, WF:2, GA:2, WS:1, GD:1, GE:3, GF:1, GG:2, GH:5, GI:1, GL:14, GM:1, GN:1, GP:1, GQ:2, GR:39, GT:2, GU:1, GW:1, GY:2, HK:1, HN:6, HR:8, HT:2, YE:9, HU:2, ID:67, YT:1, IE:7, IL:4, IM:1, IN:72, ZA:20, IQ:6, IR:44, IS:5, IT:36, ZM:8, JE:1, ZW:3, JM:2, JO:2, JP:63, KE:14, KG:2, KH:3, KI:2, KM:1, KN:2, KP:1, KR:15, KS:1, KW:1, KY:3, KZ:18, LA:8, LB:1, LC:2, LK:6, LR:2, LS:1, LT:3, LU:1, LV:1, LY:10, MA:14, MD:1, ME:2, MF:1, MG:13, MH:2, MK:1, ML:1, MM:14, MN:10, MO:1, MP:2, MQ:1, MR:3, MT:1, MU:2, MV:8, MW:2, MX:57, MY:34, MZ:10, NA:4, NC:1, NE:1, NF:1, NG:18, NI:1, NL:5, NO:49, NP:10, NR:1, NZ:25, OM:3, PA:4, PE:20, PF:30, PG:26, PH:37, PK:21, PL:12, PM:1]

Because the air-routes graph also has country specific vertices, we could chose to write the previous query a different way. We could start by finding country vertices and then see how many airport vertices each one is connected to.

// Another way to ask the question above, this time by counting the edges (degree) from each country
g.V().hasLabel('country').group().by('code').by(outE().count())

If we wanted to sort the list in descending order we could adjust the query as follows. Note the use of local to specify how the ordering is applied. If we did not use local the ordering would not have the desired effect.

g.V().hasLabel('airport').groupCount().by('country').order(local).by(values,decr)

[US:579,CN:209,CA:203,AU:124,RU:120,BR:115,IN:73,ID:67,JP:63,MX:59,UK:58,FR:58,CO:50,NO:49,TR:48,IR:44,ES:42,SE:39,GR:39,PH:38,AR:36,IT:36,MY:34,DE:33,TH:32,PF:30,DZ:29,SA:26,VU:26,PG:26,NZ:25,VE:24,VN:21,PK:21,FI:20,ZA:20,KZ:20,PE:20,BS:18,NG:18,SB:17,CL:17,BO:15,UA:15,EC:15,KR:15,PT:14,AO:14,RO:14,ET:14,GL:14,KE:14,MA:14,MM:14,BZ:13,CR:13,MG:13,PL:13,CU:12,CD:11,UZ:11,AE:10,EG:10,FJ:10,LY:10,MN:10,MZ:10,NP:10,TW:9,YE:9,TN:8,TZ:8,DK:8,HR:8,ZM:8,LA:8,MV:8,BD:7,CV:7,DO:7,IE:7,PR:6,AT:6,CK:6,HN:6,IQ:6,LK:6,AZ:5,BE:5,SD:5,SO:5,CH:5,CM:5,CZ:5,GH:5,IL:5,IS:5,NL:5,PA:5,AF:4,BA:4,BG:4,BW:4,TC:4,TJ:4,UG:4,FM:4,NA:4,OM:4,BQ:3,SN:3,CG:3,CY:3,EE:3,GE:3,ZW:3,KH:3,KY:3,LT:3,MR:3,PY:2,AM:2,RE:2,RS:2,BF:2,RW:2,SC:2,SH:2,BY:2,SK:2,SY:2,TT:2,EH:2,UY:2,VG:2,VI:2,FK:2,WF:2,GA:2,GG:2,GQ:2,GT:2,GY:2,HT:2,HU:2,JM:2,JO:2,KG:2,KI:2,KN:2,LC:2,LR:2,ME:2,MH:2,MP:2,MU:2,MW:2,PW:1,QA:1,AG:1,AI:1,AL:1,AS:1,AW:1,BB:1,BH:1,BI:1,BJ:1,BL:1,BM:1,BN:1,BT:1,SG:1,SI:1,SL:1,SR:1,SS:1,CC:1,ST:1,SV:1,CF:1,SX:1,CI:1,SZ:1,TD:1,TG:1,CW:1,CX:1,TL:1,TM:1,TO:1,TV:1,DJ:1,DM:1,ER:1,VC:1,FO:1,WS:1,GD:1,GF:1,GI:1,GM:1,GN:1,GP:1,GU:1,GW:1,HK:1,YT:1,IM:1,JE:1,KM:1,KP:1,KS:1,KW:1,LB:1,LS:1,LU:1,LV:1,MD:1,MF:1,MK:1,ML:1,MO:1,MQ:1,MS:1,MT:1,NC:1,NE:1,NF:1,NI:1,NR:1,PM:1]

If we wanted to sort by the country code, the key in other words, we could change the query accordingly. In this case we will use by(keys,incr) to get a sort in ascending order. If we wanted to sort in descending order by key we could use by(keys,decr) instead.

g.V().hasLabel('airport').groupCount().by('country').order(local).by(keys,incr)

[AE:10, AF:4, AG:1, AI:1, AL:1, AM:2, AO:14, AR:36, AS:1, AT:6, AU:118, AW:1, AZ:5, BA:4, BB:1, BD:7, BE:5, BF:2, BG:4, BH:1, BI:1, BJ:1, BL:1, BM:1, BN:1, BO:15, BQ:3, BR:115, BS:18, BT:1, BW:4, BY:1, BZ:13, CA:203, CC:1, CD:11, CF:1, CG:3, CH:5, CI:1, CK:6, CL:17, CM:5, CN:200, CO:50, CR:13, CU:12, CV:7, CW:1, CX:1, CY:3, CZ:5, DE:32, DJ:1, DK:8, DM:1, DO:7, DZ:29, EC:15, EE:3, EG:10, EH:2, ER:1, ES:41, ET:14, FI:20, FJ:10, FK:2, FM:4, FO:1, FR:56, GA:2, GD:1, GE:3, GF:1, GG:2, GH:5, GI:1, GL:14, GM:1, GN:1, GP:1, GQ:2, GR:39, GT:2, GU:1, GW:1, GY:2, HK:1, HN:6, HR:8, HT:2, HU:2, ID:67, IE:7, IL:5, IM:1, IN:72, IQ:6, IR:44, IS:5, IT:36, JE:1, JM:2, JO:2, JP:63, KE:14, KG:2, KH:3, KI:2, KM:1, KN:2, KP:1, KR:15, KS:1, KW:1, KY:3, KZ:18, LA:8, LB:1, LC:2, LK:6, LR:2, LS:1, LT:3, LU:1, LV:1, LY:10, MA:14, MD:1, ME:2, MF:1, MG:13, MH:2, MK:1, ML:1, MM:14, MN:10, MO:1, MP:2, MQ:1, MR:3, MS:1, MT:1, MU:2, MV:8, MW:2, MX:58, MY:34, MZ:10, NA:4, NC:1, NE:1, NF:1, NG:18, NI:1, NL:5, NO:49, NP:10, NR:1, NZ:25, OM:3, PA:5, PE:20, PF:30, PG:26, PH:38, PK:21, PL:13, PM:1, PR:6, PT:14, PW:1, PY:2, QA:1, RE:2, RO:13, RS:2, RU:118, RW:2, SA:26, SB:17, SC:2, SD:5, SE:39, SG:1, SH:2, SI:1, SK:2, SL:1, SN:3, SO:5, SR:1, SS:1, ST:1, SV:1, SX:1, SY:2, SZ:1, TC:4, TD:1, TG:1, TH:32, TJ:4, TL:1, TM:1, TN:8, TO:1, TR:48, TT:2, TV:1, TW:9, TZ:8, UA:14, UG:4, UK:54, US:578, UY:2, UZ:11, VC:1, VE:24, VG:2, VI:2, VN:21, VU:26, WF:2, WS:1, YE:9, YT:1, ZA:20, ZM:8, ZW:3]

Note that we can use select to only return one or more of the full set of key/value pairs returned. Here is an example of doing just that.

// Only return the values for Germany, China, Holland and the US.
g.V().hasLabel('airport').groupCount().by('country').select('DE','CN','NL','US')

[DE:32, CN:179, NL:5, US:566]

We can use a similar query to the one above to find out how many airports are located in each of the seven continents. As you can see from the output, a key/value map is again returned where the key is the continent code and the value is the number of airports in that continent. Note that currently there are no airports with regular scheduled service in Antarctica!

// How many airports are there in each continent?
g.V().hasLabel('continent').group().by('code').by(out().count())

[EU:561, AS:888, NA:959, OC:274, AF:292, AN:0, SA:300]

This next query will, for each airport, return a key value pair where the key is the airport code and the value is the number of outgoing routes from that airport. Because there are over 3,000 in the graph, this query will produce quite a lot of results so I did not try to include them all here. The second query just picks the results from the map for a few airports. Those results are shown.

// How many flights are there from each airport?
g.V().hasLabel('airport').out().groupCount().by('code')

// count the routes from all the airports and then select a few.
g.V().hasLabel('airport').out().groupCount().by('code').select('AUS','AMS','JFK','DUB','MEX')

[AUS:46,AMS:249,JFK:168,DUB:150,MEX:95]

This next query essentially asks the same question about how many outgoing routes each airport has. However rather than return the count for each airports individually it groups the ones with the same number of routes together. As this query returns a lot of data I just included a few lines from the full result below the query.

// Same query except sorted into groups by ascending count
g.V().hasLabel('airport').group().by(out().count()).by('code')

77:[MNL,MLA,SXF],79:[BWI,TLV],80:[BUD,CUN],81:[BOM,RUH],82:[CAI,STR,LPA,LYS,SHJ,BGY], 83:[WAW],84:[JNB,CRL],85:[PHX,MRS,TFS],86:[SYD,LTN,CMN,BHX],87:[SLC,YVR],88:[SZX], 89:[DCA,CKG,XIY],90:[HEL,EDI,GRU,HAM],92:[NCE],93:[AUH],94:[SEA],95:[CGN,MEX,KMG], 97:[YUL],98:[ALC,JED],99:[DEL],100:[PRG,SAW],102:[MCO,GVA],103:[LIS,TPE],105:[FLL,OSL], 106:[BOS,ATH],110:[NRT,TXL,CTU],111:[SFO],112:[KUL,MXP],116:[LED],117:[AGP],120:[ORY], 122:[PHL,BKK,CPH],125:[ARN],126:[IAD],127:[DOH],129:[PMI],132:[MSP,SIN],133:[DTW], 134:[LAS],136:[ICN],140:[VIE],142:[HKG,ZRH,CLT],145:[MIA],147:[SVO],148:[BRU,MAN,DUS], 150:[DUB,CAN],155:[YYZ],156:[STN],157:[PVG],159:[EWR],160:[LAX],163:[FCO],164:[BCN], 166:[MAD],167:[DEN],169:[JFK],170:[IAH],171:[LGW],174:[LHR],187:[DXB],189:[DME], 195:[DFW],196:[MUC],207:[ORD],210:[PEK],218:[ATL],229:[IST],236:[CDG],240:[FRA,AMS]

As the above query returns a lot of data, we can also extract specific values we are interested in as follows:

// Which of these airports have 110 outgoing routes?
g.V().hasLabel('airport').group().by(out().count()).by('code').next().get(110L)

NRT
TXL
CTU
Note
Currently select can only take a string value as the key so we have to use the slightly awkward next().get() syntax to get a numeric key from a result.

5.1.1. Using groupCount with a traversal variable

So far we have just used groupCount with no parameters. When used in that way, groupCount behaves like a map step in that it passes the transformed data on to the next step. However, if you specify the name of a traversal variable as a parameter, the results of the count will be stored in that variable and groupCount will act the same way as a sideEffect would, nothing is passed on from groupCount to the next step. We can use this capability to keep track of things during a query while not actually changing the overall state of the traversal.

The example below starts at the vertex V(3) and goes out from there. A groupCount step is then used to group the vertices we visited by a count of the number of runways each has. We then go out again and count how many vertices we found and save that result in the variable b. Note that the groupCount when used in this way did not pass anything on to the following step. Finally we use select to return our two variables as the results of the query.

g.V(3).out().groupCount('a').by('runways').
       out().count().as('b').select('a','b')

[a:[1:2,2:9,3:17,4:22,5:4,6:3,7:1,8:1],b:5913]

5.1.2. Analysis of routes between Europe and the USA

The next few queries show how you can use a graph like air-routes do perform analysis on a particular industry segment. The following queries analyze the distribution and availability of routes between airports across Europe and airports in the United States.First of all let’s just find out how many total routes there are between airports anywhere in Europe and airports in the USA.

// How many routes from anywhere in Europe to the USA?
g.V().has('continent','code','EU').out().out().has('country','US').count()

345

So we now know that there are 345 different routes. Remember though that the air-routes graph does not track the number of airlines that operate any of these routes. The graph just stores the data that at least one airline operates each of these unique route pairs. Let’s dig a bit deeper into the 345 and find out how many US airports have flights that arrive from Europe.

// How many different US airports have routes from Europe?
g.V().has('continent','code','EU').out().out().has('country','US').dedup().count()

38

So we can now see that the 345 routes from European airports arrive at one of 38 airports in the United States. We can dig a bit deeper and look at the distribution of these routes across the 38 airports. John F. Kennedy airport (JFK) in New York appears to have the most routes from Europe with Newark (EWR) having the second most.

//What is the distribution of the routes amongst those US airports?

g.V().has('continent','code','EU').out().out().has('country','US').
      groupCount().by('code').order(local).by(values,incr)

[PHX:1,CVG:1,RSW:1,BDL:2,SJC:2,BWI:2,AUS:2,RDU:2,MSY:2,SAN:3,TPA:3,SLC:3,PDX:3,PIT:3,SFB:4,DEN:4,OAK:4,DTW:5,FLL:5,SWF:5,MSP:5,CLT:7,DFW:7,SEA:7,PVD:7,IAH:8,MCO:9,LAS:10,ATL:14,SFO:15,PHL:17,IAD:19,ORD:21,BOS:22,LAX:23,MIA:24,EWR:33,JFK:40]

Now let’s repeat the process but looking at the European end of the routes. First of all, we can calculate how many European airports have flights to the United States.

// How many European airports have service to the USA?
g.V().has('continent','code','EU').out().as('a').out().has('country','US').
      select('a').dedup().count()

53

Just as we did for the airports in the US we can figure out the distribution of routes for the European airports. It appears that London Heathrow (LHR) offers the most US destinations and Frankfurt (FRA) the second most.

//What is the distribution of these routes amongst the European airports?
g.V().has('continent','code','EU').out().as('a').out().has('country','US').
      select('a').groupCount().by('code').order(local).by(values,incr)

[RIX:1,TER:1,BRS:1,STN:1,NCE:1,KRK:1,ORK:1,KBP:1,PDL:1,DME:1,BEG:1,AGP:1,HAM:1,OPO:2,STR:2,VCE:2,BHX:2,ORY:2,ATH:2,MXP:3,BFS:3,BGO:3,GVA:3,VKO:3,HEL:3,WAW:4,SVO:4,GLA:4,EDI:5,SNN:5,CGN:5,TXL:6,VIE:6,LIS:6,BRU:7,ARN:7,OSL:8,BCN:9,LGW:9,IST:9,MAD:11,DUS:11,CPH:11,FCO:12,ZRH:13,MAN:13,DUB:14,MUC:16,KEF:17,AMS:18,CDG:21,FRA:24,LHR:27]

Lastly, we can find out what the list of routes flown is. For this example we just return 10 of the 345 routes. Note how the path step returns all parts of the traversal including the continent code EU.

// What are some of these routes?
 g.V().has('continent','code','EU').out().out().has('country','US').path().by('code').limit(10)

[EU,WAW,JFK]
[EU,WAW,LAX]
[EU,WAW,ORD]
[EU,WAW,EWR]
[EU,BEG,JFK]
[EU,IST,ATL]
[EU,IST,BOS]
[EU,IST,IAD]
[EU,IST,IAH]
[EU,IST,JFK]

5.1.3. Using fold to do simple Map-Reduce computations

Earlier in the document we saw examples of sum being used to count a collection of values. You can also use fold to do something similar but in a more map-reduce type of fashion.

First of all, here is a query that uses fold in a way that we have already seen. We find all routes from Austin and use fold to return a nice list of those names.

g.V().has('code','AUS').out('route').values('city').fold()

[Harlingen,Guadalajara,Orlando,Atlanta,Los Angeles,Orlando, New York, Nashville,Boston,Baltimore,Washington D.C.,Dallas, Ft. Lauderdale, Washington D.C.,Houston,Toronto,London,Frankfurt, Mexico City,Pittsburgh, San Diego,Long Beach,Santa Ana,Miami,Minneapolis,Chicago,Phoenix,Seattle, San Francisco,San Jose, Tampa,St Louis,Albuquerque,Chicago,Lubbock,Cleveland,Oakland,Philadelphia,Detroit,Portland,Charlotte,Cancun,Memphis,Cincinnati, Dallas,Salt Lake City,Las Vegas,Denver,New Orleans,Newark,Houston, El Paso]

However, what if we wanted to reduce our results further? Take a look at the modified version of our query below. It finds all routes from Austin and looks at the names of the destination cities. However, rather than return all the names, fold is used to reduce the names to a value. That value being the total number of characters in all of those city names. We have seen fold used elsewhere in the document but this time we provide fold with a parameter and a closure. The parameter is passed to the closure as the first variable and the name of the city as the second. The closure then adds the zero and the length of each name effectively to a running total.

g.V().has('code','AUS').out('route').values('city').fold(0) {a,b -> a + b.length()}

449
Note
While this query will work as-is on TinkerGraph within the Gremlin Console, some graph systems are more strict about their type checking and sandboxing of Groovy closures. To be on the safe side you can always explicitly type cast the closure as follows.
g.V().has('code','AUS').out('route').values('city').
                       fold(0) {a,b -> (int)a + ((String)b).length()}

5.1.4. Distribution of routes in the graph (mode and mean)

An example of a common question we might want to answer with a network graph, of which air routes are an example, is "how are the routes in my graph distributed between airport vertices?". We can also use this same query to find the statistical mode (most common number) for a set of routes.

Take a look at the next query that shows how we can do analysis on the distribution of routes throughout the graph. We are only interested in vertices that are airports and for those vertices we want to count how many outgoing routes each airport has. We want to return the results as a set of odered key:value pairs where the key is the number of outgoing routes and the value is the number of airports that have that number of outgoing routes.

g.V().hasLabel('airport').groupCount().by(out('route').count()).
                          order(local).by(values,decr)

When we run the query we get back the results below. As the results are sorted in descending order by value, we can see that the mode (most common) number of outgoing routes is actually just one route and that 786 airports have just one outgoing route. We can see that 654 airports have just two routes and so on. We can also see at the other end of the scale that one airport has 226 outgoing routes.

[1:770,2:652,3:370,4:236,5:148,6:115,7:94,8:81,9:68,10:61,12:42,11:39,13:38,15:30,19:27,16:26,20:25,22:25,14:20,17:17,18:16,0:15,23:14,31:14,33:14,30:13,21:12,32:12,37:12,35:10,24:9,25:9,39:9,42:9,26:8,29:8,47:8,27:7,34:7,36:7,40:7,44:7,45:7,55:7,63:7,67:7,41:6,48:6,50:6,59:6,60:6,105:6,28:5,38:5,43:5,52:5,54:5,61:5,62:5,64:5,94:5,56:4,68:4,70:4,80:4,74:3,77:3,83:3,84:3,85:3,86:3,93:3,106:3,107:3,124:3,144:3,46:2,53:2,57:2,73:2,76:2,78:2,79:2,82:2,91:2,95:2,97:2,98:2,104:2,109:2,116:2,118:2,146:2,166:2,182:2,192:2,232:2,262:1,269:1,270:1,272:1,49:1,51:1,58:1,65:1,66:1,69:1,71:1,72:1,75:1,81:1,89:1,90:1,92:1,101:1,102:1,108:1,110:1,112:1,113:1,114:1,115:1,119:1,122:1,126:1,127:1,129:1,130:1,132:1,133:1,136:1,137:1,141:1,142:1,143:1,145:1,151:1,153:1,156:1,162:1,163:1,164:1,168:1,175:1,180:1,181:1,186:1,187:1,188:1,189:1,190:1,191:1,197:1,200:1,201:1,214:1,221:1,229:1,234:1,237:1]

We could change our query above, replacing out() with __.in() and we could find out the distribution of incoming routes. Remember, in an air route network there is not always a one to one equivalent number of outgoing to incoming routes due to the way airlines plan their routes.

Another change we could make to our query is to change the ordering to use the key field for each key:value pair and this time sort in ascending order.

g.V().hasLabel('airport').groupCount().by(out('route').count()).
                          order(local).by(keys,incr)

When we run our query again we get the results below. Looking at the data sorted this way helps some new interesting facts stand out. The most interesting thing we can immediately spot is that there are 15 airports that currently have no outgoing routes at all!

[0:15, 1:786, 2:654, 3:361, 4:244, 5:149, 6:110, 7:86, 8:80, 9:67, 10:54, 11:45, 12:40, 13:30, 14:28, 15:28, 16:17, 17:23, 18:17, 19:30, 20:18, 21:13, 22:15, 23:19, 24:10, 25:9, 26:12, 27:7, 28:8, 29:13, 30:12, 31:8, 32:10, 33:9, 34:8, 35:11, 36:6, 37:8, 38:7, 39:11, 40:5, 41:7, 42:10, 43:4, 44:4, 45:2, 46:3, 47:5, 48:2, 49:9, 50:6, 51:4, 52:4, 53:4, 54:6, 55:2, 56:4, 57:4, 58:7, 59:6, 60:7, 61:1, 62:5, 63:2, 64:4, 65:4, 66:4, 67:2, 69:3, 70:2, 71:1, 72:3, 74:2, 75:1, 76:3, 77:2, 78:3, 79:1, 80:1, 81:3, 82:2, 83:4, 84:4, 85:2, 86:3, 87:1, 88:1, 89:1, 91:2, 92:4, 93:2, 94:1, 95:1, 96:1, 97:3, 99:2, 100:4, 101:1, 102:1, 103:3, 104:1, 105:1, 106:1, 108:2, 109:1, 110:1, 111:1, 112:1, 115:2, 117:1, 118:1, 119:2, 121:1, 123:1, 125:1, 127:1, 128:2, 129:1, 132:1, 134:3, 140:1, 141:1, 142:3, 146:1, 148:1, 149:1, 153:1, 154:1, 155:1, 157:1, 158:1, 159:1, 166:1, 172:1, 174:2, 176:2, 178:1, 182:1, 183:2, 184:1, 186:1, 191:2, 197:1, 206:1, 216:1, 219:1, 225:1, 226:1, 232:2, 254:2, 257:1, 259:1]

If we wanted to find the statistical mean number of routes in the graph we could easily write a query like the one below to tell us how many airports and outgoing routes in total there are in the graph.

g.V().hasLabel('airport').union(count(),out('route').count()).fold()

[3340,40662]

We could then use the Gremlin Console do the division for us to calculate the mean.

gremlin> 40662/3340
==>12.1742514970

However, Gremlin also has a mean step that we can take advantage of if we can figure out a way to use it in this case that will do the work for us. Take a look at the next query. The key thing to note here is the way local has been used. This will cause Gremlin to essentially do what we did a bit more manually above. If we did not include local the answer would just be the total number of outgoing routes as Gremlin would essentially calculate 40662/1. By using local we force Gremlin to in essence create an array containing the number of routes for each airport, add those values up and divide by the number of elements in the array (the number of airports). I hope that makes sense. If it is confusing try the query yourself on the gremlin console with and without local and try it without the mean step. You will see all of the interim values instead!

g.V().hasLabel('airport').local(out('route').count()).mean()

12.174251497005988

So it seems there is an average of just over 12 outgoing routes per airport in the graph whichever way we decide to calculate it!

Now that we have a query figured out for calculating the average number of outgoing routes per airport, we can easily tweak it to do the same for incoming routes and combined, incoming and outgoing, routes.

// Average number of incoming routes
g.V().has('type','airport').local(__.in('route').count()).mean()

12.174251497005988

// Average number of outgoing and incoming routes
g.V().has('type','airport').local(both('route').count()).mean()

24.348502994011977

5.1.5. How many routes are there from airports in London (UK)?

This next query can be used to figure out how many outgoing routes each of the airports classified as being in (or near) London, England has. Note that we first find all airports in England using has('region,GB-ENG)'. If we did not do this we would pick up airports in other countries as well such as London, Ontario, in Canada.

g.V().has('region','GB-ENG').has('city','London').
      group().by('code').by(out().count())

[LCY:37, LHR:176, LTN:91, STN:162, LGW:179]

Here is a twist on the above theme. How many places can I get to from London in two hops but not including flights that end up back in London? It turns out there are over 2,000 places! Notice how aggregate is used to store the set of London airports as a collection that can be referenced later on in the query to help with ruling out any flights that would end up back in London.

// Leave from London, fly with one stop, not ending back in London, how many places?
g.V().has('region','GB-ENG').has('city','London').aggregate('lon').
      out().out().dedup().where(without('lon')).count()

2082

We could have written the previous query like this and avoided using aggregate but to me, this feels more clumsy and somewhat repetitive.

g.V().has('region','GB-ENG').has('city','London').out().out().dedup().
      not(and(has('city','London'),has('region','GB-ENG'))).count()

2240

5.1.6. What are the top ten airports by route count?

These next three queries produce a table of the top ten airports in terms of incoming, outgoing and overall routes. Note that because of the way some airlines route flights, the number of outgoing and incoming routes to an airport will not always be the same. For example, several KLM Airlines flights from Amsterdam to airports in Africa continue on to other African airports before returning to Amsterdam. As a result there are more inbound routes from than out bound routes to these airports.

First of all, this query will find the ten airports with the most incoming routes, sorted by descending order.

// Find the top ten overall in terms of incoming routes
g.V().hasLabel('airport').order().by(__.in('route').count(),decr).limit(10)
                         .project('ap','routes').by('code').by(__.in('route').count())
[ap:AMS, routes:249]
[ap:FRA, routes:243]
[ap:CDG, routes:239]
[ap:IST, routes:234]
[ap:ATL, routes:221]
[ap:PEK, routes:213]
[ap:ORD, routes:212]
[ap:MUC, routes:199]
[ap:DFW, routes:198]
[ap:DME, routes:190]

Now let’s do the same thing but for outgoing routes.

// Find the top ten overall in terms of outgoing routes
g.V().hasLabel('airport').order().by(out('routes').count(),decr).limit(10)
                         .project('ap','routes').by('code').by(out('routes').count())

[ap:FRA, routes:243]
[ap:AMS, routes:240]
[ap:CDG, routes:239]
[ap:IST, routes:232]
[ap:ATL, routes:221]
[ap:PEK, routes:213]
[ap:ORD, routes:212]
[ap:MUC, routes:199]
[ap:DFW, routes:198]
[ap:DME, routes:190]

Lastly, let’s find the top ten airports ordered by the total number of incoming and outgoing routes that they have.

// Find the top ten overall in terms of total routes
g.V().hasLabel('airport').order().by(both('route').count(),decr).limit(10).
      project('ap','routes').by('code').by(both('route').count())

[ap:FRA,routes:544]
[ap:AMS,routes:541]
[ap:IST,routes:540]
[ap:CDG,routes:524]
[ap:MUC,routes:474]
[ap:PEK,routes:469]
[ap:ATL,routes:464]
[ap:ORD,routes:464]
[ap:DXB,routes:460]
[ap:DFW,routes:442]

5.1.7. Using local while counting things

Earlier in this document we saw examples of local being used. Here is another example of how local can be used while counting things to achieve a desired result.

Take a look at the query below. It finds any airports that have six or more runways and then returns the airports IATA code along with the number of runways.

g.V().has('airport','runways',gte(6)).values('code','runways').fold()

Here is the output from running the query. As you can see what is returned is a list of airport codes with each followed by its runway count.

[BOS,6,DFW,7,ORD,8,DEN,6,DTW,6,AMS,6]

While the output returned by the previous query is not bad, it might be nice to have what is returned be a set of code and runway pairs each in it’s own list. We can achieve this result by having the fold step applied to the interim or local results of the query.

Take a look at the modified form of the query below. Part of the query is now wrapped inside of a local step.

g.V().has('airport','runways',gte(6)).local(values('code','runways').fold())

Here is the output from running our modified form of the query. Each airport code and runway value pair is now in it’s own individual list.

[BOS,6]
[DFW,7]
[ORD,8]
[DEN,6]
[DTW,6]
[AMS,6]

5.2. Where can I fly to from here?

Here are some more examples of queries that explore different questions along the lines of "Where can I fly to from here?". The first query looks for routes to the USA or Canada from any airport in India.

// Where in the USA or Canada can I fly to from any airport in India?
g.V().has('country','code','IN').out().out().
      has('country',within('US','CA')).path().by('code')

[IN,BOM,EWR]
[IN,DEL,SFO]
[IN,DEL,EWR]
[IN,DEL,JFK]
[IN,DEL,ORD]
[IN,DEL,YVR]
[IN,DEL,YYZ]

Which cities in Europe can I fly to from Ft. Lauderdale in Florida?

// Where can I fly to in Europe from Ft. Lauderdale?
g.V().has('code','FLL').out().as('a').in('contains').
      has('code','EU').select('a').values('city')

London
Paris
Oslo
Stockholm
Copenhagen

Where can I fly to from Charlotte, North Carolina to cities in Europe or South America?

// Flights from Charlotte to airports in Europe or South America
g.V().has('code','CLT').out().as('a').in('contains').
      has('code',within('EU','SA')).select('a').by('code')

LHR     FCO
CDG     MAD
FRA     MUC
GIG     DUB
GRU

Where in the United States can I fly from to any one of the five airports in the London area in the UK?

// Where in the United States can I fly to non-stop from any of the
// airports in and around London in the UK.
g.V().has('airport','code',within('LHR','LCY','LGW','LTN','STN')).
      out().has('country','US').path().by('code')

[LHR,AUS]      [LHR,SEA]      [LHR,EWR]
[LHR,ATL]      [LHR,RDU]      [LHR,DEN]
[LHR,BWI]      [LHR,SJC]      [LHR,DTW]
[LHR,BOS]      [LHR,SFO]      [LHR,PHL]
[LHR,IAD]      [LHR,LAX]      [LGW,SFO]
[LHR,DFW]      [LHR,JFK]      [LGW,LAS]
[LHR,MSP]      [LHR,IAH]      [LGW,TPA]
[LHR,MIA]      [LHR,LAS]      [LGW,FLL]
[LHR,PHX]      [LHR,CLT]      [LGW,MCO]
[LHR,ORD]      [LHR,SAN]      [LGW,JFK]

Where in New York state can I fly to from any of the airports in Texas?

// Where in New York state can I fly to from any airport in Texas?
g.V().has('airport','region','US-TX').out().has('region','US-NY').path().by('code')

[AUS,JFK]      [IAH,EWR]
[AUS,EWR]      [SAT,EWR]
[DFW,EWR]      [SAT,JFK]
[DFW,JFK]      [HOU,JFK]
[DFW,LGA]      [HOU,LGA]
[IAH,JFK]      [HOU,EWR]
[IAH,LGA]

Which cities in Mexico can I fly to from Denver?

// Where in Mexico can I fly to from Denver?
g.V().has('code','DEN').out().has('country','MX').values('city')

Puerto Vallarta
San Josa del Cabo
Cozumel
Mexico City
Cancun

Which cities in Europe can I fly to from Delhi in India?

// Where in Europe can I fly to from Delhi?
g.V().has('code','DEL').out().as('a').in("contains").
      has('code','EU').select('a').by('city')

Istanbul
Helsinki
Paris
Frankfurt
London
Birmingham
Vienna
Zurich
Amsterdam
Moscow
Brussels
Munich
Rome

Find all the routes between airports in London, Munich and Paris. Notice how by using aggregate to collect the results of the first within test that we don’t have to repeat the names in the second within, we can just refer to the aggregated collection.

g.V().has('city',within('London','Munich','Paris')).aggregate('a').out().
      where(within('a')).path().by('code')

[LHR,MUC]   [CDG,LHR]   [MUC,STN]   [STN,MUC]
[LHR,ORY]   [CDG,LGW]   [MUC,LHR]   [ORY,LCY]
[LHR,CDG]   [CDG,MUC]   [MUC,LGW]   [ORY,MUC]
[LGW,MUC]   [CDG,LCY]   [MUC,CDG]   [ORY,LHR]
[LGW,CDG]   [MUC,LTN]   [LCY,CDG]   [LTN,CDG]
[CDG,LTN]   [MUC,ORY]   [LCY,ORY]   [LTN,MUC]

5.3. More analysis of distances between airports

In this section you will find some more queries that examine distances between airports.

This query returns a nice list of all the routes from Austin (AUS) along with their distances. The results are sorted in ascending order by distance. For ease of reading I broke the results into four columns.

// Distances of all routes from AUS along with destination IATA CODE
g.V().has('code','AUS').outE().order().by('dist',incr).inV().path().by('code').by('dist')

[AUS,142,IAH]      [AUS,755,GDL]       [AUS,1080,LAS]       [AUS,1430,PHL]
[AUS,152,HOU]      [AUS,755,BNA]       [AUS,1080,SLC]       [AUS,1476,SJC]
[AUS,183,DFW]      [AUS,768,DEN]       [AUS,1110,FLL]       [AUS,1493,OAK]
[AUS,189,DAL]      [AUS,809,ATL]       [AUS,1140,DTW]       [AUS,1500,SFO]
[AUS,274,HRL]      [AUS,866,PHX]       [AUS,1160,SAN]       [AUS,1500,EWR]
[AUS,341,LBB]      [AUS,922,CUN]       [AUS,1173,CLE]       [AUS,1520,JFK]
[AUS,444,MSY]      [AUS,925,TPA]       [AUS,1220,LGB]       [AUS,1690,BOS]
[AUS,527,ELP]      [AUS,972,MDW]       [AUS,1230,LAX]       [AUS,1712,PDX]
[AUS,558,MEM]      [AUS,973,ORD]       [AUS,1294,IAD]       [AUS,1768,SEA]
[AUS,618,ABQ]      [AUS,994,MCO]       [AUS,1313,DCA]       [AUS,4901,LHR]
[AUS,722,STL]      [AUS,1030,CLT]      [AUS,1339,BWI]       [AUS,5294,FRA]
[AUS,748,MEX]      [AUS,1040,MSP]      [AUS,1357,YYZ]

This query finds all routes from DFW that are longer than 4,000 miles and returns the airport codes and the distances. Notice the use of two by modulators in this query to decide which values are returned from the source node, the edge and the destination node respectively. Also note that only two were specified but three values are returned. This works because by is processed in a round robin fashion if there are more values than by modulators.

// Where can I fly to from DFW that is more than 4,000 miles away?
g.V().has('code','DFW').outE('route').has('dist',gt(4000)).inV()\
                       .path().by('code').by('dist')

[DFW,8105,HKG]   [DFW,8022,DXB]
[DFW,6951,PEK]   [DFW,6822,ICN]
[DFW,7332,PVG]   [DFW,5228,GIG]
[DFW,4905,AMS]   [DFW,5119,GRU]
[DFW,4950,MAD]   [DFW,5299,EZE]
[DFW,4736,LHR]   [DFW,4884,SCL]
[DFW,4933,CDG]   [DFW,7914,DOH]
[DFW,5127,FRA]   [DFW,8053,AUH]
[DFW,6410,NRT]   [DFW,5015,DUS]
[DFW,8574,SYD]

This next query also finds all routes longer than 4,000 miles but this time originating in London Gatwick. Note also the use of where to query the edge distance. The has form is simpler but I show where being used just to demonstrate an alternative way we could do it. Note that this query uses three by modulators as each of the values returned is from a different property of the respective vertices and edges.

// Routes longer than 4,000 miles starting at LGW
g.V().has('code','LGW').outE().where(values('dist').is(gt(4000L))) \
     .inV().path().by('code').by('dist').by('city')

[LGW, 5287, MalT]              [LGW, 4380, Calgary]
[LGW, 4618, Varadero]          [LGW, 5987, Cape Town]
[LGW, 5147, Tianjin]           [LGW, 4680, Kingston]
[LGW, 5303, Chongqing]         [LGW, 4953, Cancun]
[LGW, 4410, Ft. Lauderdale]    [LGW, 5399, Colombo]
[LGW, 5463, Los Angeles]       [LGW, 4197, Bridgetown]
[LGW, 4341, Orlando]           [LGW, 4076, St. George]
[LGW, 5374, San Francisco]     [LGW, 4408, Port of Spain]
[LGW, 4416, Tampa]             [LGW, 4699, Montego Bay]
[LGW, 5236, Las Vegas]         [LGW, 4283, Punta Cana]
[LGW, 5364, Oakland]           [LGW, 5419, San Jose]
[LGW, 4731, Vancouver]         [LGW, 4662, Havana]
[LGW, 5982, Hong Kong]         [LGW, 6053, Port Louis]
[LGW, 5070, Beijing]           [LGW, 4222, Vieux Fort]

This query is similar to the previous ones. We look for any routes from DFW that are longer than 4,500 miles. However, there are a few differences in this query worthy of note. First of all it uses the preferred has technique again to test the distance whereas in the previous query we used where. Also this time we just list the distance and the destination airport’s code and we sort the end result using a sort. We also use select and as rather than the perhaps more succinct path and by to show a different way of achieving effectively the same results.The path and by combination were introduced more recently into TinkerPop and I find that to be a more convenient syntax to use most of the time but both ways work and both have their benefits. We should also note that I show sort being used here but in most cases we can re-write our query to use order. You will find several examples of order being used throughout this document. Order is introduced in the "Sorting things" section.

// Routes from DFW that are over 4,500 miles in length.
// Sorted into ascending order

g.V().hasLabel('airport').has('code','DFW').outE().has('dist',gt(4500)).as('e').
      inV().as('c').select('e','c').by('dist').by('code').sort(){it.e}


[e:4736, c:LHR]     [e:6410, c:NRT]
[e:4884, c:SCL]     [e:6822, c:ICN]
[e:4905, c:AMS]     [e:6951, c:PEK]
[e:4933, c:CDG]     [e:7332, c:PVG]
[e:4950, c:MAD]     [e:7914, c:DOH]
[e:5015, c:DUS]     [e:8022, c:DXB]
[e:5119, c:GRU]     [e:8053, c:AUH]
[e:5127, c:FRA]     [e:8105, c:HKG]
[e:5228, c:GIG]     [e:8574, c:SYD]
[e:5299, c:EZE]

5.3.1. Finding routes longer than 8,000 miles

This next set of queries show various ways of finding and presenting all routes longer than 8,000 miles. Each query improves upon the one before by adding some additional feature or using a step that simplifies the query. First of all let’s just find all routes longer than 8,000 miles. This will includes routes in both directions between airport pairs.

// All outes longer than 8,000 miles
g.V().as('src').outE('route').has('dist',gt(8000)).inV().as('dest').
      select('src','dest').by('code')


[src:ATL,dest:JNB]   [src:SIN,dest:SFO]
[src:DFW,dest:SYD]   [src:DXB,dest:DFW]
[src:DFW,dest:DXB]   [src:DXB,dest:IAH]
[src:DFW,dest:HKG]   [src:DXB,dest:LAX]
[src:DFW,dest:AUH]   [src:DXB,dest:SFO]
[src:IAH,dest:DXB]   [src:DXB,dest:AKL]
[src:IAH,dest:DOH]   [src:HKG,dest:DFW]
[src:JFK,dest:HKG]   [src:HKG,dest:JFK]
[src:LAX,dest:DXB]   [src:HKG,
